ENGINE TECHNICAL DATA N67 MNA M15

The technical code and serial number are indicated on the rating plate,
which is located on different parts of the engine, according to the
model: flywheel casing, tappet cover, coolant tank.
Commercial code
Engine family
Cycle
Number and arrange-
ment
of cylinders
Bore x stroke
Total displacement
Air system
Injection type
Engine direction of rota-
tion
Dry weight
Electrical system
Accumulator/s
- capacity
- discharge current
N67 MNA M15
F4
4-stroke diesel
6, in line
104 x 132 mm
3
6,700 cm
Natural aspiration (NA)
Direct with VE rotating pump
Anticlockwise (seen from flywheel side)
600 kg
12 V (24 V on request)
180 Ah or above
800 A or above
Available settings (*)
A1
B
C
D
(*)Maximum net power to the flywheel in compliance with ISO 3046-1.
Test conditions: T 25 °C; atmospheric pressure 100 kPa; relative
humidity 30%.
Any alteration of the above mentioned characteristics, in particular
modification of the calibration of the injection system or the
characteristics of the engine and its fittings, is strictly prohibited,
penalty invalidation of the guarantee and absence of all liability on the
part of IVECO MOTORS.
6
N67 MNA M15
110 kW (150 CV) @ 2800 rpm
99.5 kW (135 CV)@ 2800 rpm
92 kW (125 CV)@ 2800 rpm
92 kW (125 CV)@ 2800 rpm
WARNING
