- Page 1 Ultrasonic Level Meter SLM800S/1200S (USER’S MANUAL) IS Technologies Co., Ltd.
- Page 2 IABILITY IS Technologies Co., Ltd. guarantees for a period of 1 year from the date of delivery that it will either exchange or repair any part of this product returned to IS Technologies Co., Ltd. if it is found to be defective in material or workmanship, subject to the defect not being due to unfair wear and tear, misuse, modification or alteration, accident, misapplication or negligence.
-
Page 3: Table Of Contents
Contents Chapter 1 Product Specification…............................4 Chapter 2 Installation................................5 Power Supply Requirements ..............................5 Dimensions ....................................6 Terminal Connection ................................6 Outdoor and Open Vessel Application……………………………………………………………………………………….8 Closed Vessel Application……………………………………………………………………………………………………..8 Stand Pipe Application…………………………………………………………………………………………………………8 Chapter 3 How To Use Controller ............................9 Operating the Controller................................9 Chapter 4 Menu Guide...............................11 Application Menu Options ..............................11 Process Menu Options................................13 Compensation Menu Options .............................16... -
Page 4: Chapter 1 Product Specification
Chapter 1 Product Specification Product Composition SLM800S : SLM1000(CONTROLLER) + XDS800(SENSOR) SLM1200S : SLM1000(CONTROLLER) + XDS1200(SENSOR) Physical Dimensions Controller 240 (width). x 185 (height) mm = SLM1000(Controller) Sensor 67 (dia) x160 (height) mm = XDS800 88 (dia) x 100 (height) mm = XDS1200 Mounting 3/4”NPT(XDS800), 1”NPT(XDS1200) -
Page 5: Chapter 2 Installation
All electronic products are susceptible to electrostatic shock, so follow proper grounding procedures during installation. The construction of the SLM800S/1200S can be mounted easily using the thread (3/4” NPT, 1”NPT ). When choosing a location to mount the XDS800/1200(Sensor), bear in mind the following: •... -
Page 6: Terminal Connection
SLM1000 SLM-1000 MODE DOWN ALARM Sondar Ultrasonic Level Meter (185) (107) Terminal Connection 26 terminals are aligned inside the terminal box. Input & Output Terminals LL_COM L_COM H_COM HH_COM ER_COM LL_NO LL_NC L_NO L_NC H_NO H_NC HH_NO HH_NC ER_NO ER_NC... - Page 7 Function Terminal Function Note SEN+ Connect to positive wire(red) of ultrasonic sensor SEN- Connect to shield wire(blue) of ultrasonic sensor This terminal is only used at factory IOUT 4~20mA current output Maximum :900Ω IRTN Current output return RS232C interface in use, connect to reception part OPTION RS485 interface in use, connect to Y RS232C interface in use, connect to transmission part...
-
Page 8: Outdoor And Open Vessel Application
Outdoor and Open Vessel Installation The XDS800S/1200S can be simply mounted on a bracket, suitable for the application and secured using the thread located at the top of the transducer (3/4”NPT, 1” NPT). Care should be taken to ensure that the XDS800/1200 are not installed in direct sunlight, in order to avoid errors in the measurement of ambient temperature. -
Page 9: Chapter 3 How To Use Controller
Chapter 3 How To Use Controller Operating the Controller Display Window SLM1000 is designed to display various data at the same time by adopting 40 letter LCD. The display below shows an example of a normal operation of SLM1200S. Conditions : The distance between the sensor and bottom of the tank : 12m Current liquid level : 10m L : 10. - Page 10 2) UP Button : Used for increasing the value. 3) DOWN Button : Used for decreasing the value. 4) RUN Button : Used for starting measurement. Alarm Display 1) HH LED Lamp : Lighted in case of upper limit operated 2) H LED Lamp : Lighted in case of upper alarm operated 3)L LED Lamp : Lighted in case of lower alarm operated 4)LL LED Lamp : Lighted in case of lower limit operated...
-
Page 11: Chapter 4 Menu Guide
Chapter 4 Menu Guide Application Menu Option 1) Password PASSWORD IDENTITY PASSWORD : Password is needed to enter the operation mode. After setting the password using UP/DOWN button, press MODE to get into the operation mode. - Password : 412 2) Measure Type MEASURE TYPE SET LEVEL... - Page 12 This option is the distance from the face of the transducer that is not capable of being measured, and is pre-set to 35cm(SLM800S) or 50cm(SLM1200S). It should not be set to less than this figure, but can be increased if required.
-
Page 13: Process Menu Options
7) HH ON Point Setting HH ON POINT SET ON : 11.00m This option determines the high limit “ON” point for HH relay - Setting Range : SLM800S : 0.35~8m SLM1200S : 0.5~12m 8) HH OFF Point Setting HH OFF POINT SET OFF : 10.00m... - Page 14 11) L ON Point Setting L ON POINT SET ON : 2.00m This option determines the “ ON” point for L switched output - Setting Range : SLM800S : 0.35~8m SLM1200S : 0.5~12m 12) L OFF Point Setting L OFF POINT SET OFF : 3.00m...
- Page 15 ERROR CURRENT SET SET : 3.8mA If the SLM800S/1200S fails to receive a valid echo return from the target, then the mA output can be used to indicate a fault condition (Lost of Echo) - Setting Range : 3.8mA, 21mA, HOLD...
-
Page 16: Compensation Menu Options
Compensation Menu Options 19) Detection Threshold Voltage DETECTION THRESHOLD LEV : 4 This option determines detectable size of return echo. This is useful when the first return echo is needed in condition where small objects creating various kinds of return echoes exist. In case the set value is high, it can be stronger to the noise, but may not be able to detect small echoes. - Page 17 MATERIAL TEMPERATURE TEMP : 25.0°C The SLM800S/1200S uses an internal temperature sensor, housed inside the transducer nose cone and therefore the temperature used for compensation is the temperature close to sensor. In applications where there is a large difference between the temperature near the sensor and that at the surface of the material being measured, errors in measurement may occur.
- Page 18 - Setting Range : 0~100 25) Measuring Unit UNIT(FEET/METER) METER This option determines system unit. - Setting Range : METER, FEET 26) 12mA Output 12mA OUTPUT SLM800S/1200S outputs 12mA regardless of measurement at this mode. This option is used with other equipments for testing.
-
Page 19: Chapter 5 Digital Communication
Chapter 5 Digital Communication The SLM800S/1200S provides RS232/485 digital communication interface function as option The kinds of data and its format are as follows; Output Data 1. Kinds of Output Data 1) Distance Data Distance from the sensor to the surface of measuring material. Unit is mm 2) Temperature Data This is temperature data measured by built-in temperature sensor. -
Page 20: Chapter6 Trouble Shooting
Chapter 6 Troubleshooting This section describes some problem symptoms, with suggestions as to what to do. Symptom What to Do Display blank, transducer not Check power supply firing. Display shows “S”, “ ERROR! “S” means there is an abrupt liquid change or an obstacle in the LOST ECHO”... -
Page 21: Menu Option Record
Menu Option Record SLM800S/1200S Option Details Entered Value Description Factory Set Value Range Password Identity 0 ~ 1000 Measure Type Level Level/Distance/Space Bottom Distance 8.50m/12.50m 0 ~ 8.50m/12.50m 4mA SetPoint 0.00m 0 ~ 10.00m 20mA SetPoint 8.50m/12.50m 0 ~ 8.50/12.50m Blanking 0.35m/0.50m...
