HySecurity StrongArm M30 Programming & Operation Manual page 79

s a m30/m50: s
trong rm
StrongArm M30/M50 with Swing Gate
2
Configuration steps:
1. Set both gate operator's
Installer Menu item to SG 2.**
2. Configure the Close
Timer (CT).
Operator Position
F
Dimension "F" = 2 feet
minimum clearance (61 cm)
StrongArm M30
Concrete foundation shown
6 x 6 x 2 foot
(183 x 183 x 61 cm)
NOTICE:
For sequenced gates to
operate properly, all vehicle
detectors must be wired
to the Traffic Control Gate.
If a communication failure
occurs, an AL22 (Alert 22)
appears and the buzzer
sounds.
The Traffic Control Gate
maintains functionality while
the Security Gate defaults
to open until communication
is restored (or the Security
Gate is manually closed).
© 2012 Drawings not to scale.
www.hysecurity.com
g
equenCed ates
Sequential Gate #2
Vehicle Loop Layout
OUTSIDE
OBSTRUCTION
LOOP
(SLD: Shadow Loop
for Security Gate)
D
SECURITY SWING GATE
C
/
L
RESET LOOP for M30
TRAFFIC CONTROL GATE
(Becomes IOLD
for Security Gate)
A
INSIDE
OBSTRUCTION
LOOP
(for Traffic Control Gate)
Loop Installation, Detection, & Layout
#2 - s g
wIng ate
Optional access control
devices (card reader, etc.)
E
B
Bi-directional Traffic Control
D
Dimension "A" = 6 to 18 feet
Dimension "B" = 6 to 8 feet.
C
Dimension "C" = Maintain 3 feet
(91 cm) between loop and edge of
roadway.
Dimension "D" = 1 to 5 feet (30 to 152 cm)
Vehicles must pass from one loop to
the next without loss of detection.
Dimension "E" = 10 to 12 feet (305 cm
to 366 cm) if an access control device
is employed.
D0433 Rev C .
l l
oop aYout
ntro ntro
er, e r, e
(183 to 549 cm)
(183 to 244 cm)
C7
