- Page 1 User Instructions To be read in conjunction with the Pingg-String Installation Guide © Sureguard – All Rights Reserved www.sureguard.com.au – Revision #4 September 2020...
- Page 3 Fence-Top Barrier (for Cats & Possums) Both are powered by this Pingg-String Energiser. The barrier kits are sold separately, so you only need to buy what you need. For details, refer to the Pingg-String Installation Guide. Solar Powered Fence Energiser...
-
Page 4: Specifications
Specifications • Maximum Distance Rating for Ground Kit (1-Wire): 400m (1300ft) • Maximum Distance Rating for Fence-Top (4-Wire): 200m (650ft) • Weight: 0.7kg (25oz) • Dimensions: 195mm Wide. 100mm High. 220mm Deep. (4.95" x 3.95" x 8.65"). • Battery Life: 5 to 8 years, under typical operating conditions. Battery Technology LiFePO4. - Page 5 Screw Mounting Insert a single M4 screw (4mm with head no more than 9mm) into timber, steel or plastic fencing or posts to hang the Energiser using the screw mounting option (Key #3 on page 3). Steel Post Anti-Theft Mounting You can mount the Energiser on top of most sizes of steel posts (Key #4 &...
- Page 6 Energiser to the Pingg-String fence. Please refer to Figure 24 of the Pingg-String Installation Guide for wiring details. Cut two pieces of Pingg-String Cable of suitable length to connect each Terminal of your Energiser to your Pingg-String fence. Remove at least 12mm of insulation. Twist the copper wires together.
- Page 7 Normal operation. The Pingg-String Wire is active. GREEN Pingg-String fence wire has low power. FENCE Pingg-String fence wire has very low power. Rectify immediately! RED FLASHING BLUE You have selected the ON/OFF Timer. The fence is currently inactive. BLUE FLASHING Only happens when switched ON.
- Page 8 ❖ Touch once (Function #1): Reset all functions to factory default and perform tests in the following order: 1/ LED’s light in sequence RED-GREEN-BLUE 2/ Alarm Buzzer sounds. 3/ Solar panel, in sunlight, is linked to the POWER LED. It will flicker BLUE to verify power is going into the battery.
- Page 9 ❖ Touch 10 times: Reports the highest fence voltage since mid-night. ❖ More than 10: Does nothing. Beeps an error. Rectifying Power Faults POWER LED Continuously RED: The internal battery needs more charge. The Energiser will automatically lower its power consumption to continue operation.
-
Page 10: Maintenance
3. Switch ON the Energiser. If the Energiser now displays a GREEN FENCE LED, you have a normal output. This result implies you have excessive power loss somewhere on the fence wires. If the Energiser doesn’t pass this self-test, then call Sureguard for advice.
