FCC Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
Any changes or modification made to this equipment void the user's authority to operate this
equipment.
This equipment generates, uses, and radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
* Reorient or relocate the receiving antenna.
* Increase the separation between the equipment and receiver.
* Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
* Consult the dealer or an experienced radio/TV technician for help.
* All external cables connecting to this basic unit must be shielded.
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital
apparatus as set out in the radio interference regulations or the Canadian Department of Communications.
This equipment is in conformity with the EMC directive.
C. D. C. Statement
C. D. C. Statement
C. D. C. Statement
C. D. C. Statement
C. D. C. Statement
CE Mark
CE Mark
CE Mark
CE Mark
CE Mark
BIOSTAR Motherboard
1 1 1 1 1
English
English
English
English
English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the K8NBP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Biostar K8NBP

  • Page 1: Fcc Statement

    Canadian Department of Communications. This equipment is in conformity with the EMC directive. CE Mark CE Mark CE Mark CE Mark CE Mark BIOSTAR Motherboard 1 1 1 1 1 English English English English English...
  • Page 2: Overview

    BIOSTAR Motherboard The information in this document is subject to change without notice and should not be construed as a commitment by the manufacturer. The manufacturer assumes no responsibility for any errors that might appear in this document. The software described in this document is furnished under a license and may be used or copied only in accordance with the terms of such license.
  • Page 3: Important Safety Information

    The equipment has not work well or you can not get it work according to user‘s manual. e. The equipment has dropped and damaged. f. If the equipment has obvious sign of breakage BIOSTAR Motherboard 3 3 3 3 3 English...
  • Page 4: Table Of Contents

    Section 2 Motherboard Set Up... 9 Section 2 Motherboard Set Up... 9 2.1 Layout And Components Index ... 10 2.2 Component Index ... 11 2.3 K8NBP Motherboard Features ... 12 2.4 Installation and Setup ... 16 Section 3 P Section 3 Peripheral Connection... 25...
  • Page 5 BIOSTAR Motherboard 5 5 5 5 5 English English English English English...
  • Page 6: Begin Your Tour In The Diy World

    BIOSTAR Motherboard Begin Your Tour In The DIY World Begin Your Tour In The DIY World Begin Your Tour In The DIY World Begin Your Tour In The DIY World Begin Your Tour In The DIY World Congratulations on purchasing this cutting-edge Small Form Factor...
  • Page 7: Checking The Equipments

    * Installation guide * Screws pack * Power cable for Serial-ATA hard disk drive * Driver CD * StudioFun CD * Thermal grease * A power cord * Serial-ATA cable BIOSTAR Motherboard 7 7 7 7 7 English English English English English...
  • Page 8 BIOSTAR Motherboard 8 8 8 8 8 English English English English English...
  • Page 9 BIOSTAR Motherboard 9 9 9 9 9 English English English English English...
  • Page 10: Layout And Components Index

    BIOSTAR Motherboard Layout And Components Index Layout And Components Index Layout And Components Index Layout And Components Index Layout And Components Index PCI1 AGP1 Wireless LAN Chip SATA Chip SATA1 SATA2 NOTE: “ ” represents the first pin. 10 10 10 10 10...
  • Page 11: Component Index

    AGP1: Accelerated Graphics Port Slot JUSBV2: Power Source Selection for USB JKBMSV1: Power Source Selection for Keyboard and Mouse U30: Wireless LAN Slot JSATA1-2: Serial ATA Header JCOM2: COM2 Header BIOSTAR Motherboard 11 11 11 11 11 English English English English...
  • Page 12: K8Nbp Motherboard Features

    BIOSTAR Motherboard K8NBP Motherboard Features K8NBP Motherboard Features K8NBP Motherboard Features K8NBP Motherboard Features K8NBP Motherboard Features In this section, you shall find all the information about the In this section, you shall find all the information about the In this section, you shall find all the information about the...
  • Page 13: Main Memory

    * Supports remote wake-up in both ACPI and APM environments. * Keeps network maintenance costs low and eliminates usage barriers. * Uses one RF card for Wireless LAN. l a t (optional) BIOSTAR Motherboard e z i 13 13 13 13 13 English English...
  • Page 14 BIOSTAR Motherboard Serial ATA/RAID * Chips: VT6420/VT6410 * Supports RAID 0, 1, 0+1. * Supports 2 Serial ATA (SATA) ports. - Compliant with SATA 1.0 specification. - Data transfer rates up to 150 Mb/s. On Board AC’ 97 Sound Codec * Chip: ALC650.
  • Page 15: Bios & Software

