If machine CAN be moved without adding or removing weight stack
Two people will be required for this procedure
1. Move to desired location.
2. Remove shipping cones using a 3/4" socket or wrench.
3.
Remove bolt from shipping cone with hammer. Recycle cone.
4. Attach foot pads to each foot of frame.
If machine CANNOT be moved without adding or removing weight stack
Two people will be required for this procedure
1. Do not remove middle BHSCS securing shroud to bottom bracket.
2. Remove the two Button Head Socket Cap Screws (BHSCS) securing the bottom bracket to the
frame sing a 1/8" Allen wrench.
3. Remove the remaining BHSCS securing the back shroud to the frame.
4. After the final BHSCS is removed shroud will slide down to the floor with bottom bracket attached.
5. Slide shroud out of machine.
6. Slide spring loaded top guide rod cap down guide rod until cap is clear of frame.
7. Slowly release grasp of guide rod cap.
8. Guide rod cap contains a compression spring that will fly if grasp is not released slowly.
9. Remove guide rod cap and spring and set aside.
10. Repeat above steps for opposite guide rod.
11. Lean guide rods slightly outward, away from machine to clear pulley. DO NOT put excessive pressure
on guide rods, it will damage rod caps.
12. Slide top weight up and out of the machine and set aside.
13. Remove weight plates.
14. Move to desired location.
15. Remove shipping cones using a 3/4" socket or wrench.
16.
Remove bolt from shipping cone with hammer. Recycle cone.
17. Attach foot pads to each foot of frame.
Securely anchor machine to floor
Owner should not allow equipment to be used until it is properly anchored as described below.
VR3 Lat Pull Part Number 12130-999-4 T
