Tachosys digiDL-B Administration Manual page 10

digiConnect Windows® Software
Con gure Device - Device Con guration Window
1. Firmware Version of rmware on device
2. Serial Number Unique to each device.
3. PWD Used as a means of security between the
device and the digiCentral server.
4. Build Date Date and time of when device was built
5. Connectivity Will be via Modem for digiDL-B / BT
6. Module Module type
Please note that PWD (password) is a unique string which is used by your
service provider or on your own digiCentral for initial registration of the device.
It avoids communication by random devices with digiCentral. Coupled with
our encryption it provides added security.
DigiDL-B / BT Installation Guide
Con gure Device - Network - GPRS
Fig 8.
Fig 9. shows the GPRS settings for digiDL-B / BT.
1. For the GPRS network settings, navigate to the 'Mobile Network' tree
view. Enter the APN, User and Password appropriate to your service
provider. Many of the standard APN settings can be found online.
2. If your SIM has a PIN enter it in the PIN eld.
3. Click the 'Apply' or 'OK' button to save the settings.
4. In the 'digiCentral Server' tree view enter the Host name or IP address of
your digiCentral server. This will either be provided by your analysis
provider or will match your own digiCentral server settings. The PORT
Number should be left as 4616 unless you are hosting your own
digiCentral server and have changed the default PORT.
5. If your GPRS settings and Hostname are correct and the device is correctly
registered on digicentral then the "W" BLUE LED should shine solid blue
on the digiDL-B.
Please note that if the BLUE LED is not solid then you do not have connection to
the server and you should call the provider you are trying to connect to. A slow
ashing Blue LED indicates no connection to GPRS a faster ash at around twice
per second indicates that the device is not registered on a digicentral server or
your digicentral server settings are incorrect.
Page - 18 DigiDL-B / BT Installation Guide
Fig 9.
Page - 19
