P4TCA Pro BIOS Setup
BIOS Setup....................................................................................... 1
1 Main Menu.................................................................................................... 3
2 Standard CMOS Features.............................................................................. 6
3 Advanced BIOS Features.............................................................................. 9
4 Advanced Chipset Features......................................................................... 13
5 Integrated Peripherals ................................................................................. 16
6 Power Management Setup........................................................................... 20
7 PnP/PCI Configurations .............................................................................. 24
8 PC Health Status ......................................................................................... 26
9 Frequency Control....................................................................................... 28
i
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Biostar P4TCA Pro
Summary of Contents for Biostar P4TCA Pro
-
Page 1: Table Of Contents
P4TCA Pro BIOS Setup BIOS Setup... 1 1 Main Menu... 3 2 Standard CMOS Features... 6 3 Advanced BIOS Features... 9 4 Advanced Chipset Features... 13 5 Integrated Peripherals ... 16 6 Power Management Setup... 20 7 PnP/PCI Configurations ... 24 8 PC Health Status ... -
Page 2: Bios Setup
P4TCA Pro BIOS Setup BIOS Setup Introduction This manual discussed Award™ Setup program built into the ROM BIOS. The Setup program allows users to modify the basic system configuration. This special information is then stored in battery-backed RAM so that it retains the Setup information when the power is turned off. - Page 3 P4TCA Pro BIOS Setup PCI Bus Support This AWARD BIOS also supports Version 2.1 of the Intel PCI (Peripheral Component Interconnect) local bus specification. DRAM Support DDR DRAM (Double Data Rate Synchronous DRAM) are supported. Supported CPUs This AWARD BIOS supports the Intel Pentium Using Setup In general, you use the arrow keys to highlight items, press <Enter>...
-
Page 4: Main Menu
P4TCA Pro BIOS Setup 1 Main Menu Once you enter Award BIOS™ CMOS Setup Utility, the Main Menu will appear on the screen. The Main Menu allows you to select from several setup functions. Use the arrow keys to select among the items and press <Enter> to accept and enter the sub-menu. - Page 5 P4TCA Pro BIOS Setup Input/ Output features. Power Management Setup This submenu allows you to configure the power management features. PnP/PCI Configurations This submenu allows you to configure certain “Plug and Play” and PCI options. PC Health Status This submenu allows you to monitor the hardware of your system.
- Page 6 P4TCA Pro BIOS Setup will be displayed before proceeding. Exit Without Saving Abandon all changes made during the current session and exit setup. Confirmation message will be displayed before proceeding. Upgrade BIOS This submenu allows you to upgrade bios.
-
Page 7: Standard Cmos Features
P4TCA Pro BIOS Setup 2 Standard CMOS Features The items in Standard CMOS Setup Menu are divided into 10 categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the<PgUp>... - Page 8 P4TCA Pro BIOS Setup Main Menu Selections This table shows the selections that you can make on the Main Menu. Item Options Date mm : dd : yy Time hh : mm : ss IDE Primary Master Options are in its sub menu.
- Page 9 P4TCA Pro BIOS Setup Item Options Halt On All Errors No Errors All, but Keyboard All, but Diskette All, but Disk/ Key Base Memory Extended Memory Total Memory Description Select the situation in which you want the BIOS to stop the POST process and notify you.
-
Page 10: Advanced Bios Features
P4TCA Pro BIOS Setup 3 Advanced BIOS Features Figure 3. Advanced BIOS Setup Boot Seq & Floppy Setup First/ Second/ Third/ Boot Other Device These BIOS attempt to load the operating system from the device in the sequence selected in these items. - Page 11 P4TCA Pro BIOS Setup Cache Setup CPU L1&L2 Cache Depending on the CPU/chipset in use, you may be able to increase memory access time with this option. Enabled (default) Disabled Virus Warning This option allows you to choose the Virus Warning feature that is used to protect the IDE Hard Disk boot sector.
-
Page 12: Apic Mode
P4TCA Pro BIOS Setup Typematic Delay (Msec) Sets the delay time after the key is held down before it begins to repeat the keystroke. The Choices: 250 (default), 500,750,1000. Security Option This option will enable only individuals with passwords to bring the system online and/or to use the CMOS Setup Utility. - Page 13 P4TCA Pro BIOS Setup Swap Floppy Drive For systems with two floppy drives, this option allows you to swap logical drive assignments. The Choices: Disabled (default), Enabled. Boot Up Floppy Seek Enabling this option will test the floppy drives to determine if they have 40 or 80 tracks.
-
Page 14: Advanced Chipset Features
P4TCA Pro BIOS Setup 4 Advanced Chipset Features This submenu allows you to configure the specific features of the chipset installed on your system. This chipset manage bus speeds and access to system memory resources, such as DRAM. It also coordinates communications with the PCI bus. The default settings that came with your system have been optimized and therefore should not be changed unless you are suspicious that the settings have been changed incorrectly. - Page 15 P4TCA Pro BIOS Setup DRAM RAS# to CAS# Delay This field let you insert a timing delay between the CAS and RAS strobe signals, used when DRAM is written to, read from, or refreshed. Fast gives faster performance; and slow gives more stable performance.
