3.4 Technical data for base/charging station

Operation
Base charging station zone
2/22:
Nominal values of
hazardous area base
station iSCAN212EXB2D:
Nominal values of safe
area base station:
Ambient temperature for
base station zone 2/22:
Storage temperature for
base charging station zone
2/22
Bluetooth:
Bluetooth
Operational area
Terminal assignment
(Handheld scanner)
Extronics Limited
1 Dalton Way, Midpoint 18, Middlewich, Cheshire, UK. CW10 0HU
Tel: +44 (0) 845 277 5000 Fax: +44 (0)845 277 4000 E-mail: info@extronics.com Web:
The base charging station zone 2/22 iCSAN212EXB2D may be
operated in hazardous areas. Its purpose is to receive data
captured by the associated handheld scanner zone 2/22 via
bluetooth.
•
Maximum input voltage
•
Maximum internal inductance
•
Maximum internal capacitance
•
operating voltage
•
power requirement
-20°C to +50°C
-30°C to +70°C
Bluetooth V4.0 EDR, Class 1
2.4...2.4835 GHZ (ISM band)
Up to 100m (line of sight), Batch function for increasing the range
USB cable
USB/D+ green
USB/D- white
GND black
+UB brown
Ui 6.5 V
Li Negligible
Ci <144 µF
U 5 V
I 85 mA in standby mode
RS232 cable
RS232-TXD white
GND brown
+UB yellow
