Summary of Contents for Foamit FI-BP-15N
- Page 1 USER MANUAL MODEL NUMBER: FI-BP-15N FI-BP-15NK FI-BP-15NV AND RELATED UNITS 15 Gallon Battery-Powered Portable Foam Unit English (Original Instructions)
-
Page 2: Protect The Environment
• Always depressurize unit after use (as described in the After Use Instructions). Always store unit depressurized, with the discharge trigger gun or ball valve in the closed position. • Do not exceed a fluid temperature of 100˚F (37˚C). • Always flush the unit with fresh water for 5 minutes when switching from an alkaline to an acid or an acid to an alkaline. • To prevent premature battery failure, do not store battery in a depleted state for long periods of time. Do not recharge battery until it has been used to power the unit for a minimum of 30 minutes of use. PROTECT THE ENVIRONMENT Please dispose of packaging materials, old machine components, and hazardous fluids in an environmentally safe way according to local waste disposal regulations. Always remember to recycle. *Specifications and parts are subject to change without notice. Model Number: FI-BP-15N, FI-BP-15NK, FI-BP-15NV AND RELATED UNITS Page 2 of 10 | 20180626... -
Page 3: Specifications
SPECIFICATIONS Power type Battery Battery charge time (from full depletion) 7.5 hours Battery run time (from full charge) Up to 2 hours of non-continuous run time Chemical pickup type Draws from pre-mixed solution Number of products unit can draw from One product Suction line diameter 3/8 in. (9.5 mm) inside diameter Capacity 15 gallons (56.78 liters) Discharge hose diameter/length 15 ft. (4.6 m) hose, with 1/2 in. (12.7 mm) inside diameter Discharge wand/tip type Stainless steel wand with 650 fan tip and ball valve Output distance 5-6 ft. (1.52-1.83 m) Output volume 4-5 gal/min (15-18.93 l/min) of foam Flow rate* 2 gal/min (7.6 l/min) Pump seals Santoprene, Viton, or Kalrez Wheel type Two 10 inch non-marking wheels *Dilution rates and flow rates given are based on chemical with viscosity of water and factory air pressure settings. Model Number: FI-BP-15N, FI-BP-15NK, FI-BP-15NV AND RELATED UNITS Page 3 of 10 | 20180626... -
Page 4: Battery Instructions
To charge battery: Use Instructions” above. Always disconnect the battery before 1. Verify that the power button (PBS-12V) is in the OFF opening the unit back plate. position. • Inspect the air pump (P56/P56K/P56V) for wear and leaks. 2. Plug the charger into a GFCI protected 110 VAC power outlet. • Inspect all hoses for leaks or excessive wear. Make sure all hose clamps are in good condition and properly 3. Plug the charger (BC12V-NC72) into the charging port secured. (BCP12V). NOTE: The charger will begin in standby mode, indicated by an orange LED. In standby mode, the charger • Check the suction line and strainer (STR38-IL) for debris or is not providing any power. blockages, and clean as needed. 4. Press MODE button on charger until correct mode is selected. Blue LED under 12V Cold is the correct mode. Model Number: FI-BP-15N, FI-BP-15NK, FI-BP-15NV AND RELATED UNITS Page 4 of 10 | 20180626... -
Page 5: Troubleshooting Instructions
• Bad control relay • Replace control relay (LVRC-12V-40F) Power switch light is on but • Unit overheating from extended use • Turn unit off and let cool at least 1 hour unit is not running (when it has previously been operating) • Bad battery • Replace battery (BSLA-12V55) Battery will not completely charge • Bad charger • Replace charger (BC12V-NC72) or charing port (BCP12V) • Battery was stored in depleted state • Replace battery (BSLA-12V55) for long periods of time Battery discharges too • Battery has reached life expectancy • Replace battery (BSLA-12V55) quickly • Battery was charged and run for short • Replace battery (BSLA-12V55) periods of time (not allowed to fully charge or discharge) Model Number: FI-BP-15N, FI-BP-15NK, FI-BP-15NV AND RELATED UNITS Page 5 of 10 | 20180626... - Page 6 WAND ASSEMBLY DISCHARGE HOSE ITEM NUMBER: SSWA-BP ITEM NUMBER: H12-15HBR H12B-F ST6540SS (Available per ft.) HHSB1214 SC1212 SSN126 MIX7-WAND (Located inside SSN126) HV60 HBSS1212 HBSS1212 F12SS HBR12 Model Number: FI-BP-15N, FI-BP-15NK, FI-BP-15NV AND RELATED UNITS Page 6 of 10 | 20180626...
