Button Menu Control; Unlock & Power Select Mode; Button Menu Structure - Team Blacksheep TBS UNIFY PRO32 5G8 nano Manual

Button menu control
The menu consists of categories and settings. Pressing the button for 3 seconds will toggle between
categories, pressing it for a short time toggles between settings. To enter the menu, hold the button for 3
seconds. LED colors will signal the state of the menu, for an overview see the menu table .
Unlock & power select mode
(FOR HAM USERS ONLY!) Press the button for about 30 seconds. The Red LED will flash 3 times to confirm.
You have unlocked the video transmitter for use with all frequencies (see frequency table below).
NOTE : Unlock only works if you are inside the band selection menu
The power select mode is now accessible. Once unlocked, you can select the power level according to the
table below. To lock the transmitter, go back into band select menu and press the button for 20 to 25
seconds again.
Button menu structure
For Unify PRO32 HV
6
