FCC Statement and Copyright
This equipment has been tested and found to comply with the limits of a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. There is no guarantee that interference will not occur in a
particular installation.
The vendor makes no representations or warranties with respect to the
contents here of and specially disclaims any implied warranties of
merchantability or fitness for any purpose. Further the vendor reserves the
right to revise this publication and to make changes to the contents here of
without obligation to notify any party beforehand.
Duplication of this publication, in part or in whole is not allowed without
first obtaining the vendor's approval in writing.
The content of this user's is subject to be changed without notice and we
will not be responsible for any mistakes found in this user's manual. All the
brand and product names are trademarks of their respective companies.
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P4TGE and is the answer not in the manual?

Questions and answers

Summary of Contents for Biostar P4TGE

  • Page 1 FCC Statement and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 2: Table Of Contents

    Jumpers, Headers, Connectors & Slots ... 7 ESPAÑOL ... 15 Características del P4TGE... 15 Contenido del Paquete... 17 Disposición del P4TGE ... 18 Instalación de la CPU ... 19 Módulos DDR DIMM: DDR1-2 ... 20 Puentes, Cabezales, Conectores y Ranuras... 21 TROUBLE SHOOTING...
  • Page 3: English

    English P4TGE Features Use Intel 845GE/ ICH4 Chipset, Winbond W83627, 1394A Chip, SATA/ RAID Chip (Optional). Contains on board I/O facilities, which include one serial port, one VGA port, a parallel port, a PS/2 mouse port, a PS/2 keyboard port, audio ports, USB ports and a game port .
  • Page 4 Supports SPDIF-Out function. Line-in phone-jack share with rear out . Mic-in phone-jack share with Bass and Center. CMI 8738 Hardware Audio Features (Optional): 6CH DAC for AC3® 5.1CH purpose. HRTF-based 3D positional audio, supporting DirectSound™ 3D and A3D™ interface. Supports 4.1/5.1 speakers, C3DX positional audio in 4/ 6 CH speaker mode.
  • Page 5: Package Contents

    Package contents HDD Cable X 1 FDD Cable X 1 Fully Setup Driver CD X 1 USB Cable X 2 (Optional) IEEE1394 Cable X1 (Optional) Serial ATA Cable X1 (Optional) SPDIF OUT Cable X1 (Optional).
  • Page 6: Layout Of P4Tge

    Layout of P4TGE JKBMS1 & JATXPWR2 Mouse JUSBLAN1 Socket 478 USB & LAN JKBV1 JUSBV1 JCOM1 JPRNT1 JCOM2 JVGA1 JGAME1 JGAME1 LAN Chip AGP SLOT PCI1 PCI SLOT JAUDIO1 Codec PCI2 PCI SLOT PCI3 JCDIN1 PCI SLOT PCI4 JSPDIF_OUT 1...
  • Page 7: Cpu Installation

    CPU Installation Pull the lever sideways away from the socket then raise the lever up to 90-degree angle. Locate Pin A in the socket and lock for the white dot or cut edge in the CPU. Match Pin A with the white dot/cut edge then insert the CPU.
  • Page 8: Ddr Dimm Modules: Ddr1-2

    DDR DIMM Modules: DDR1-2 Supports DDR200/266/333 unregistered 184-pin non-ECC DDR SDRAM DIMMs. Does not support double-size x16 DDR DIMMs. DRAM Type: 64MB/ 128MB/ 256MB/ 512MB/ 1GB DIMM Module (184 pin) DIMM Socket DDR Module Location DDR 1 64MB/128MB/256MB/512MB/1GB DDR 2 64MB/128MB/256MB/512MB/1GB * The list shown above for DRAM configuration is only for reference.
  • Page 9: Jumpers, Headers, Connectors & Slots

