Broan Elite 15XeBl Specification Sheet

15-INCH wIDE, XE SERIES,
AuTOMATIC
TRASH COMPACTOR
FEATuRES
• 3000 lbs. of continual compaction force.
• ¾ horsepower motor drives dual screw compaction system.
• Dedicated 15 Amp circuit recommended.
• Six (6) to one (1) compaction ratio. Compact the equivalent
of six (6) 13 gallon trash containers into one bag.
• Programmable compaction cycle for automatic compaction.
• Battery backup prevents loss of electronic settings in the
event of power interruption.
• Stainless steel compacting plate with Microban
antimicrobial protective coating designed to crush cans and
bottles.
• 1.55 cubic foot bucket trash bucket holds 30 lbs. of trash.
• Trash bucket has drop down door for easy trash removal.
• Full extension ball bearing trash bucket drawer slides for
smooth action.
• Start button with ram status LED.
• Removable key switch prevents unauthorized compaction.
• Safety interlock prevents compaction when door is open.
• Bag storage compartment. Unit comes with three (3) bags.
• Automatic advance odor control system with disk
replacement indicator. First six (6) month disk provided
with trash compactor.
• Insulated door with magnetic gasket for quiet cycling and
odor control.
• Reversible doors with 170° range of motion offered in
different finishes.
- Model 15XEBL - Black door and trim
- Model 15XEWH - White door and trim
- Model 15XESS - Stainless steel door and stainless-look trim
- Model 15XESSA - Arched stainless steel door and
stainless-look trim
- Model 15XEWT - Wood door kit with stainless-look trim
- Model 15XETT - Tile door kit with stainless-look trim
• Textured cabinet features a durable baked epoxy finish in
black (all models).
• Two (2) adjustable height leveling legs (front) and two
(2) adjustable height rollers (rear) provide one (1) inch of
height adjustment.
*Microban is a
registered trademark
Broan-NuTone LLC
of the Microban
Broan-NuTone Canada
Products Company.
REFERENCE QTY.
ACCESSORIES (purchased separately)
• Model 15TCTK - Toe kick kit (required for freestanding
installations).
• Model 15TCBL – Sixty (60) trash bags (black).
• Model 15TCOD – Set of ten (10) odor control disks.
Each disk lasts up to six (6) months.
• Model 15TCBB – Hardwood cutting board (rests on top
of compactor when not installed under a counter top).
*
®
SPECIFICATIONS
Volts
120
(not including handle)
* Model 15XESSA = 22¼
Hartford, Wisconsin www.broan.com
Mississauga, Ontario www.broan.ca
REMARKS
SPECIFICATION SHEET
Hz AMPS Capacity
1.55 ft
3
60 5.0
30 lbs.
21½ *
(all models except
15XESSA)
14
800-558-1711
877-896-1119
Project
Location
Architect
Engineer
Contractor
Submitted by
80J
Compaction Weight
165 lbs
3000 lbs
(pack-
6 to 1
aged)
34 ⁄
MIN.
1
8
⁄
7
8
Date
99044472A
