2. Connector References
Reference
Designation Description
SIM1
CN1 DOCKING I
CN2
CN3
CN4 DOCKING II
CN5 SATA PORT
CN6 SATA POWER
CN8
AAEON Technology Inc.
Connector Index
Functional
SIM CARD (TF)Micro SIM Socket.8P.SMD.Hinge Type.REGO.80440GIH-081T-12CL
Connector.100P.180D(F).SMD.Pitch=0.5mm.H=6.05mm.Panasonic.AXK5S0034
(TF)USB3.0 Connector.Single Port.Type A.9P.90D(F).SMD.Trontek.930-00406-
USB3.0
MINI PCIE
(TF)MiniCard SLOT.52P.90D.(F).SMD.FOXCONN.AS0B226-S68Q-7H
Connector.100P.180D(F).SMD.Pitch=0.5mm.H=6.05mm.Panasonic.AXK5S0034
(TF)SATA CONNECTOR.7P.180D(M).SMT.TechBest.007-01-00757
(TF)WAFER BOX.2P.180D(M).DIP.2.0mm.w/LOCK.PINREX.721-81-02TW00
(TF)Wafer Box.10P.90D(M).SMD.1.0mm.PINREX.710-74-10TWR6
Expend IO
Connector Type
(TF)Board-Board
7YG
A91-22
(TF)Board-Board
7YG
