- Page 2 Table of Contents: Introduction .................... 2 Product instructions and warnings ............3 Inflation and set up ................. 8 Preparation for use.……………………………………………………………………. 10 Operation ..................... 12 Cleaning and repair ................17 Date Purchased: __________________________ Purchased from: __________________________ Serial Number: ___________________________ (Serial # is located next to the inflation valve on the bow tube.) Contents: Qty 1- Super Shuttle™...
- Page 3 Make sure that everyone who operates this product also receives proper education and supervision and understands the safety instructions and warnings presented in this manual. Be sure to save this manual for future reference. If you have any questions regarding this product, please call RAVE Sports at: www.ravesports.com 1-800-659-0790 or visit Please have your serial number available.
-
Page 4: Product Instructions And Warnings
W A R N I N G USE OF THIS PRODUCT AND PARTICIPATION IN PARASAILING INVOLVES INHERENT RISKS OF INJURY OR DEATH. 1. The Super Shuttle™ is designed to carry no more than 7 persons or 1,500 lbs/680kg. Shuttle can carry 6 Passengers plus 1 supervising Crew Member. 2. - Page 5 ▪ Do not use a tow rope with elastic or bungee material to pull Shuttle. Such an addition can break or stretch, which may lead to injury of PWC operators or Shuttle occupants. ▪ The stress on the tow rope is different than the stress on the Shuttle. Stress will vary with the weight of the riders combined with the force of wind, waves and currents acting on the Shuttle as well as Shuttle impact with waves and surf.
- Page 6 ▪ Do not attempt to tip, roll, or stand on Shuttle while being towed. ▪ Do not use after consuming alcohol or drugs. ▪ If unclear about these Warnings or the proper use of the Super Shuttle, call RAVE Sports customer service (1-800-659-0790).
- Page 7 Water Sports Responsibility Code Water sports are fun and challenging but involve inherent risks of injury or death. To increase your enjoyment of water sports and to reduce your risks, use common sense and follow these rules. Before you start: Familiarize yourself with all applicable federal, state and local laws, the risks inherent in the ▪...
- Page 8 ▪ Keep away from the tow rope and Shuttle tow harness to avoid injury. Passengers can be hit or become entangled in the ropes. ▪ Ensure tow rope is clear of all body parts prior to starting out or during use. Inspect tow rope and its attachments before using.
- Page 9 Step 2 Before starting the inflation process, locate all 5 air chamber valve openings on the Super Shuttle. Use the RAVE Sports Inflator/Deflator (item #01083) for inflating the Shuttle. valves IMPORTANT: Inflate tubes only until the Super Shuttle takes shape (about 80% to 90% air volume).
-
Page 10: Valve Positions
Push in full and turn ¼ turn to lock in place. NOTE: RAVE Sports’ special adaptor found on the High Speed Inflator and Digital Pressure Gauge will automatically open the valve when inserted and will close the valve when removed. - Page 11 Step 3 Carry (DO NOT DRAG) the Shuttle and place in shallow water. Step 4 Attach proper rated tow line/rope (not included) to the Shuttle Towing Harness. • Feed tow line through the open forward hole of BOTH nylon sliding rings. It is critical to tow with both rings together.
- Page 12 ▪ Conduct test runs without passengers to gain experience with the Shuttle docking procedure, approach angles, speeds, securing Shuttle to parasail boat, releasing Shuttle from boat, etc. Always attach docking line Attach second docking line to forward D-Ring to shuttle D-Ring which best aligns with aft boat cleat IMPORTANT: For safe passenger transfer, Shuttle must be tightly secured to the Parasail Boat with NO GAP between Shuttle and Boat.
- Page 13 SAFELY OPERATING YOUR RAVE SUPER SHUTTLE Beach Boarding Procedure: ▪ Always secure Super Shuttle on the beach in a position that will not allow the Surf to pull it out to sea. Orient the Shuttle so the bow is facing away from the beach towards open water. Do not allow the Shuttle to position itself sideways against incoming waves.
- Page 14 ▪ PWC driver will tow the Super Shuttle to meet the moving Parasail Boat in open water. ▪ All riders MUST stay seated and follow directions of Crew Members while the Super Shuttle is underway. Dock/Pier Boarding Procedure: ▪ Use extreme caution when maneuvering and docking the Shuttle to the Dock/Pier. ▪...
- Page 15 Super Shuttle & Parasail Boat Docking Procedure ▪ The Super Shuttle must dock along the side of the moving Parasail Boat. ▪ The PWC and Shuttle should approach from the stern of the moving Parasail Boat, on a parallel course with the Boat. ▪...
- Page 16 Transferring Passengers from the Super Shuttle to the Parasail Boat: ▪ Only after the Super Shuttle is secured TIGHTLY to the side of the Parasail Boat, Riders may safely transfer to the Parasail Boat under the direction of the Boat Crew. ▪...
- Page 17 ▪ All riders MUST follow directions of Crew Members while the Super Shuttle is underway. ▪ Upon returning to the Beach and after Crew members have secured the Shuttle, Riders may exit to the rear of the Super Shuttle. Emergency Re-Boarding of the Super Shuttle in Open Water: ▪...
- Page 18 Repairs For large holes, tears or seam damage, contact RAVE Sports Customer Service at 1-800-659-0790. IMPORTANT: repair glue is not included with this product. Repair glue and additional patch material is available from RAVE Sports.
- Page 19 NOTE: Adhesion of the patch will increase with time. If you can wait before inflating and using, the adhesion of the patch will be increased. 3” x 6” Tear Aid® Type B clear patch material: Item #20100- order from RAVE Sports. To purchase, Contact RAVE Customer Service (1-800-659-0790) or purchase on our website (www.ravesports.com)
- Page 20 RAVE Sports A Revel Match, LLC Company 985 Aldrin Drive Suite #301 Eagan, Minnesota 55121 800.659.0790 February 2020...
