- Page 1 4-647-113-11(1) DVD-ROM Drive Operating Instructions PCGA-DVD51 2000 Sony Corporation...
-
Page 2: Regulatory Information
For questions regarding your product or for the Sony Service Center nearest you, call 1-888-476-6972 in the United States or 1-800-961-7669 in Canada. The number below is for FCC related matters only. - Page 3 • In no event will SONY be liable for any financial damages, or loss of profits, including claims made by third parties, arising out of the use of the software supplied with this drive.
-
Page 4: Table Of Contents
Table of Contents Overview ... 5 Usable discs ... 6 Unpacking the DVD-ROM drive ... 7 Locating the controls and connectors ... 8 Setting up the DVD-ROM drive ... 9 Installing the driver (Windows Installing the driver (Windows 2000 Professional) ... 12 Using the DVD-ROM drive ... -
Page 5: Overview
Overview The DVD-ROM disc is a data memory medium that can be used to read a program or other data for a computer only. You cannot save your own data on it. The data capacity of a single-layer and single-sided DVD-ROM disc, at 4.7 GB (Giga Byte), is 7 times that of a CD-ROM disc. -
Page 6: Usable Discs
Usable discs To play CD-R discs written using “DirectCD“ software, close the operation when the writing is finished. If you use a Windows 98 models and play CD-RW discs written using “DirectCD“ software, “UDF Reader“ software must be installed in your notebook computer. -
Page 7: Unpacking The Dvd-Rom Drive
After taking the DVD-ROM drive out of the box, check that the package contains the components listed below. If anything is missing, contact the Sony dealer where you purchased this product or a Sony service representative serving your area. • PCGA-DVD51 DVD-ROM drive (1) •... -
Page 8: Locating The Controls And Connectors
Locating the controls and connectors 1 DC IN connector 2 LINE OUT connector 3 POWER indicator 4 Manual eject hole 5 Eject button 6 BUSY indicator 7 Manual eject pin (P. 18) -
Page 9: Setting Up The Dvd-Rom Drive
Setting up the DVD-ROM drive Note Make sure to connect the supplied AC adapter to the drive before installing the driver. The driver cannot be installed without the AC adapter. If you are using one of the following models PCG-505GX, 505G, 505FX, 505F, 505TX, 505TS, 505TR, Z505SX, Z505S, Z505HSK, PCG-C1X Before installing the DVD-ROM drive, the required driver must be installed in the notebook computer. - Page 10 [Control Panel]. Double-click [PC card]. [PC card (PCMCIA)] opens. If “Sony CardBus ATAPI-Socket 1” appears on the list, the driver is installed correctly. If you use any of the following models, follow the steps below to complete the installation...
- Page 11 Check that the supplied installation disk is in the floppy disk drive, ensure that “Copy manufacturer’s files from” is “A:\” and then click [OK]. Ensure that “Sony 16Bit ATAPI PC Card” appears on the “Model” item and then click [Next]. Click [Next].
-
Page 12: Installing The Driver (Windows 2000 Professional)
In step 11, confirm the installation. Double-click the icon in the taskbar on the right side of the display. [Unplug or Eject Hardware] appears. If [Sony CardBus ATAPI] in the [Hardware Devices] list, the installation is finished correctly. Click [Close] to close the window. 2000... -
Page 13: Using The Dvd-Rom Drive
Using the DVD-ROM drive Note Do not connect or disconnect the supplied AC adapter while the DVD drive is in use or the notebook computer is in power saving mode. Disconnect the AC adapter after removing the PC card. This section describes how to connect the DVD-ROM drive to your notebook computer and how to insert or remove a disc. - Page 14 24. Insert the PC card into the PC card slot on the notebook computer with the “SONY“ logo side facing up. The POWER indicator on the DVD-ROM drive lights in green when the notebook computer detects the drive.
-
Page 15: Removing The Dvd-Rom Drive From The Notebook Computer
Perform step 5 or 6 only. • Ensure that there is no disc in the disc tray before removing the DVD-ROM drive. • Instead of [Sony CardBus ATAPI], [Sony 16 Bit ATAPI Card] (Windows 98) or [Sony 16Bit ATA PC... -
Page 16: Transporting
“SONY“ logo side 1 Attach the PC card with the “SONY“ logo side facing the bottom of the DVD-ROM drive. If you attach the PC card upside down, the cable may twist and may not fit into the groove. -
Page 17: Inserting A Disc
Inserting a disc Before attempting to insert a disc, connect the AC adapter and then turn on the notebook computer. Press the eject button. The disc tray ejects. Eject button Place the disc on the center of the disc tray and, while supporting the bottom of the disc tray, press gently on the center of the disc until it clicks into place. - Page 18 Using the DVD-ROM drive (continued) Note Place the DVD-ROM drive on a level surface and then insert the manual eject pin into the manual eject hole. Removing a disc Confirm that the BUSY indicator is not flashing and press the eject button. BUSY indicator Eject button When the disc tray does not eject...
