- Page 1 RM133 Series Rackmount Chassis User Manual January 2020 Version 1.3 A document provides an overview of product features, functions, architecture, and support specifications.
- Page 2 No license (express or implied, by estoppel or otherwise) to any intellectual property rights is granted by this document. Chenbro disclaims all express and implied warranties, including without limitation, the implied warranties of merchantability, fitness for a particular purpose, and non-infringement, as well as any warranty arising from course of performance, course of dealing, or usage in trade.
-
Page 3: Table Of Contents
RM133 Series Table of Contents List of Figures ..............................4 List of Tables ..............................6 Product Overview .......................... 7 System Features Overview ......................8 Front Panel........................... 10 Back Panel............................ 11 Front Control Panel ........................12 Chassis Dimensions ........................13 Available Rack Mounting Kit Options (Refer to “Installation”) ............14 System Level Environmental Specifications .................. -
Page 4: List Of Figures
RM133 Series List of Figures Figure 1 RM13304 overview ........................8 Figure 2 RM13310 overview ........................8 Figure 3 RM13304 major components overview ..................9 Figure 4 RM13310 major components overview ..................9 Figure 5 RM13304 front panel ....................... 10 Figure 6 RM13310 front panel ....................... - Page 5 RM133 Series Figure 39 PCIe card blank removal ......................33 Figure 40 Cards and brackets installation ....................33 Figure 41 Single 1U PSU installation-1 ...................... 34 Figure 42 Single 1U PSU installation-2 ...................... 34 Figure 43 Redundant PSU module installation..................35 Figure 44 Redundant PSU module removal ....................
-
Page 6: List Of Tables
RM133 Series List of Tables Table 1 Chenbro RM13304/10 specifications ................... 7 Table 2 Front control panel ........................12 Table 3 Slide rail installation ........................14 Table 4 System environmental specifications summary ................15 Table 5 System packaging information ....................16 Table 6 Product weight information ....................... -
Page 7: Product Overview
1. Product Overview RM133 series are 1U versatile storage server chassis, which support feature-rich motherboards in a standard form factor with dual processor sockets to address storage and computing applications. This chapter provides a high-level overview of the system features and available options. -
Page 8: System Features Overview
RM133 Series 1-1 System Features Overview Figure 1 RM13304 over view Figure 2 RM13310 over view Product Overview │... -
Page 9: Figure 3 Rm13304 Major Components Overview
RM133 Series Figure 3 RM13304 major components over view Figure 4 RM13310 major components over view A. Front Top Cover D. Rear Top Cover Latch G. Fan Assembly B. Back Top Cover E. Optical Drive Bay H. Server Board C. Label Embossing F. -
Page 10: Front Panel
RM133 Series 1-2 Front Panel Figure 5 RM13304 front panel Figure 6 RM13310 front panel A. Rack Handles C. Optical Drive Bay E. Front Control Panel B. Storage Drive Bay D. Info Tag F. Storage Drive Bay Product Overview │... -
Page 11: Back Panel
RM133 Series 1-3 Back Panel Figure 7 Back panel with redundant PSU Figure 8 Back panel with single PSU A. Redundant Power Supply C. I/O Gasket B. Single 1U Power Supply D. Full Height Expansion Slot Product Overview │... -
Page 12: Front Control Panel
RM133 Series 1-4 Front Control Panel Figure 9 RM13304 front control panel Figure 10 RM13310 front control panel Table 2 Front control panel Label ICON Indicator, button or connector Power Button LAN1, LAN2 Activity LED Power LED HDD Activity LED System Alarm LED USB3.0... -
Page 13: Chassis Dimensions
RM133 Series 1-5 Chassis Dimensions Figure 11 Chassis dimensions Figure 12 Label embossing dimensions Product Overview │... -
Page 14: Available Rack Mounting Kit Options (Refer To "Installation")
Advisory Note – Available rack and cabinet mounting kits are not designed to support shipment of the server system while installed in a rack. If you choose to do so, Chenbro advises you verify your shipping configuration with appropriate shock and vibration testing before shipment. -
Page 15: System Level Environmental Specifications
RM133 Series 1-7 System Level Environmental Specifications The following table defines the system level specifications under operating and non-operating environments. Table 4 System environmental specifications summary Parameter Specification Temperature Operating 5º C to 35º C (41º F to 95º F) -
Page 16: System Packaging