    * Supports Warpspeeder , 9th Touch (optional) * Offers the highest performance for Windows 98 SE, Windows 2000, Windows Me, Windows XP, Linux, SCO UNIX, etc. BIOSTAR Motherboard , FLASHER , Watchdog , WinFlasher and StudioFun! 15 15 15 15 15...
  • Page 16: Installation And Setup

    BIOSTAR Motherboard Installation and Setup Installation and Setup Installation and Setup Installation and Setup Installation and Setup In this section, you will learn how to install the CPU, DDR Module, In this section, you will learn how to install the CPU, DDR Module,...
  • Page 17: Installing Ddr Module

    “close”. If no jumper cap is placed on the pins, the jumper is ”open”. The illustration shows a 3-pin jumper whose pin1and 2 are “close” when jumper cap is placed on these 2 pins. Jumper open Jumper close Pin1-2 close BIOSTAR Motherboard 17 17 17 17 17 English English English...
  • Page 18: Jumpers, Headers, Connectors & Slots

    BIOSTAR Motherboard 5. Jumpers, Headers, Connectors & Slots: (1) Floppy Disk Connector: FDD1 (1) Floppy Disk Connector: FDD1 (1) Floppy Disk Connector: FDD1 (1) Floppy Disk Connector: FDD1 (1) Floppy Disk Connector: FDD1 The motherboard provides a standard floppy disk connector that supports 360K, 720K, 1.2M, 1.44M and 2.88M floppy disk types.
  • Page 19 JUSBV3" jumper caps should be placed on pin 2-3 respectively. +5V(fused) USBP5- USBP5+ Ground Description JUSBV1: for JUSB3/4 ports JUSBV2: for JRJ45 port. JUSBV3: for JUSB1/2 headers. 5V standby to power on. BIOSTAR Motherboard 19 19 19 19 19 English English English English English...
  • Page 20 BIOSTAR Motherboard (10) Wake On LAN Header: JWOL1 (10) Wake On LAN Header: JWOL1 (10) Wake On LAN Header: JWOL1 (10) Wake On LAN Header: JWOL1 (10) Wake On LAN Header: JWOL1 This connector allows you to connect to a LAN card with Wake On LAN function. You can wake up the computer by remote control through a local area network.
  • Page 21 Power LED (+) Power LED (-) Power Button Ground Ground IRRX Assignment +3.3V -12V Ground PS_ON Ground Ground Ground Assignment Ground Ground BIOSTAR Motherboard SleepButton POWER LED Power-on Button IrDA Connector 21 21 21 21 21 English English English English English...
  • Page 22 BIOSTAR Motherboard (11) Back Panel Connectors (11) Back Panel Connectors (11) Back Panel Connectors (11) Back Panel Connectors (11) Back Panel Connectors JAUDIO Line In Speaker Out Mic In 6 Channel Speakers Speaker Out English English English English English PS/2...
  • Page 23 BIOSTAR Motherboard 23 23 23 23 23 English English English English English...
  • Page 24 BIOSTAR Motherboard English English English English English...
  • Page 25: Overview

    Front Panel Connectors Back Panel Connectors BIOSTAR Motherboard figure 3.1 figure3.2 25 25 25 25 25 English...
  • Page 26: Connecting Peripheral Devices

    BIOSTAR Motherboard 3.2 Connecting Peripheral Devices 3.2 Connecting Peripheral Devices 3.2 Connecting Peripheral Devices 3.2 Connecting Peripheral Devices 3.2 Connecting Peripheral Devices Before you connect any peripherals, observe the following instructions. Before you connect any peripherals, observe the following instructions.
  • Page 27: Connecting Monitor

    PS/2 port located on the rear panel of your computer). * Plug the keyboard cable into the black USB port (if your keyboard uses the PS/2 connector, plug the cable into the purple PS/2 port located on the rear panel of your computer). BIOSTAR Motherboard figure3.3 figure3.4...
  • Page 28: Connecting Usb Devices

    BIOSTAR Motherboard Connecting USB Devices Your computer is equipped with four standard USB 2.0 ports as the figure 3.5 shown. The USB 2.0 connector is backward compatible with the USB1.1. You can obtain USB-compatible devices such as USB mouse, USB keyboard, digital camera, scanner, flash disk...etc.
  • Page 29: Connecting Ieee1394 Devices

    Your computer is equipped with the following audio ports, which offer wide-range applications. * SPDIF (Sony/Philips Digital Interface) jack: SPDIF is a standard audio transfer file format, which provides digital audio instead of analog audio through optical fiber. BIOSTAR Motherboard figure3.6 29 29 29 29 29...
  • Page 30 BIOSTAR Motherboard * "Headphone" jack: Use this jack to connect stereo headphone or amplified speakers to your computer. * "Microphone" jack: Use this jack to connect microphone. * "Line-in" jack: Use this jack to enjoy stereo audio from the external source such as CD/Tape player and other audio appliance.
  • Page 31: Connecting Printer

