- Page 1 GF / GS / CR SERIES USER MANUAL www.rksmotor.eu...
-
Page 3: Table Of Contents
TABLE OF CONTENT 1. The Purpose and Benefit of a Booklet 2. Assembly Instructions 3. Operation of Your Electric Bike 4. Best Practices 5. Adjustment and Maintenance 6. Troubleshooting FOREWORD The following operation manual is a guide to assist you. This manual is not a complete document on all aspects for the maintenance and repair of your bike. - Page 4 ABOUT THIS MANUAL WHY YOU SHOULD READ THIS MANUAL Th s manual s wr tten to help you to get the best performance, comfort, enjoyment and safety when r d ng your new E-B ke. The manual descr bes spec fic care and ma ntenance procedures that help protect your warranty and ensure years of trouble free use.
- Page 5 Check w th your local pol ce department for requ rements n your commun ty. Do not wear loose cloth ng that can become tangled n the mov ng parts of the E-B ke. Wear sturdy shoes and eye protect on. Also check your state laws concern ng other protect ve wear that may be requ red when r d ng the E-B ke.
- Page 6 Know the Law Cycl sts are requ red to follow traffic rules. Add t onally, some commun t es regulate the use of motor zed b cycles regard ng m n mum age requ rements and necessary equ pment. Check w th your local pol ce department for spec fic deta ls.
- Page 7 The Purpose and Benefit of this Booklet This booklet describes assembly and safe operation of your electric bicycle. Pictures are for reference only and may show the similar component from another model. • Please Read The Entire Users Manual Before Riding Your New Electric Bicycle •...
- Page 8 All photos are for general reference only and may differ slightly for each model of pedelec. NEVER carry a passenger on the Electr c B ke! NEVER mod fy the Electr c B ke w th unapproved accessor es. NEVER r de through deep water. NEVER perform wheel es, jumps or tr ck stunts.
-
Page 9: Assembly Instructions
8. It is forbidden to be overloaded for the electric bicycle. If it is overloaded, the electrical parts will be damaged.( the plastic parts may disformed for the high temperature, or the fuse socket will be damaged for the high temperature) These are not under warranty. 9. - Page 10 Name of clamp bolts Standart torque / N.m 10-12 1 bolt / 2 bolts 12-15 Bolt for handlebar 4 bolts 8-10 12-15 Handlebar expander bolt 15-18 8-10 Handle bar stem and fork clamp bolt 10-18 Sunflower fix ng bolt 10-12 Saddle 15-18 8-10...
- Page 11 Your handlebars have two main parts--the bar itself and the stem.On some models, the stem can be adjusted to tip the handlebar forward or back. If your bar has been removed for shipping, position the bar in the center of the stem and check, to be sure that your grips are in the right place and the angle of the bar is comfortable.
- Page 12 Check and adjust the Front Brake Screw down the positioning screw; Adjust the distance of brake shoe by left/right rotation, the left rotation of brake shoe adjustment bolt will increase the distance of brake shoe, and the distance of brake shoe will decrease on the contrary (as shown in Fig and disc Fig).The adjustment for brake shall be made according to conditions.
- Page 13 Always check that both your front and rear brakes are properly adjusted before riding your bike. Squeeze your brake together and slip the cable into the trough. You may need to adjust the cable length by loosening the nut and sliding the cable through to the proper position.
- Page 14 Adjust the Saddle Your seat will tip forward for easy battery removal on most models. Your seat height is adjusted by a quick release. Pull the quick release lever, Insert your seat post to at least the minimum insertion line marked on the post.
-
Page 15: Operation Of Your Electric Bike
Operation of Your Electric Bike Your e-bike is driven by a motor embedded in the hub of the rear wheel and can not be driven directly by throttle. The motor is powered by a battery. The amount of power delivered to the motor, and hence the accelerating force on the e-bike, is controlled by you in a way according to the power-assisted mode you choose. - Page 16 Always charge your battery before it gets too low. If you let your pack run completely dead, it may not re-charge. It is a good idea to turn the key to the position OFF and remove your key after any ride so that it will not be left on accidentally.
-
Page 17: Best Practices
Best Practices Please observe the traffic regulations. Keep both your hands on the handlebars ready to brake while riding. Always charge your battery after riding. Don' t run your battery dead or extremely low. If you do, charge as soon as you can. -
Page 18: Adjustment And Maintenance
The match of the electric bicycle and people Adjustments and Maintenance • Your e-bike is designed for regular road for a single person. Using your e-bike for extreme maneuvers, such as extreme off-road use, jumping, or carrying excessive load will damage the e-bike and could cause serious injury. - Page 19 • Using soap and hot water,wash all oil off the wheel rims,the brake shoes,the pedals,and the tires.Rinse with clean water and dry completely before you ride the bicycle. • Using a light machine oil (20W) and the following guidelines,lubricate the bicycle: Put 4 drops of o l where catch pedal axle Every 6 Months Pedal...
-
Page 20: Troubleshooting
9. Please sure that there is no short-circuit in your wall socket for fear of burning out battery and causing danger. 10.Please don‟t pull out the power key when you are riding the bike forward under highspeed. BATTERY DISPOSAL W A R N I N G ! NEVER throw batteries away in the trash. - Page 21 1)Loose connectors 1) Check all Bicycle has 2) Loose fuse connectors intermittent 3) Damaged wires 2) Check fuse power connector 3) Inspect all wires 1)Power outlet faulty 1) Try another outlet 2)Charger is not 2) Check all plugs Charger light plugged to wall or 3) Replace charger does not...
- Page 22 Regular Inspection List Before every ride, it is important to carry out the following safety checks 1.Brakes • Ensure front and rear brakes work properly • Ensure brake shoe pads are not over worn and are correctly positioned in relation to the rims. •...
- Page 23 7.Bearings • Ensure all bearings are lubricated, run freely and display no excess movement, grinding or ratting. • Check headset, wheel bearing, pedal bearings and bottom bracket bearings and Lubricate it regularly 8.Cranks and pedals • Ensure pedals are securely tightened to the cranks. •...
- Page 24 GS25 GF25...
- Page 26 ABOUT SEALER AND INFORMATION CARD Purchase Record Card F ll n mmed ately and reta n as a record of your purchase * Please reta n your sales rece pt for any poss ble warranty cla ms Your Name: Address: Date Purchased: Place of Purchase: Model &...
- Page 27 RKS MOTOR 4. Organize Sanayi Bolgesi 83422 Nolu Cad. - Sehitkamil / Gaziantep 0850 302 86 92 - info@mj.com.tr - www.rksmotor.eu RKS; reserves the right to process the product specifications, color and permits.