    The first hard drive should always be connected to IDE1. Serial ATA Connector: (JSATA1/ JSATA2) (Optional) The motherboard has a PCI to SATA Controller with 2 channels SATA interface, it satisfies the SATA 1.0 spec and can transfer data with 1.5GHz speed.
  • Page 10 3D graphics. Peripheral Component Interconnect Slots: PCI1-5 This motherboard is equipped with 5 standard PCI slots. PCI stands for Peripheral Component Interconnect, and it is a bus standard for expansion cards, which has, supplanted the older ISA bus standard in most ports.
  • Page 11 Front USB Header: JUSB3/ JUSB4 Pin Assignment Pin Assignment Data (-) Data (+) JUSB3/ 4 Ground 5V/ 5VSB Selection for USB: JUSBV1/ JUSBV3_4 JUSBV1/ 3_4 Pin 1-2 on Pin 2-3 on 5V/ 5VSB Selection for KB: JKBV1 JKBV1 Pin 1-2 on Pin 2-3 on Data (-) Data (+)
  • Page 12 Case Open: JCL1 Front 1394 Header: J1394A1/J1394B1/J1394C1 Pin Assignment Pin Assignment Ground J1394A1/B1/C1 +12V Serial ATA Connector: JSATA1/ JSATA2 (Optional) Pin Assignment Pin Assignment Ground JSATA1/2 Ground Digital Audio Connector: JSPDIF_OUT SPDIF_Out JSPDIF_OUT Intruder Ground JCL1 Ground +12V Ground...
  • Page 13 Audio Subsystem: JAUDIO1/ JCDIN1 JAUDIO1 (Front Audio Header) (CD-ROM Audio-In Header) Assignment Mic In Mic Power RT Line Out Reserved LFT Line Out RT Line In LFT Line In Pin 5, 9, 11, 13 are routed to Front Panel Audio Out. Pin 6, 10, 12, 14 are routed from Front Panel Audio Out.
  • Page 14 Front Panel Audio Connector/ Jumper Block Jumper Setting Pin 5 and 6 Audio line out signals are routed Pin 9 and 10 to the back panel audio line out connector. Pin11 and 12 Pin13 and 14 No jumpers Audio line out and mic in signals are installed available for front panel audio connectors.
  • Page 15 Front Panel Connector: JPANEL1 PWR_LED (+) (-) HLED ==> Speaker Conn. HLED ==> Hard Driver LED ==> Reset Button ==> Infrared Conn. ==> Sleep Button PWR_LED ==> Power LED ON/ OFF ==> Power-on Button Back Panel Connectors JKBMS1 JUSBLAN1 JPRNT1 LAN(Optional) PS/2 Mouse...
  • Page 16 4 Ch an nel Speakers Speaker Out Line In/ Speaker Out Mic In Rear Speaker 6 Ch an n el Speakers Line In/ Mic In/ Center & Bass Rear Speaker...
  • Page 17: Español

    Español Características del P4TGE Usa Chipset Intel 845GE/ ICH4, Winbond W83627, Chip 1394A, Chip SATA/ RAID (Opcional). Contiene facilidades I/O integrados en la placa madre en el que incluye un puerto en serie, un puerto VGA, un puerto paralelo, un puerto para ratón PS/2, un puerto para teclado PS/2, puertos de audio, puertos USB y un puerto de juego .
  • Page 18 Alto S/N ratio para requerimientos PC 99. 6CH Audio Codec, aplicable para chipsets de principales placas madres. Soporta función SPDIF_Out. Entrada de Línea phone-jack compartido con el rear out. Micrófono phone-jack compartido con Bass y Center. CMI 8738 Características del Hardware Audio (Opcional): 6CH DAC para AC3®...
  • Page 19: Contenido Del Paquete

    modo 3, 4, 5, 6 de Ultra DMA. Compatible con PC2000, requerimientos WHQL hardware. Contenido del Paquete Cable HDD X 1 Cable FDD X 1 Configuración Completa del Driver CD X 1 Cable USB X 2 (Opcional) Cable IEEE1394 X1 (Opcional) Cable Serial ATA X1 (Opcional) Cable SPDIF OUT X1 (Opcional)
  • Page 20: Disposición Del P4Tge

    Disposición del P4TGE JKBMS1 Teclado & JATXPWR2 Raton JUSBLAN1 Socket 478 USB & LAN JKBV1 JUSBV1 JCOM1 JPRNT1 JCOM2 JVGA1 JGAME1 JGAME1 LAN Chip PCI1 JAUDIO1 Codec PCI2 PCI3 JCDIN1 PCI4 JSPDIF_OUT 1 PCI5 Hardware CNR1 Audio JWOL1 J1394B1 J1394A1...
  • Page 21: Instalación De La Cpu

    Instalación de la CPU Tire de la palanca del lado del zócalo, luego levante la palanca hasta un ángulo de 90 grados. Sitúe el contacto A del zócalo y busque el punto blanco o corte el borde en la CPU. Empareje el contacto A con el punto blanco/ corte del borde, luego inserte la CPU.
  • Page 22: Módulos Ddr Dimm: Ddr1-2

