4.2 Cable range for Hazardous Area

RS232 iSCAN212EXB2D
USB iSCAN212EXB2D
4.3 Assembly RS232 in Non-Hazardous Area
The Bluetooth handheld scanner zone 2/22 can also be used separately in the hazardous area.
The base non-ex base station/charging station is then operated in the non-hazardous area.
Use an RS232 cable (iSCAN2XXCAB1 or 2) to connect the station directly to a power supply and a PC.
The warnings and notes of caution contained in these operating instructions and in the
manual issued by SICK AG (www.SICK.com) must be adhered to.
Extronics Limited
1 Dalton Way, Midpoint 18, Middlewich, Cheshire, UK. CW10 0HU
Tel: +44 (0) 845 277 5000 Fax: +44 (0)845 277 4000 E-mail: info@extronics.com Web:
1.8m
iSCAN2XXCAB5
iSCANCABR
3.8m
iSCAN2XXCAB6
1.8m
iSCAN2XXCAB9
iSCANCABU
3.8 m
iSCAN2XXCAB10
Up to 15m Host
Up to 5m Host