1-8 System Packaging The original Chenbro packaging, where the server system is delivered, is designed to provide protection for L5 configuration and tested to meet ISTA (International Safe Transit Association) Test Procedure 1A (2008). The packaging is also designed to be reused for shipment after the system integration has been completed. -
Page 17: System Components Removal And Installation
RM133 Series 2. System Components Removal and Installation RM133 series supports for a variety of different storage options: Up to 4 x 3.5” hot-swap HDD (RM13304) Up to 10 x 2.5” hot-swap HDD or SSD (RM13310) 2 x 2.5’’ internal HDD or SSD up to 9.5 mm thickness (RM13304) ... -
Page 18: Top Cover Installation
RM133 Series 2-1 Top Cover Installation Figure 13 Front top cover installation 1. Insert the front top cover, align the pins on the cover with the grooves on the chassis base, and slide it toward the front panel until locking into place. -
Page 19: Hdd Cage Installation
RM133 Series 2-2 HDD Cage Installation Figure 15 RM13304 HDD cage installation 1. Insert HDD cage, carefully align the grooves on the cage with the pins on the chassis, and slide the cage backward the front panel. 2. Secure HDD cage with two screws as shown. -
Page 20: External Hot-Swap Hdd Assembly Installation And Removal
RM133 Series 2-3 External Hot-swap HDD Assembly Installation and Removal Figure 17 3.5” hot-swap HDD assembly installation 1. With the lever open, insert the HDD assembly into the drive bay until the end of the HDD cage. 2. Push in the lever to lock it into place. -
Page 21: Figure 19 3.5" Hdd Installation (Tool-Less Type)
RM133 Series Figure 19 3.5” HDD installation (tool-less type) 1. Slide in the HDD until align the anchor point of HDD tray. 2. Push down the HDD when it is locked into place. NOTE: Due to degraded performance and reliability concerns, the use of the 3.5” drive blank as a 2.5” device bracket is intended to support SSD type storage devices only. -
Page 22: Figure 21 2.5" Hdd/Ssd Installation (Screw Type)
1. Align the front of HDD/SSD with the anchor point on the tray. 2. Assemble 2.5” HDD/SSD to the tray by three screws from the bottom as shown. NOTE: Dedicated screw type is required for 2.5” HDD/SSD Installation, Chenbro P/N: 384-14602-3143A0. System Components Removal and Installation │... -
Page 23: Figure 22 2.5'' Hot-Swap Hdd/Ssd Assembly Installation
RM133 Series Figure 22 2.5’’ hot-swap HDD/SSD assembly installation 1. With the lever open, insert the HDD/SSD assembly into the drive bay until the end of the HDD/SSD cage. 2. Push in the lever to lock it into place. Figure 23 2.5’’ hot-swap HDD/SSD assembly removal 1. -
Page 24: Figure 24 2.5'' Hdd/Ssd Installation (Tool-Less Type)
RM133 Series Figure 24 2.5’’ HDD/SSD installation (tool-less type) 1. Align the front of the HDD/SSD with the anchor points on the tray and slide in the HDD/SSD at an angle. 2. Push down the HDD/SSD carefully. NOTE: To ensure proper system airflow requirements, all front drive bays must be populated with drive carriers. Drive carriers must be installed with either drives or supplied drive blanks. -
Page 25: Internal 2.5'' Hdd/Ssd Installation
RM133 Series 2-4 Internal 2.5’’ HDD Installation Figure 26 RM13304 internal 2.5” HDD installation 1. Attach the plastic carrier with the HDD and engage both embossed pins into the side dimples on the HDD as shown. 2. Insert the 2.5” HDD assembly into the chassis base. -
Page 26: Internal Slim Odd Installation
RM133 Series 2-5 Internal Slim ODD Installation Figure 27 Internal slim ODD installation 1. Insert the slim ODD with an angle as shown. Ensure two embossed pins and side dimples engaged. 2. Carefully push down the slim ODD until locking into place. -
Page 27: System Maintenance
RM133 Series 2-6 System Maintenance Figure 28 Installation of whole system into the rack (screw type) 1. Push the system all the way into the cabinet. 2. Secure the system with two thumb screws clockwise on both sides. Figure 29 Installation of whole system into the rack (latch type) 1. -
Page 28: Fan Module Installation
RM133 Series 2-7 Fan Module Installation Figure 30 Fan module assembly (4028) 1. Attach the fan guard with fan as shown and secure it with two screws. 2. Insert four fan mounts as shown. Figure 31 Fan module installation (4028) 1. -
Page 29: Figure 32 Fan Module Assembly (4048)
RM133 Series Figure 32 Fan module assembly (4048) 1. Attach the fan guard with fan as shown and secure it with two screws. 2. Attach plastic extension holder with the fan. 3. Insert four fan mounts as shown. Figure 33 Fan module installation (4048) 1. -
Page 30: Figure 34 Fan Module Assembly (4056)
RM133 Series Figure 34 Fan module assembly (4056) 1. Attach the fan guard with fan as shown and secure it with two screws. 2. Attach plastic extension holder with the fan. 3. Insert four fan mounts as shown. Figure 35 Fan module installation (4056) 1. -
Page 31: Figure 36 Fan Module Assembly (4056)
RM133 Series Figure 36 Fan module assembly (4056) 1. Attach the fan guard with fan as shown and secure it with two screws. 2. Insert four fan mounts as shown. Figure 37 Fan module installation (4056) 1. Attach the fan bracket with chassis bottom and secure it with four screws. -
