- Page 1 USER MANUAL...
-
Page 3: Check Packing Contents
Check Packing Contents User manual / Warranty card Case body Quality approval Charger Spare charger (Optional) Dust cover Battery wiring Packing List Case body 1 unit Charger 1 unit Quality approval manual / Warranty card 1 unit 1 unit Battery wiring 1 unit Spare charger(Optional) 1 unit... - Page 4 SE3 Diagram *Lite edition Customs coded lock Accelerator Power switch Charge interface Meter Unfold switch Handle Lift grip Quick connector Pull rod Rear light Front wheel Pedal Rear wheel Meter instruction Battery SPEED indication 1. Short press the up button to switch...
- Page 5 SE3 Diagram *Wit edition Flash light Bluetooth speaker USB Charger Bluetooth speaker instruction(wit edition) Turn on phone's bluetooth, play music once connected. - 03 -...
-
Page 6: Main Specifications
Specifications Main specifications 629X365X826mm Vehicle weight ~14.5kg Open size Folded size 489X365X580mm Maximum load 90kg USB Output voltage Maximum climbing angles ~15° Lock type TSA coded lock Applicable temperature -10℃ ~40℃ Rear wheel 8 inches inflatableX2 Volume 29.3L Shell ABS+PC Material Front wheel 6.5 inches motor wheel... - Page 7 Use SE3 quick connector Folded status Unfolded status Unfold Turn on the power switch and place the unfold switch in the "I" position. The handlebars will automatically unfold. After the expansion is completed, the unfold switch will be reset to the "o"...
- Page 8 Custom coded lock instruction The original password is 0-0-0, set your own password, follow these steps: 1.Dial the password to the original password: 0-0-0; 2.Press the button A with a pen or other tool until you hear the 'tick' sound; 3.Dial the password wheel B to set your own password, for example: 8-8-8;...
-
Page 9: Riding Precautions
Avoid using this product in bad weather (such as rain, snow, or ice). When not riding, turn off the power. Pull rod Towing SE3 Fold SE3, pull out rod and tow Lifting SE3 Lift grip Fold SE3, lift grip and go... -
Page 10: Very Important
It is strictly forbidden to accelerate, decelerate and turn sharply, or overspeed. When cell phone APP shows one cell or SE3 display voltage shows one cell, it is not recommended to ride. Please keep slow speed during riding. If you face risk of fall, please protect your personal safety. Do not consider SE3. The SE3 may lose during riding and during parking, affecting the performance of the product. -
Page 11: Charging Precautions
Charging precautions When charging, place it in a safe place that children cannot touch. It should not be used without full charge. Do not use other brands of charger to charge, other types of batteries should not use the charger. The charger contains high voltage circuits. -
Page 12: Download App
*Support Android 4.3 or higher, iOS 7.0 or higher. APP Instructions 1. Turn on SE3 power button, and start App as well as Bluetooth. 2. Click the search button and do as the follows to connect (verify password is 11111111). -
Page 13: Appearance Cleaning
Maintaining Appearance cleaning Vehicles need to be cleaned at any time. When cleaning dust, do not wipe the electrical parts and connectors with a damp cloth. Battery maintaining When using it, it was found that the battery was low, it need to be recharged. When not in use, turn off the switch.
