IS Technologies SONDAR 5000 User Manual

Ultrasonic open channel flow meter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SONDAR 5000
Ultrasonic Open Channel Flow Meter
(USER'S MANUAL/FEET)
IS Technologies Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SONDAR 5000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IS Technologies SONDAR 5000

Summary of Contents for IS Technologies SONDAR 5000

  • Page 1 SONDAR 5000 Ultrasonic Open Channel Flow Meter (USER’S MANUAL/FEET) IS Technologies Co., Ltd.
  • Page 2 IABILITY IS Technologies Co., Ltd. guarantees for a period of 1 year from the date of delivery that it will either exchange or repair any part of this product returned to IS Technologies Co., Ltd. if it is found to be defective in material or workmanship, subject to the defect not being due to unfair wear and tear, misuse, modification or alteration, accident, misapplication or negligence.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1 Introduction ................................4 About Sondar 5000 ................................4 Features of of Sondar 5000… .............................. 5 Product Specification… ................................. 6 Chapter 2 Installation ................................7 Dimensions .................................... 7 Cable Entry .................................... 8 Sensor Installation… ................................10 Chapter 3 How To Use Sondar5000 ..........................

  • Page 4: Chapter 1 Introduction

    Chapter 1 Introduction About SONDAR 5000 Sondar 5000 is an instrument that can be used both as ultrasonic open channel flow meter and level gauge. The ultrasonic open channel flow meter measures the water level and calculates and displays accurate flow rate and total flow rate in a manner to measure the flow rate according to a flow/level calculation method, based on the principle that water level is specifically related to flow rate in the standardized open channel.

  • Page 5: Features Of Of Sondar 5000

    Features of SONDAR 5000 Non-contact flow measurement - applicable to various fluids, semi-permanent life Applicable to various kinds of channels 10 point DIY CURVE function able to conduct flow measurement, regardless of the types of channels Digital measurement and display (0.01 gal/min)

  • Page 6: Product Specification

    Product Specification Physical 240(width). X 185(height) mm Controller Ø 67(dia) X 160(height) mm Sensor 3/4” NPT Mounting around 3.0kg (sensor, controller) Weight Polypropylene Sensor Material Environmental IP65(Controller) IP Rating (electronics housing) -20 ºC to +60 ºC(Controller), -20 to +70°C(Sensor) Max. & Min. temperature (electronics) 10m (Standard) RTX cable length Performance...

  • Page 7: Chapter 2 Installation

    Chapter 2 Installation Sondar 5000 is composed of a controller unit and one sensor Power Supply Requirements The Sondar 5000 operates from a AC supply of 90 ~260V. All electronic products are susceptible to electrostatic shock, so follow proper grounding procedures during installation.

  • Page 8: Cable Entry

    Controller MODE Cable Entry There are 23 terminals for controller and 3 terminals for power board as follows: Input & Output Terminal A1_COM A2_COM ER_COM A1_NO A1_NC A2_NO A2_NC ER_NO ER_NC...
  • Page 9 Function Terminal Function Note DC +12V output SEN- Connect to shield cable of sensor of RTX Black SEN+ Connect to +cable of sensor of RTX TX CLK Output of sensor’s transmitting signals in pulse form Option Connect to outer temperature sensor External Input[FOLW SWITCH] External input GND When using RS232C interface, connection to RS232C's transmitter.

  • Page 10: Sensor Installation

    Sensor Installation Min 30cm 10° Less than 2m In order to prevent malfunctions and assure accurate measurement, installation should be conducted under consideration of the following points. 1) There should be no disturbing objects within the range of 10°beam angle where the ultrasonic pulse moves.
  • Page 11 Weir Flow In the rectangular, triangular, and Cipolletti channels, the sensor should be installed at the top of the channel (Max. height x 4 ~ 5 times recommended). Parshall Flume 2/3 L Flow Flow In the Parshall Flume, the sensor should be installed at a 2/3 position of the whole converging section length.
  • Page 12 In the Leopold-Largco Flume, the sensor should be installed at a position distant from Converging Section (corresponding to the distance of measurement point according to Flumes size) Flume Size Measurement Point inches inches 100 ~ 4~12 Flickering of "DT" at the bottom of the screen at Operation Mode means detection of water level. Therefore, such flickering should be confirmed in the course of installation.

  • Page 13: Chapter 3 How To Use Sondar5000

    Chapter 3 How To Use SONDAR 5000 Operating the controller Sondar 5000 Flow Rate: [GPM] 12345.6 Lev. : 1 . 2 3 4 ft R 1 R 2 SYSTEM OK DT Ultrasonic Open Channel Flow Meter Operation Mode I Push SET button at Operation Mode I and Operation Mode II will be displayed. Operation Mode II can be toggled to Operation Mode I by SET button.