- Page 7 P56, P56V, or P56K HHSB1418 HBB103217 HBB103217W CR14B PS14QF-55 HBB1414 EC14-2 H14B-F SSC38 H38B-F CV14QF AC12V-CL HBSS1238 BEL18M14F SST12 AS1-V HHSB1214 EC18 HBBEL1417 AC12V-14HP SSC2.8-3.8 FU40-ATO SH-12V-40F PSH-12V-40F LVRC-12V-40F CH-12V-40F BH-12V-40F PS14QF-55 Model Number: FI-BP-15N, FI-BP-15NK, FI-BP-15NV AND RELATED UNITS Page 7 of 10 | 20180626...
-
Page 8: Suction Line
BACK PLATE - Outside View SUCTION LINE S142058-VS PBS-12V NV1032HNDL, NV18, NV1032SETS STR38-IL CCSR12 BCP12V GSKT1125 SMQC-M HBSSEL1438 SMQC-FT HHPB3414 AS1-VS HBSS1212 PVCV34FM BATTERY COMPONENTS BC12V-NC72 BSLA-12V55 Model Number: FI-BP-15N, FI-BP-15NK, FI-BP-15NV AND RELATED UNITS Page 8 of 10 | 20180626... - Page 9 DFP7-F 7 INCH TANK LID FLANGE POLYETHYLENE NV1032SETS SET SCREW FOR HANDLE DFP7-PIN HINGE PIN FOR 7 INCH FILL CAP AND FLANGE NV18 NV2SV-B,6.5T DS,1/8M,10-32F-VALVE ONLY-NO SETS-NO HANDLE DP-A DRAIN PLUG ASSEMBLY FOR NATURAL PORTABLE UNITS - INCLUDES PLUG AND GASKET PUMP WITH SANTOPRENE SEALS - INCLUDES HOSE BARBS, AIR FITTING, AND EXHAUST BARB FRONT DRAIN PLUG FOR PORTABLE UNIT POLYETHYLENE P56K PUMP WITH KALREZ SEALS - INCLUDES HOSE BARBS, AIR DP-G FKM LATHE CUT 60 DUROMETER FITTING, AND EXHAUST BARB EC14-2 OETIKER CLAMP 13.8 P56V PUMP WITH VITON SEALS - INCLUDES HOSE BARBS, AIR FITTING, AND EXHAUST BARB EC18 OETIKER CLAMP - 11.3 F12SS STAINLESS .875 ID FERRULE FOR 1/2 INCH HOSE FW14 1/4 X 5/8 OD FLAT WASHER 18-8 PLN Model Number: FI-BP-15N, FI-BP-15NK, FI-BP-15NV AND RELATED UNITS Page 9 of 10 | 20180626...
- Page 10 S14201 1/4 20 Pan Head Screw - 1 inch Stainless STR38-IL IN LINE STRAINER-3/8 BARB-EPDM GSKT-20 MESH SS S1420125 1/4 20 Pan Head Screw 1 and 1/4 inch Stainless TANK-15N-B-CVR 15 GALLON NATURAL BATTERY TANK COVER S142058-VS 1/4-20 X 5/8 PHIL TRUSS MACHINE SCREW 18-8 W/#516 TSW150 THERMAL SWITCH 150 DEGREE VIBRASEAL ORANGE PATCH NONMARKING WHEEL FOR PORTABLE UNITS SC1212 S.S. COUPLER 1/2in BY 1/2in WC14RT14 INSULATED WIRE CONNECTOR - #14-16 RING TERMINAL - SH-12V-40F SWITCH HARNESS -ON/OFF- FOR LVRC-12V-40F-GRAY, 1/4 INCH STUD ORANGE AND YELLOW WIRES SMQC-FT PLATE QUICK CONNECT FPT SMQC-M PLATE QUICK CONNECT MPT Model Number: FI-BP-15N, FI-BP-15NK, FI-BP-15NV AND RELATED UNITS Page 10 of 10 | 20180626...