    Módulos DDR DIMM: DDR1-2 Soporta DDR200/266/333 unregistered 184-contactos sin ECC DDR SDRAM DIMMs. No soporta DDR DIMMs x16 de doble cara. DRAM Tipo: 64MB/ 128MB/ 256MB/ 512MB/ 1GB Módulos DIMM (184 contactos) Localización Módulo DDR del Zócalo DIMM DDR 1 64MB/128MB/256MB/512MB/1GB DDR 2 64MB/128MB/256MB/512MB/1GB...
  • Page 23: Puentes, Cabezales, Conectores Y Ranuras

    Puentes, Cabezales, Conectores y Ranuras Conectores del Disco Duro: IDE1/ IDE2 La placa madre tiene un controlador de 32-bit PCI IDE que proporciona Modo PIO 0~4, Bus Master, y funcionalidad Ultra DMA / 33/ 66/ 100. Tiene dos conectores HDD IDE1 (primario) y IDE2 (secundario). El conector IDE puede conectar a un master y un drive esclavo, así...
  • Page 24 Accelerated Graphics Port Slot: AGP1 Su monitor se fijará directamente a la tarjeta de video. Ésta placa madre soporta tarjetas de video para ranuras PCI, y también está equipado con un Puerto Acelerado para Gráficos. Ésta tarjeta AGP tomará ventaja de la tecnología del AGP para el mejoramiento de la eficiencia y funcionamiento del video, especialmente con gráficos 3D.
  • Page 25 Cabezal Frontal USB: JUSB3/ JUSB4 Contactos Asignacion Contactos Asignacion Data (-) Data (+) Tierra 5V/ 5VSB Selección para USB: JUSBV1/ JUSBV3_4 JUSBV1/ 3_4 Pin 1-2 on Pin 2-3 on 5V/ 5VSB Selección para KB: JKBV1 JKBV1 Contactos 1-2 on Contactos 2-3 on JUSB3/ 4 Data (-) Data (+)
  • Page 26 Case Open: JCL1 Cabezal Frontal 1394: J1394A1/J1394B1/J1394C1 Pin Asignacion Pin Asignacion Tierra J1394A1/B1/C1 +12V Conector Serial ATA: JSATA1/ JSATA2 (Opcional) Pin Asignacion Pin Asignacion Ground JSATA1/2 Ground Conector Digital de Audio: JSPDIF_OUT SPDIF_Out JSPDIF_OUT Intruder Tierra JCL1 Tierra +12V Ground...
  • Page 27 Subsistema de Audio: JAUDIO1/ JCDIN1 JAUDIO1 JAUDIO1 (Cabezal de Audio Frontal) (Front Audio Header) Contactos Asignacion Entrada del MIC Corriente del MIC RT Salida de Linea Reservado LFT Salida de Linea RT Entrada de Linea LFT Entrada de Linea Contactos 5, 9, 11, 13 son encaminados a la Salida de Audio del Panel Frontal.
  • Page 28 Front Panel Audio Connector/ Jumper Block Jumper Setting Pin 5 and 6 Audio line out signals are routed Pin 9 and 10 to the back panel audio line out connector. Pin11 and 12 Pin13 and 14 No jumpers Audio line out and mic in signals are installed available for front panel audio connectors.
  • Page 29 Conector del Panel Frontal: JPANEL1 PWR_LED (+) (-) HLED ==> Conector de Altavoz HLED ==> LED del Disco Duro ==> Boton de Reinicio ==> Conector Infrarojo ==> Boton de Suspension PWR_LED ==> Corriente LED ON/ OFF ==> Boton de Encendido Conectores del Panel Trasero JKBMS1 JUSBLAN1...
  • Page 30 Altavoz de 4 Canales Salida del Altavoz Entrada de Entrada Salida del Linea/ del Mic Altavoz Rear Speaker Altavoz de 6 Canales Entrada Entrada del Mic/ de Linea/ Center & Bass Rear Speaker...
  • Page 31: Trouble Shooting

    Trouble Shooting PROBABLE CAUSE No power to the system at all Power light don’t illuminate, fan inside power supply does not turn on. Indicator light on keyboard does not turn on PROBABLE CAUSE System inoperative. Keyboard lights are on, power indicator lights are lit, hard drive is spinning.
  • Page 32: Solución De Problemas

    Solución de Problemas CAUSA PROBABLE No hay corriente en el sistema. La luz de corriente no ilumina, ventilador dentro de la fuente de alimentación apagada. Indicador de luz del teclado apagado. CAUSA PROBABLE Sistema inoperativo. Luz del teclado encendido, luz de indicador de corriente iluminado, disco rígido está...
  • Page 33 12/13/2002...