  • Page 14: Button Functions

    4) T : Ambient temperature. 5) Bar graph: Ratio of measured flow rate to max. flow rate. Description of characters displayed SONDAR 5000 shows its operational conditions on its LCD. 1) A1 : RELAY1 is ON. 2) A2 : RELAY2 is ON.

  • Page 15: Chapter 4 Menu Guide

    Chapter 4 Menu Guide Application Menu Option Password Check PASSWORD PASSWORD CHECK CHECK Password Number? Password Number? **** **** PASSWORD OK! PASSWORD WRONG RETURN MEASURE MODE < When password is confirmed > < When password is not confirmed > Push MODE button at Operation Mode and PASSWORD CHECK, the initial menu of Program Mode, will be displayed.
  • Page 16 Password Change Factory Set= 0 *01. PASSWORD CHANGE 02. DEVICE SELECTION 03. AUTO ZERO 04. BOTTOM DISTANCE This is an option for change of password. Push ↑ or ↓ to change the password. Push SET button and the changed password will be saved. The initial value is 0.
  • Page 17 At Program Mode, push ↑ or ↓ to place the cursor (*) at a specific menu and push SET button to go to the mode for change of the relevant device. Push ↓ at No. 4 and Screen II showing No. 5 to 8 will be displayed. Also, push↑ at No. 1 and the cursor will go to No.
  • Page 18 Select Rect. Suppressed and push SET button. Then, the menu for selection of the rectangular weir will be displayed as shown in the above figure. Use ↑ or ↓ to select the relevant Rect. Suppressed and push SET button to save the set values and return to main menu option.
  • Page 19 V-Notch Weirs[Triangular] Factory Set = 0.600m 4. V-Notch Weirs ** Weir Selection: 1 : 22.5° 2 : 30° 3 : 45° 4 : 60° 5 : 90° 6 : 120° Select V-Notch Weirs and push SET button. Then, the menu for selection of the triangular weir will be displayed as shown in the above figure.
  • Page 20 Leopold Lagco Flumes Factory Set = 1 6. Leopold Lagco Flumes ** Flume Selection: 1 : 4in. 2 : 6in. 3 : 8in. 4 : 10in. 5 : 12in. 6 : 15in. 7 : 18in. 8 : 21in. 9 : 24in. 10 : 30in.
  • Page 21 DIY Curve / Special Factory Set = 1 8. DIY Curve/Special ** Selection: 1 : DIY CURVE 2 : Q=K*H(PWR) 3 : Rectangular Weir Select DIY Curve / Special and push SET button. Then, an option for selection of 1. DIY Curve, 2.
  • Page 22 Q=K*H(PWR) Factory Set = 1.234 2. Q=K*H(PWR) K Constant : 1.234 KWR Constant : 1.234 H: Height [mm] Select 2. Q=K*H(PWR) and push SET button. Then, an option to input constants, K and PWR, will be displayed as shown in the above figure. Use ↑...
  • Page 23 Rectangular Weir Factory Set = 1 3. Rectangular Weirs *Selection: 1. Suppressed Weir 2. Contracted Weir *Crest Length[m]: 1.234 Select 3. Rectangular Weirs and push SET button. Then, two options to select the type of rectangular weir, *Selection and *Crest Length [m], will be displayed as shown in the above figure.
  • Page 24 DT will flicker and the distance will appear. When the distance is stabilized after damping time (measurement response rate), "Auto SET? SET, No? DOWN" will be displayed. If you want automatic setting of the measured value, push SET button. If not, push DOWN button and select other menu.