-
Page 19: Playing A Dvd-Video
Setting up to play a DVD-VIDEO Install the supplied software, “DVD Software Decoder“ and “Media Bar DVD Player“, (on the supplied CD-ROM disc) to play a DVD-VIDEO using the DVD-ROM drive. First, install “DVD Software Decoder“ and then install “Media Bar DVD Player“. - Page 20 Using the DVD-ROM drive (continued) Note When you use a notebook computer with Windows 2000 Professional, restart the notebook computer after the step 3. Ensure that “DVD-VIDEO” is checked and click [OK]. The setting is complete. Close the window and remove the disc.
- Page 21 This method may alter the wallpaper color however . • If you use a Sony C1 Series Notebook Computer, some part of display will not appear depending on titles of software. Display modes while playing a DVD-VIDEO While playing a DVD-VIDEO disc, the display mode (except for the “DVD Player“...
-
Page 22: Notes About Dvd-Video Discs
Using the DVD-ROM drive (continued) DVD region code settings If a region code warning appears when you are using the DVD player, it could be that the DVD you are trying to play is incompatible with the DVD-ROM drive in your notebook. -
Page 23: Playing An Audio Cd
Notes • The following notebook computers do not support digital audio CD playback. PCG-505GX, 505G To playback audio CDs use the audio cable RK- G136, sold separately, to connect the DVD- ROM drive’s LINE OUT connector and your notebook computer’s LINE IN connector. -
Page 24: Reinstalling
Connect the AC adapter to the notebook computer and an AC outlet. Insert the PC card into the PC card slot on the notebook computer with the “SONY“ logo side facing up. Eject the disc tray using the supplied manual eject pin and place the “Product recovery CD”... -
Page 25: Precautions
Precautions Safety Should any solid object or liquid fall into the casing, unplug the DVD-ROM drive and have it checked by qualified personnel before operating it any further. Installation Do not place the DVD-ROM drive in a location where it is : •... - Page 26 Precautions (continued) Cleaning the casing Clean the casing with a soft, dry cloth or a soft cloth slightly moistened with a mild detergent solution. Do not use any type of abrasive pad, scouring powder, or solvent such as alcohol or benzine. Cleaning the lens If you accidentally touch the lens with dirty fingers or if dust on the lens prevents the DVD-ROM drive from...
-
Page 27: Notes On Discs
Notes on Discs Handling • To keep the disc clean, handle it only by the edges. Do not touch the surface. • Do not write on or stick paper or tape to the surface of the disc. • Do not use a disc with tape, seals, or paste on it, as the disc may damage the DVD-ROM drive. -
Page 28: Specifications
Specifications The maximum data transfer rate varies with the notebook computer‘s performance. Disc Compatible discs • DVD-ROM • DVD-VIDEO • DVD-R (reading only) • CD-R (reading only) • CD-RW (reading only) • CD-ROM • Photo CD (multisession) • CD-DA (music CD) •... - Page 29 AC adapter Power requirements 100-240V AC, adjustable, 50/60 Hz Power consumption 15W max. Output voltage and current 10 Vmax., 1.5 A Other Specifications Power source DC IN connector: 10 V Connecting the supplied AC adapter supplies power from an AC outlet. Power consumption Approx.
-
Page 30: Getting Help
Getting Help This section describes how to get help and support from Sony, as well as troubleshooting tips for your DVD-ROM drive. About Sony’s Support Options Sony provides several support options for your DVD-ROM drive. When you have questions about... -
Page 31: Troubleshooting
If you experience any of the following difficulties while using the DVD-ROM drive, use this troubleshooting guide to help remedy the problem. If the problem persists, consult your nearest Sony dealer. The disc tray does not eject even when the Eject Button is pressed. - Page 32 Troubleshooting (continued) The DVD-ROM drive is not detected by the notebook computer or the POWER indicator does not light. cEnsure that the driver for the DVD-ROM drive is installed (page 9). cEnsure that the PC card is seated securely in the PC card slot of the notebook computer.
- Page 33 The sound skips during digital audio CD playback. cAnother application may be functioning. Exit the other application. To playback an audio CD while another application is functioning, perform the analog audio connections. See the operating instructions for the notebook computer. cThe notebook computer may be in power management mode.
- Page 34 DVD-VIDEO disc, the disc tray will be opened and the software cannot read data. If you remove a disc, push the eject button after stopping a DVD- VIDEO disc using the “DVD Player“ software.
- Page 36 Sony Corporation Printed in Japan...
