Summary of Contents for IKA LOGIC IkaScope WS200
- Page 1 IkaScope WS200 datasheet and user manual Ultra portable, one channel, 30 MHz, wireless oscilloscope. www.ikalogic.com | support@ikalogic.com December 28, 2020...
-
Page 2: Table Of Contents
IkaScope WS200 Ultra portable oscilloscope WS200 Contents IkaScope WS200 overview Typical applications ........ - Page 3 IkaScope WS200 Ultra portable oscilloscope WS200 What’s in the box Ordering information and customer support Accessories and maintenance Limited warranty & limitation of liability Document Revisions (c) Ikalogic SAS 2019 3/21...
-
Page 4: Ikascope Ws200 Overview
WS200 IkaScope WS200 overview IkaScope WS200 is an ultra portable oscilloscope probe. It weighs less than 60g and is designed to fit perfectly in your hand. With a Wifi connection to a smartphone, a tablet or a computer, signals can be displayed and measurements can be easily made. -
Page 5: Typical Applications
IkaScope WS200 Ultra portable oscilloscope WS200 Typical applications IkaScope is designed to be mobile, hence applications that require quick, on-the-field measurements are a perfect match for this technology. • Onsite maintenance and inspectio • Isolated measurements • Design troubleshooting • Education and research •... -
Page 6: Warning
IkaScope WS200 Ultra portable oscilloscope WS200 Warning Read safety information section carefully before using this instrument. (c) Ikalogic SAS 2019 6/21... -
Page 7: Main Characteristics
IkaScope WS200 Ultra portable oscilloscope WS200 Main characteristics Timing Sampling rate (MAX.) 200 MSPS (8 bits) Rise time (Calculated) 12 ns Input channels Sampling memory 4 Kpts Waveform update rate 250 fps Time base accuracy 100ppm Vertical Input impedance 1MΩ|| 14 pF... -
Page 8: General
IkaScope WS200 Ultra portable oscilloscope WS200 2V/div 38 MHz 5V/div 38 MHz 10V/div 30 MHz General Input protection 253 VAC during 1 minute (production sample test, not tested in production, not guaranteed). Do NOT exceed 40V! Input to USB galvanic isolation 520 VAC 1 minute (production sample test, not tested in production, not guaranteed). -
Page 9: Ikascope Ws200 Interfaces
IkaScope can be seen as a wireless oscilloscope probe, that displays measured signals and is configured via remote screen (Tablet, smartphone or computer). Technically speaking, IkaScope WS200 integrates a full featured analog front end, a digital processing stage and a wifi module. First, measured signals are conditioned, then converted to digital values via a high speed 8-bits ADC. -
Page 10: Probeclick®Technology
IkaScope WS200 Ultra portable oscilloscope WS200 ProbeClick®technology IkaScope incorporates an intelligent probe tip (called ProbeClick®) that detects when pressure is applied. This allows important power saving since all power consuming circuitry is in stand-by when a measurement is not in progress. That same intelligent probe tip is used to turn ON IkaScope, which then turns OFF a er 10 minutes of non activity. -
Page 11: First Connection
IkaScope to connect to existing wifi networks. This way, it won’t be necessary to change wifi settings of the display device for each and every usage. LEDs behavior There are 2 LEDs on the back of IkaScope probe. Refer to IkaScope WS200 interfaces section for more info about those LEDs. Battery status LED Normally, battery status LED is turned o . -
Page 12: Measuring Your First Signal
WS200 Figure 4: Ikascope application GUI 1. IkaScope general menu that gives you access to connection options (mainly to connect the application to a specific IkaScope WS200 device) 2. Menus for Measurements, cursors, trigger and annotations. 3. Autoset button 4. History feature, to restore previously measured signals. - Page 13 IkaScope WS200 Ultra portable oscilloscope WS200 Figure 5: Ikascope application screenshot Note: IkaScope device must be turned ON to be connected to a network. If all LEDs are switched OFF, please turn ON IkaScope by pressing on the probe tip for 1 second. Finally, press IkaScope probe tip on the pad where an electric signal needs to be measured.
-
Page 14: So Ware Technical Requirements
IkaScope WS200 Ultra portable oscilloscope WS200 So ware technical requirements Download the IkaScope app on www.ikalogic.com so you can use your device on your favorite platform. IkaScope can run on any of those platforms: • A Desktop computer connected to a network that has a Wifi spot (the computer may be connected by ethernet or Wifi). -
Page 15: Mechanical Data
EMC : IEC NF/EN 61326-1 (In high perturbed RF environment, the displayed signal may be altered during perturbation with self recovering) and complies with Limit for class B digital device, pursuant to part 15 of the FCC rules. IkaScope WS200 complies with the following regulations • FCC (Part 15) • CE •... - Page 16 IkaScope WS200 Ultra portable oscilloscope WS200 • PI967 SEA • UN38.3 IkaScope contains a Wifi module that complies with the following regulations • CE1177 • FCC (USA) • IC (Canada) • GITEKI • KCC All test certificates can be provided upon request.
-
Page 17: Safety Information
IkaScope WS200 Ultra portable oscilloscope WS200 Safety information This product complies with safety standards IEC NF/EN 61010-1: 2010, IEC NF/EN 61010-2-030 and UL 61010-1: 2015 To prevent possible electrical shock, fire, personal injury, or damage to the product, read all safety information before you use the product. The following international symbols are used on the product and in this manual. -
Page 18: Lithium Battery Safety Information
Periodically check and install new so ware updates on www.ikalogic.com as they can improve the safety of the product as well as its features. Lithium battery safety information IkaScope WS200 contains a 3.7V 420mAh lithium battery. Warning To avoid electrical shock or fire: (c) Ikalogic SAS 2019... - Page 19 • Never recharge a device that shows signs of malfunctioning. • Never recharge IkaScope WS200 for more than 3 hours (disconnect the USB cable from USB port) • Only use the USB cable provided by Ikalogic to recharge the device.
- Page 20 IkaScope WS200 Ultra portable oscilloscope WS200 Ordering information and customer support For ordering information, please check for nearest distributor on www.ikalogic.com or contact us for any inquiry at contact@ikalogic.com. Accessories and maintenance Accessories and maintenance services are available on our website: www.ikalogic.com or by contacting customer support (support@ikalogic.com).
- Page 21 IkaScope WS200 Ultra portable oscilloscope WS200 28-May-2019 Updated safety related information. 27-March-2018 Corrected time base accuracy. 26-February-2018 Added so ware technical requirements section. 04-December-2017 Initial release of this document. The information in this document is subject to change without notice.
