FCC Statement

This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
Any changes or modification made to this equipment void the user's authority
to operate this equipment.
This equipment generates, uses, and radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
* Reorient or relocate the receiving antenna.
* Increase the separation between the equipment and receiver.
* Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
* Consult the dealer or an experienced radio/TV technician for help.
* All external cables connecting to this basic unit must be shielded.
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus as set out in the radio interference regulations or the Canadian
Department of Communications.
This equipment is in conformity with the EMC directive.
C. D. C. Statement
CE Mark
BIOSTAR Motherboard
1 1 1 1 1
English
English
English
English
English

Advertisement

Table of Contents
loading

Related Manuals for Biostar K8NHA-M

Summary of Contents for Biostar K8NHA-M

  • Page 1: Fcc Statement

    BIOSTAR Motherboard FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 2: Overview

    BIOSTAR Motherboard Overview The information in this document is subject to change without notice and should not be construed as a commitment by the manufacturer. The manufacturer assumes no responsibility for any errors that might appear in this document. The software described in this document is furnished under a license and may be used or copied only in accordance with the terms of such license.

  • Page 3: Important Safety Information

    BIOSTAR Motherboard Important Safety Information Please read these safety instructions carefully. Please keep this User’s Manual for later reference. Please disconnect this equipment from AC outlet before cleaning. Don‘t use liquid or sprayed detergent for cleaning. Use moisture sheet or clothe for cleaning.

  • Page 4: Table Of Contents

    BIOSTAR Motherboard Table of Contents FCC Statement ..........1 Overview ............2 Section 1. Layout of K8NHA-M ....5 Section 2. Component Index ...... 6 Section 3. K8NHA-M Features ....7 Section 4. Package contents ...... 10 Section 5. Installation and Setup .... 11 Section 6.

  • Page 5: Section 1. Layout Of K8Nha-M

    BIOSTAR Motherboard ection 1. Layout of K8NHA-M JCFAN1 JKBMS1 DDR1 JKBMSV1 JUSBV1 Super I/O IT 8712F J1394_USB1 CPU1 Socket 754 FDD1 JCOM1 JCOM3 JATXPWR2 JCOM2 JUSBLAN1 J1394A1 JSFAN2 JUSBV2 JAUDIO BIOS JSATA2 JSATA3 RTL8201BL JSPDIF_OUT IDE2 IDE1 JSPDIF_IN JAUDIO1 JCDIN2...

  • Page 6: Section 2. Component Index

    BIOSTAR Motherboard ection 2. Component Index This section helps you to locate the components in the motherboard and to find the details about them easily according to the mentioned pages. Super I/O IT 8712F CPU1 Socket 754 RTL8201BL NVIDIA CK 8...

  • Page 7: Section 3. K8Nha-M Features

    BIOSTAR Motherboard ection 3. K8NHA-M Features In this section, you shall find all the information about the motherboard in your computer, including its features, layout, component index, various jumpers, headers, connectors, and also the installation guide to help you a quick and correct installation of your system.
  • Page 8 BIOSTAR Motherboard Main Memory Main Memory Main Memory Main Memory Main Memory * Supports up to two DDR devices. * Supports 200/266/333/400MHz (with ECC) DDR devices. * Maximum memory size is 2GB. Total Memory Size with Unbuffered DIMMs l a t...
  • Page 9 BIOSTAR Motherboard On Board AC On Board AC 97 Sound Codec 97 Sound Codec On Board AC On Board AC On Board AC’97 Sound Codec 97 Sound Codec 97 Sound Codec * Chip: ALC655/CMI9761. * Compliant with AC’97 specification. * AC’97 2.2 interface.

  • Page 10: Section 4. Package Contents

    BIOSTAR Motherboard ection 4. Package contents Check what you have bought before you start your DIY action. If there are anything missing, please contact your dealer immediately. * HDD Cable X 1 * FDD Cable X 1 * User's Manual X1 * USB 2.0 Cable X1 (optional)

