digiDL-E for Front Port Download Only - Installation
digiDL-E for Use in Front Port Download - VDO Tachographs Only
When you connect a digiDL-E to digiConnect in order to setup the device the
settings are broader than for the standard digDL.
Please use digiConnect to set the "Sources" to K-Line for front port download
as below. See page 16 onwards for all other software settings for both the
digiDL-B / BT and the digiDL-E versions.
N.B. the settings screen below is speci c to the digiDL-E version and will not
appear when you con gure a digiDL-B or BT.
DigiDL-B / BT Installation Guide
digiDL-E for Use in Front Port Download - VDO Tachographs Only
The con guration software view for the digiDL-E is slightly di erent to the
digiDL-B or BT as there is additional functionality. If you are using the
digiDL-E for Front Port download on a VDO Tachograph then you need only be
concerned with the additional 'Sources' section (see below and Page 14).
Please ensure that the K-Line option is Ticked ON under Features ( Fig 6. below).
If you are interested in the other features of the digiDL-E then refer to the
digiDL-E and digiDL-EX User Guide or visit www.tachosys.com.
Fig 6.
Page - 14 DigiDL-B / BT Installation Guide
digiDL-E for Front Port Download Only - Installation
Page - 15