Page 32: Figure 38 Air Baffle Installation
RM133 Series Figure 38 Air baffle installation 1. Insert the air baffle into the fan guard as shown until its tabs locking into place. System Components Removal and Installation │... -
Page 33: Pcie Card Installation
RM133 Series 2-8 PCIe Card Installation Figure 39 PCIe card blank removal Remove the PCIe blank. Figure 40 Cards and brackets installation Secure the riser card with PCIe bracket by two screws. Align two screw holes of PCIe slot bracket with the PCIe card, and secure them with two screws. -
Page 34: Psu Installation And Removal
RM133 Series 2-9 PSU Installation and Removal Figure 41 Single 1U PSU installation-1 Figure 42 Single 1U PSU installation-2 1. Secure the PSU bracket with two screws as shown. 2. Secure the PSU bracket with another two screws from the bottom of chassis. -
Page 35: Figure 43 Redundant Psu Module Installation
RM133 Series Figure 43 Redundant PSU module installation 1. Insert the PSU module into the PSU cage and push it until clicking into place. Figure 44 Redundant PSU module removal 1. Press the latch and release the PSU module as shown. -
Page 36: Slide Rail Installation
RM133 Series 2-10 Slide Rail Installation Figure 45 Slide rail installation-1 (84H314610-003) 1. Attach the inner rail to the chassis base while aligning T pins on the side of the system with the slots on the inner rail. Figure 46 Slide rail installation-2 (84H314610-003) 2. -
Page 37: Figure 47 Slide Rail Installation-3 (84H314610-003)
RM133 Series Figure 47 Slide rail installation-3 (84H314610-003) 3. Lift the latch as shown. 4. Secure the inner rail with one screw. Figure 48 Slide rail installation-4 (84H314610-003) 5. Install the system into the rack. System Components Removal and Installation... -
Page 38: Backplane
RM133 Series 3. Backplane Each drive tray includes two LED indicators for drive activity and drive status. Light pipes integrated into the drive tray direct light emitted from LEDs mounted next to each drive connector on the backplane to the drive tray faceplate, making them visible from the front of the system. -
Page 39: Storage Backplane Options
RM133 Series 3-1 Storage Backplane Options RM133 series supports below backplanes: 4 x 3.5” SATA 7-pin port to port passive backplane 10 x 2.5” Mini-SAS HD passive backplane 10 x 2.5” NVMe passive backplane All available SAS/SATA/NVMe backplanes include the following common features: 12Gbps SAS, 6Gbps SAS/SATA, and PCIe Gen3 x 4 NVMe ... -
Page 40: 4-Port 12Gbps Passive Backplane
RM133 Series 3-2 3.5” 4-Port 12Gbps Passive Backplane Table 8 Backplane specifications Specification Host Interface SATA 7-pin HDD Interface SFF-8680 Hot-Swap Yes, allows users to replace devices online Display LED indicates storage device status Power LED – Off (Fault) – Blue on (Present) Access LED –... -
Page 41: Figure 51 Backplane Rear View
RM133 Series Figure 51 Backplane rear view Table 9 Connector and pin header function description Label Connector Description Drawing Power The backplane includes two 1 x 4 connectors supplying power to the backplane. Power is routed to the backplane via a power cable harness from the power supply. -
Page 42: 10-Port 12Gbps Passive Backplane
RM133 Series 3-3 2.5” 10-Port 12Gbps Passive Backplane Table 10 Backplane specifications Specification Host Interface SFF-8643 HDD Interface SFF-8680 Hot-Swap Yes, allows users to replace storage devices online Display LED indicates storage device status Power LED – Off (Fault) – Blue on (Present) Activity LED –... -
Page 43: Figure 53 Backplane Rear View
RM133 Series Figure 53 Backplane rear view Table 11 Connector and pin header function description Label Description Description Drawing Power The backplane includes a 2 x 2 connector supplying power to the backplane. Power is routed to the backplane via a power cable harness from the power supply. -
Page 44: 10-Port Nvme Passive Backplane
RM133 Series 3.4 2.5” 10-Port NVMe Passive Backplane Table 12 Backplane specifications Specification Host Interface OCuLink HDD Interface SFF-8639 Hot-Swap Yes, allows users to replace storage devices online Display LED indicates storage device status Power LED – Off (Fault) – Blue on (Present) Activity LED –... -
Page 45: Figure 55 Backplane Rear View
RM133 Series Figure 55 Backplane rear view Table 13 Connector and pin header function description Label Description Description Drawing Power The backplane includes a 2 x 2 connector supplying power to the backplane. Power is routed to the backplane via a power cable harness from the power supply. -
Page 46: Maintenance And Service
(Dead on Arrival) If the products are found Defect On Arrival, please contact Chenbro’s regional sales or CQE and indicate the defective status via email along with product photos and description. You may need to return the defective item by request.