  • Page 11: Section 5. Installation And Setup

    BIOSTAR Motherboard ection 5. Installation and Setup In this section, you will learn how to install the CPU, DDR Module, and also how to set up jumpers and all the information about the components on the motherboard. Not only can you find the installation steps, but also the details and locations of the components on the motherboard.
  • Page 12 BIOSTAR Motherboard (2) System Fan Headers: JSFAN1/JSFAN2 Assignment Ground +12V FAN RPM Sense 3. Installing DDR Module 3. Installing DDR Module 3. Installing DDR Module 3. Installing DDR Module 3. Installing DDR Module 1. Unlock a DIMM slot by pressing the retaining clips outward.
  • Page 13 BIOSTAR Motherboard (2) Hard Disk Connectors: IDE1/ IDE2 The motherboard has a 32-bit Enhanced PCI IDE Controller that provides PIO Mode 0~4, Bus Master, and Ultra DMA 33/ 66/ 100/ 133 functionality. It has two HDD connectors IDE1 (primary) and IDE2 (secondary).
  • Page 14 BIOSTAR Motherboard (8) Wake On LAN Header: JWOL1 (optional) This connector allows you to connect to a LAN card with Wake On LAN function. You can wake up the computer by remote control through a local area network. Pin Assignment...
  • Page 15 BIOSTAR Motherboard (12) CD-ROM Audio-In Header: JCDIN1/JCDIN2 This header allows you to receive stereo audio input from sound sources, such as CD-ROM, TV Tuner, MPEG card, etc. Pin Assignment Left Channel Input Ground JCDIN1/JCDIN2 Ground Right Channel Input (13) Game Header: JGAME1 (optional)
  • Page 16 BIOSTAR Motherboard (15) 5V / 5VSB Selection for KB: JKBMSV1 (optional) JKBMSV1 Assignment Description Pin 1-2 close +5V 5V for keyboard and mouse Pin 2-3 close +5V_SB 5V standby for keyboard and mouse to power on your system (16) Power Connectors: JATXPWER1/ JATXPWR2 The motherboard supports ATX power supply for the power system.
  • Page 17 BIOSTAR Motherboard (18) Digital Audio Connector: JSPDIF_OUT/ (JSPDIF_IN: optional) The connector is used to connect SPDIF (Sony & Philips Digital Interconnect Format) interface for digital audio transmission. Pin Assignment SPDIF_OUT Ground (19) Front Panel Audio Header: JAUDIO1 The connector allows you to connect to the front panel audio.
  • Page 18 BIOSTAR Motherboard (22) COM3 Header: JCOM3 (optional) Pin Assignment Pin Assignment RIN1 RIN3 DOUT2 ROUT3 Ground RIN2 DOUT1 RIN4 -XRI1 (23) Back Panel Connectors 6 Channel Speakers Line In/ Rear Speaker Speaker Out Mic In/ Center & Bass 18 18 18 18 18...

  • Page 19: Section 6. Trouble Shooting

    BIOSTAR Motherboard ection 6. Trouble Shooting SOLUTION PROBABLE * Make sure power cable is securely No power to the system at all; power light plugged in.* Replace cable. doesn't illuminate; fan inside power supply * Contact technical support. does not turn on. Indicator light on keyboard does not turn on.
  • Page 20 BIOSTAR Motherboard SOLUTION PROBABLE * Check the power connectors to monitor Scree is blank. and to system. Make sure monitor is connected to display card. Screen goes blank periodically. * Disable screen saver. * Reboot computer. Reinstall memory, Memory problem.

  • Page 21: Warpspeeder

    BIOSTAR Motherboard arpSpeeder Introduction [ WarpSpeeder ], a new powerful control utility, features three user-friendly functions including Overclock Manager, Overvoltage Manager, and Hardware Monitor. With the Overclock Manager, users can easily adjust the frequency they prefer or they can get the best CPU performance with just one click. The Overvoltage Manager, on the other hand, helps to power up CPU core voltage and Memory voltage.
  • Page 22 BIOSTAR Motherboard 2. When you see the following dialog in setup procedure, it means setup is completed. If the "Launch the WarpSpeeder Tray Utility" checkbox is checked, the Tray Icon utility and [WarpSpeeder ] utility will be automatically and immediately launched after you click "Finish" button.
  • Page 23 BIOSTAR Motherboard Usage The following figures are just only for reference, the screen printed in this user manual will change according to your motherboard on hand. [WarpSpeeder ] includes 1 tray icon and 5 panels: 1. Tray Icon: Whenever the Tray Icon utility is launched, it will display a little tray icon on the right side of Windows Taskbar.
  • Page 24 BIOSTAR Motherboard c. With a user-friendly Status Animation, it can represent 3 overclock percentage stages: Duck walking => overclock percentage from 100% ~ 110 % Duck running => overclock percentage from 110% ~ 120% Duck burning => overclock percentage from 120% ~ above 3.
  • Page 25 BIOSTAR Motherboard 4. Overclock Panel Click the Overclock button in Main Panel, the button will be highlighted and the Overclock Panel will slide out to left as the following figure. Overclock Panel contains these features: 25 25 25 25 25...
  • Page 26 BIOSTAR Motherboard a. "-3MHz button", "-1MHz button", "+1MHz button", and "+3MHz button": provide user the ability to do real-time overclock adjustment. Warning: Manually overclock is potentially dangerous, especially when the overclocking percentage is over 110 %. We strongly recommend you verify every speed you overclock by click the Verify button.
  • Page 27 BIOSTAR Motherboard 5. Hardware Monitor Panel Click the Hardware Monitor button in Main Panel, the button will be high- lighted and the Hardware Monitor panel will slide out to left as the following figure. In this panel, you can get the real-time status information of your system. The information will be refreshed every 1 second.
  • Page 28 BIOSTAR Motherboard Note: Because the overclock, overvoltage, and hardware monitor features are controlled by several separate chipset, [ WarpSpeeder ] divide these features to separate panels. If one chipset is not on board, the correlative button in Main panel will be disabled, but will not interfere other panels' functions. This property can make [ WarpSpeeder ] utility more robust.
