BENDIX
R-8
RELAY VALVE MAINTENANCE KIT
®
™
Bendix
R-8
®
Kit Contents
Item No.
1
O-Ring (.987" I.D.)
2
O-Ring (3.725" I.D.)
3
O-Ring (1.424" I.D.)
4
Inlet-Exhaust Valve Assy.
5
Sealing Ring (4.125" I.D.)
6
Exhaust Diaphragm
7
Diaphragm
8
Tube of Lubricant
Figure 1 – Bendix
R-8
®
Relay Valve
™
Valve Body
Description
Relay Valve Maintenance Kit Contents
™
Piston Return
Piston
Spring
2
5
6
3
Exhaust Cover
Assembly
Qty.
1
1
1
1
1
1
1
1
10-24
Exhaust
Valve
Screw
Cover
Washer
Screw
Cover
1
7
Cap Nut
4
1