  • Page 25: Proces Menu Option

    5. MAX FLOW 1. 2 3 4m [1 2 3 4ft] 1 2 3 4 5 6 7.8 9 m3/h 1 2 3 4 5 6 7.8 9 gal/min Use ↑ or ↓ to change maximum acceptable height and the flow rate at the height will be displayed.
  • Page 26 Relay1 On Point Factory Set= 10% of Max. flow value set at option 02 “Device Selection” 05. MAX FLOW 06. 4mA POINT 07. 20mA POINT *08. RELAY 1 ON POINT When the measured flow rate is below RELAY 1 On Point, the device's RELAY 1 is turned on. The initial value is the flow rate corresponding to 10% of the maximum measurable flow rate (m3/h) of the device set in 02.
  • Page 27 Relay2 Off Point Factory Set= 80% of the Max. flow value set at option 02 “Device Selection” 09. RELAY 1 OFF POINT 10. RELAY 2 ON POINT *11. RELAY 2 OFF POINT 12. RELAY SIMULATION When the measured flow rate is below RELAY 2 Off Point, the device's RELAY 2 is turned off. The initial value is the flow rate corresponding to 80% of the maximum measurable flow rate (m3/h) of the device set in 02.
  • Page 28 RELAY SIMULATION R1 ON : R1 OFF : R2 ON : R2 OFF : FR : This shows flow rate values set in 08, 09, 10, and 11. Further, virtual flow rates will flicker. Use ↑ or ↓ to adjust those virtual values. In this way, operational conditions of R1 and R2 can be checked.
  • Page 29 Time Factory Set = N/A 13. LOW CUT VALUE 14. HIGH CUT VALUE *15. TIME SEP/02/2003/ Tue 16:30 16. TOTALIZER Push SET button and the month/date/year/day and hour:minute will be displayed. If you don't want to change the value, push SET button again. If you want to change the value, push ↑ or ↓ to change the month.
  • Page 30 Use ↑ or ↓ to set total time and then, push SET button to save the value and go to other menu. (Setting range: 0 ~ 999999999, Unit: 1 h) ※ Delete all data previously saved. Data Save Period FactorySet = 10 mins *17.
  • Page 31 Pulse period FactorySet = 0.10 sec 17. DATA SAVE PERIOD 18. PULSE VALUE *19. PULSE PERIOD 20. DATA TRANSFER This is an option for setting the width for one pulse output according to the flow rate set in No. 18. The initial value is 0.10 sec. (Setting range: 0.01 ~ 1.00, Unit: 0.01 sec) Data Transfer Factory Set = N/A 17.
  • Page 32 2001/01/10 14/01 Memory restart! Save time:01min 2001/01/10 14/02 LE:0.194m FR: 17.14m3/h TF: 4066.90m3 2001/01/10 14/03 LE:0.195m FR: 17.28m3/h TF: 4067.19m3 2001/01/10 14/04 LE:0.194m FR: 17.14m3/h TF: 4067.47m3 2001/01/10 14/05 LE:0.194m FR: 17.14m3/h TF: 4067.75m3 2001/01/10 14/06 LE:0.194m FR: 17.14m3/h TF: 4068.04m3 2001/01/10 14/07 LE:0.194m FR:...

  • Page 33: Compensation Menu Option

    Compensation Menu Options Transmit Power Factory Set = 3 21. BLANKING *22. TRANSMIT POWER 23. OUTPUT DAMPING 24. FAIL SAFE CURRENT This is an option for setting the ultrasonic sensor's output. This menu adjusts the output and maintains optimal conditions under operating environments. Set low TRANSMIT POWER if there are many obstacles around it.
  • Page 34 Fail Safe Current Factory Set = 3.8mA 21. BLANKING 22. TRANSMIT POWER 23. OUTPUT DAMPING *24. FAIL SAFE CURRENT 3.8mA This is an option for setting FAIL SAFE CURRENT. If the reflected wave is not sufficiently received, a specific current different from normal output current is generated to indicate the error.
  • Page 35 This is an option for setting threshold for detection of the reflected wave. This menu adjusts the threshold for detection of the reflected wave and maintains optimal conditions under operating environments. To reduce the probability of false detection or at an environment generating lots of noise, increase the threshold value.
  • Page 36 28. FLOW SWITCH **Selection. 1. Installation 2. Uninstallation If a flow switch is installed and used, select "1". If not, select "2". Push SET button to display the saved value and change it. Use ↑ or ↓ to select the one you want.
  • Page 37 Chapter 5 Digital Communication The Sondar5000 provides RS232/385 digital communication interface function as an option. The kinds of data and its format are as follows ; Output Format 1. Level Data Output level data in ft 2. Flow Rate Data Output flow rate data in gal/m 3.

  • Page 38: Chapter 5 Maintenance

    Chapter 6 Maintenance Sondar 5000 does not require any special maintenance work. However, in areas where there are lots of floating matters or viscous sludge, the sensor's surface may be contaminated by them. Therefore, for accurate measurement, it is necessary to install a device to clean the sensor at appropriate interval.

  • Page 39: Chapter 6 Menu Option Record

    Chapter 7 Menu Option Record SONDAR 5000 APPLICATION Option Details Entered Value Description Factory Set Value Range Password Change 0~1000 Device Selection 1(Parshall Flume) Refer to manual Auto Zero Bottom 0.400~4.000m 1.200m Max Flow Refer to manual Refer to manual...

  • Page 40: Appendix

    Appendix > Schematic Diagrams of Channels < Parshall Flume Parshall Flumes are standardized. Depending on the channel width, there are 15 kinds of Parshall Flumes. Bottom Zero <Fig. A-1> Aerial View of Parshall Flume...
  • Page 41 Rectangular Weir, Triangular Weir, Suppressed Rectangular Weir, and Cipolletti Weir <Triangular Weir (60') > <Rectangular Weir> Crest length < Cipolletti Weir > < Suppressed Rectangular Weir> <Fig. B-1 > Front Views of Weirs h : Water level B : Suppressed Rectangular Weir's Width (m) b : Rectangular Weir's Width (m) D : Thickness from Weir's Bottom (m)
  • Page 42 4~5 × hmax Bottom Zero <Fig. B-2 > Aerial View of Rectangular Weir...
