DRO Innova 40i TS/ 40i TS-B
Quick Reference
This quick reference shows how to access the main functions shown by the color TFT screen of the DRO. Once
these functions are accessed, the DRO will guide the operator through its operations easily and intuitively with
interactive assistance messages.
For further detail on all the features, refer to the CD that comes with the DRO and contains the full installation
and operation manuals which are also available on our corporate website: www.fagorautomation.com.
Turning the DRO on and off
The DRO turns on automatically when applying voltage or after pressing the on/off key.
Front plate
TFT screen
Keys to open droplist buttons of the
Axis zero and preset
Pressing Set/Clear toggles between axis zeroing (Clear) and presetting (Set). The status bar shows the current
status of this function at the top left with the letters C or S.
Spindle orientation
Stops the spindle. When pressed while the spindle is stopped, it gives access to spindle orientation.
Keys for axes
FUNCTION BAR
(Manual code: 14460114 version: 1205)
Power-off button
Power indicator LED
Keys for entering numeric values
Abort
Validate
Cursor keys
Spindle keys
