Specifications

Input voltage:
Power Output
Extra features:
Software
protocol
Output Power
Pit mode
Pit mode -> flight
mode
Channels:
Audio on 6.5MHz
Power consumption
Range:
Antenna connector:
Port connector
Dimensions:
Weight:
Firmware upgrade
Kit contents:



TBS UNIFY PRO32 5G8 nano
1S - 3S LiPo

3V - 13V
Input Voltage - LC filter - Output voltage
(pass through, following input voltage)
PITMode (incl. Support for team racing)
Full CRSF capability (Serial commands for external control)
14dBm (25mW)
20dBm (100mW*)
26dBm (400mW*)
28dBm (600mW*) (Rev 1.1)
Activate: Press power during startup
Disable / Deactivate: Press power for 5 seconds during runtime
On-board button, SmartAudio 2.1 or CRSF Command
No
25mW: 210mA
100mW: 280mA
400mW: 390mA
2km (omni)
u.FL high strength
Through-holes, 2mm pitch
14.5(L) x 13(W) x 3(H) mm
1g
No
TBS UNIFY PRO32 NANO
u.FL Antenna
Silicon Cables pre- tinned
TBS UNIFY PRO32 HV (MMCX)
Regulated and filtered 5V / 2A
CleanSwipe
SmartAudio V2.1
CRSF
or use Smart Audio V2.1
LED flashes red when enabled
Or use Smart Audio V2.1
Band A (8ch), B (8ch), E (5ch)
Fatshark 8ch, Race Band 8ch
Yes, built in Microphone
25mW: 90mA - 130mA (22V - 14.8V)
100mW: 120mA - 170mA (22V - 14.8V)
400mW: 180mA - 270mA (22V - 14.8V)
1000mW+: 300mA - 450mA (22V - 14.8V)
37(L) x 25(W) x 6(H) mm
Through USB via TBS Agent
JST-GH 7pin Silicon Cable, ends pre- tinned
3
2S - 6S LiPo

6V - 36V
14dBm (25mW)
20dBm (100mW*)
26dBm (400mW*)
30dBm (1000mW*)
6km (omni)
80km+ (directional)
MMCX
JST-GH 7 pin
9.2g
Yes
TBS UNIFY PRO32
MMCX to SMA Pigtail