    * The LAN jack is located on the back of your LCD-PC. * Plug an RJ-45 network cable in the LAN jack. * The other end should be connected to a network hub or switch, or to a peer computer. BIOSTAR Motherboard 31 31 31 31 31 English...
  • Page 32 BIOSTAR Motherboard 32 32 32 32 32 English English English English English...
  • Page 33: Installing Drivers And Utilities

    5. The utility will start a page with the drivers you may need. 6. Click on the driver you want to install. 7. The utility will invoke other applications to complete the rest of installation. BIOSTAR Motherboard Figure 4.1 33 33 33 33 33...
  • Page 34: Installing Utilities

    BIOSTAR Motherboard 8. Follow the installing instructions to finish the installation. 9. Click on the next driver you want to install. 10. Repeat steps 6 to 8 until you have installed all the drivers the utility has for you. * If the Driver and utility installation CD does not auto run, please follow the next steps after you place the CD into the optical drive.
  • Page 35 BIOSTAR Motherboard 35 35 35 35 35 English English English English English...
  • Page 36 BIOSTAR Motherboard 36 36 36 36 36 English English English English English...
  • Page 37: System Does Not Start

    * If the monitor is powered on and known to be working, there may be a problem with the computer main circuit board. Contact your computer dealer for technical support and service. BIOSTAR Motherboard 37 37 37 37 37 English...
  • Page 38: Keyboard And Mouse Problems

    BIOSTAR Motherboard 5.2 Keyboard and Mouse Problems 5.2 Keyboard and Mouse Problems 5.2 Keyboard and Mouse Problems 5.2 Keyboard and Mouse Problems 5.2 Keyboard and Mouse Problems * Keyboard doesn't take input, but mouse pointer moves when mouse is moved: * Make sure the keyboard, mouse or receiver is connected when you start the computer.
  • Page 39: Usb Devices Problems

    * Force the device to configure by unplugging and then plugging it back in. * Use a complete shutdown (hold the power button for four seconds) whenever you stop the system. This forces all devices to be reconfigured the next time the system starts. BIOSTAR Motherboard 39 39 39 39 39 English...
  • Page 40: Software Problems

    BIOSTAR Motherboard 5.4 Software Problem 5.4 Software Problem 5.4 Software Problem 5.4 Software Problem 5.4 Software Problem Good software is tested thoroughly before you receive it. However, software Good software is tested thoroughly before you receive it. However, software Good software is tested thoroughly before you receive it. However, software Good software is tested thoroughly before you receive it.
  • Page 41 BIOSTAR Motherboard 41 41 41 41 41 English English English English English...
  • Page 42 BIOSTAR Motherboard English English English English English...
  • Page 43: General Maintenance

    * When you disconnect cords, remember to pull them by the plugs and not by the cords themselves. This will prevent damage to the cords, plugs, ports, and jacks. * Maintain your OS environment by doing scan disk, virus scan, and defragment regularly. BIOSTAR Motherboard 43 43 43 43 43 English...
  • Page 44: Safe Use Of The System

    BIOSTAR Motherboard 6.2 Safe Use of The System 6.2 Safe Use of The System 6.2 Safe Use of The System 6.2 Safe Use of The System 6.2 Safe Use of The System To ensure that you can use your computer safety and cor- rectly and increase the working lifetime of your computer, please read the following instructions.
  • Page 45 BIOSTAR Motherboard 45 45 45 45 45 English English English English English...
  • Page 46 BIOSTAR Motherboard 46 46 46 46 English English English English English...
  • Page 47 A.2. Press the quick joint hooks to remove the front panel bezel. * Use the screwdriver to remove the two screws on the base of chassis. BIOSTAR Motherboard Figure A.1 Figure A.3 47 47 English...
  • Page 48: Installing Mainboard

    BIOSTAR Motherboard * Then use the screwdriver to remove the two screws on the top of front cover panel. Installing Mainboard * Insert the mainboard into the base of the chassis and place it close to the back panel. * After fixing the mainboard on the base of the...
  • Page 49 * Connect the cable of system fan to "JSFAN1" connector on the mainboard. * Connect the cable to the floppy, CD-ROM and HDD. * Place the CD-ROM bracket and and fix it with 2 screws. BIOSTAR Motherboard Figure A.7 Figure A.8 Figure A.9 Figure A.10...
  • Page 50 * Note: The figures show the locations of the connectors on P4SBA motherboard. Please refer to section 2, the Motherboard layout of K8NBP for the correct locations of the connectors. 50 50 50 50 50...