- Page 16 P4TCA Pro BIOS Setup AGP Aperture Size (MB) Select the size of the Accelerated Graphics Port (AGP) aperture. The apertures is a portion of the PCI memory address range dedicated for graphics memory address space. Host cycles that hit the aperture range are forwarded to the AGP without any translation.
-
Page 17: Integrated Peripherals
P4TCA Pro BIOS Setup 5 Integrated Peripherals Figure 5. Integrated Peripherals Onboard IDE Device Press Enter to configure the onboard IDE Controllers. IDE HDD Block Mode Block mode is also called block transfer, multiple commands, or multiple sector read / write. If your IDE hard drive supports block mode (most new drives do),... - Page 18 P4TCA Pro BIOS Setup Primary / Secondary /Master / Slave UDMA Ultra DMA/100 functionality can be implemented if it is supported by the IDE hard drives in your system. As well, your operating environment requires a DMA driver (Windows 95 OSR2 or a third party IDE bus master driver). If your hard drive and your system software both support Ultra DMA/100, select Auto to enable BIOS support.
- Page 19 P4TCA Pro BIOS Setup The Choices: Enabled (default), Disabled. Realtek Wirless LAN(optional) This item allows you to enable or disable the Onboard Realtek Wirless Controller. The Choices: Enabled (default), Disabled. Wirless Function(optional) This item allows you to switch the Wireless Function from Wireless Audio and Wireless Lan.
- Page 20 P4TCA Pro BIOS Setup UART Mode Select This item allows you to determine which Infrared (IR) function of onboard I/O chip. The Choices: Normal(default), ASKIR, IrDA, SCR . UR2 Duplex Mode Select the value required by the IR device connected to the IR port. Full-duplex mode permits simultaneous two-direction transmission.
-
Page 21: Power Management Setup
P4TCA Pro BIOS Setup 6 Power Management Setup The Power Management Setup Menu allows you to configure your system to utilize energy conservation and power up/power down features. Figure 6. Power Management Setup ACPI Function This item displays the status of the Advanced Configuration and Power Management (ACPI). - Page 22 P4TCA Pro BIOS Setup Power Management This category allows you to select the type (or degree) of power saving and is directly related to the following modes: 1. HDD Power Down. 2. Doze Mode. 3. Suspend Mode. There are four options of Power Management, three of which have fixed mode settings Min.
-
Page 23: Modem Use Irq
P4TCA Pro BIOS Setup Video Off In Suspend This determines the manner in which the monitor is blanked. The Choices: Yes (default), No. Suspend Type Select the Suspend Type. The Choices: Stop Grant, PwrOn Suspend (default). MODEM Use IRQ This determines the IRQ, which can be applied in MODEM use. - Page 24 P4TCA Pro BIOS Setup Resume by Alarm This function is for setting date and time for your computer to boot up. During Disabled, you cannot use this function. During Enabled, Choose the Date and Time. Alarm: Date (of Month) Alarm You can choose which month the system will boot up.
-
Page 25: Pnp/Pci Configurations
P4TCA Pro BIOS Setup 7 PnP/PCI Configurations This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed of the CPU itself uses when communicating with its own special components. This section covers some very technical items and it is strongly recommended that only experienced users should make any changes to the default settings. - Page 26 P4TCA Pro BIOS Setup Resources Controlled By By Choosing “Auto(ESCD)” (default), the system BIOS will detect the system resources and automatically assign the relative IRQ and DMA channel for each peripheral.By Choosing “Manual”, the user will need to assign IRQ & DMA for add-on cards. Be sure that there are no IRQ/DMA and I/O port conflicts.
-
Page 27: Pc Health Status
P4TCA Pro BIOS Setup 8 PC Health Status Figure 8. PC Health Status Shutdown Temperature This item allows you to set up the CPU shutdown Temperature. This item only effective under Windows 98 ACPI mode. The Choices: 60°C/140°C, 65°C/149°F, Disabled (default). - Page 28 P4TCA Pro BIOS Setup Current CPU Temperature Show you the current CPU temperature. Current CPU FAN Speed This field displays the current CPUFAN speed. Current SYS FAN Speed This field displays the current speed SYSTEM fan. Show H/W Monitor in POST If you computer contain a monitoring system, it will show PC health status during POST stage.
-
Page 29: Frequency Control
P4TCA Pro BIOS Setup 9 Frequency Control Figure 9. Frequency Control CPU Clock Ratio The Choices: 8 X(default), 9X, 10X, 11X, 12X, 13X, 14 X, 15X, 16X, 17X, 18X, 19X, 20 X, 21 X, 22 X, 23 X. CPU Voltage This item allows you to select CPU Voltage Regulator. - Page 30 P4TCA Pro BIOS Setup If unfortunately, the system’s frequency that you are selected is not functioning, there are two methods of booting-up the system. Method 1: Clear the COMS data by setting the JCOMS1 ((2-3) closed)) as “ON” status. All the CMOS data will be loaded as defaults setting.
