  • Page 1 Spectrophotometer CM-36d CM-36dG Instruction Manual Please read before using the instrument.

  • Page 2: Safety Symbols

    • The KONICA MINOLTA logo and symbol marks and SpectraMagic are registered trademarks of KONICA MINOLTA, Inc. Notes on this Manual • Copying or reproduction of all or part of the contents of this manual without the permission of KONICA MINOLTA is strictly prohibited.
  • Page 3 Always use the AC adapter (AC-A312F) that was supplied as a standard accessory, and connect it to a 100 V (50/60 Hz) AC outlet. If an AC adapter other than those specified by KONICA MINOLTA is used, or if the adapter is connected to an unsupported voltage, it may result in damage to the adapter, fire, or electric shock.
  • Page 4 (Failure to adhere to the following points may result in injury or damage to CAUTION the instrument or other property.) Do not place the instrument on an unstable or sloping surface. Doing so may result in the instrument falling or overturning, causing injury. Be careful not to drop the instrument when carrying it as well.

  • Page 5: Introduction

    This instrument is a precision measuring instrument. When transporting the instrument to a service facility for maintenance or for other reasons, be sure to use the packing materials to minimize shock or vibration. If the packing materials are lost or damaged, contact a KONICA MINOLTA-authorized service facility. Sample Holder Protective Cap The instrument is shipped without the target mask installed in the target mask mounting section.

  • Page 6: Notes On Use

     Notes on Use Operating Environment • This instrument should be installed and used in an environment with an ambient temperature between 13°C and 33°C and a relative humidity of 80% or less (at 33°C) with no condensation. Use of the instrument outside this range will result in unsatisfactory performance.
  • Page 7 Measurement • Make sure no dust or dirt enters the openings of the instrument. • When the instrument is used over a prolonged period, the measured values may deviate due to changes in the environment or other factors. In order to maintain good measurement accuracy, it is recommended that white calibration and gloss calibration be performed regularly.

  • Page 8: Notes On Storage

    If the dirt on the calibration plate does not come off easily, wipe using a soft cloth dampened with ethanol. • If the inside of the integrating sphere becomes dirty, contact a KONICA MINOLTA-authorized service facility. • If you are unable to remove dirt from the instrument through the above procedure, or if the instrument becomes scratched, contact a KONICA MINOLTA-authorized service facility.

  • Page 9: Notes On Transporting

     Maintenance and Inspection • To maintain measurement accuracy, the instrument should be inspected once a year. For information on inspection, contact the nearest KONICA MINOLTA-authorized service facility.  Disposal Method • Make sure that the instrument, all accessories, and the packing materials are either disposed of or recycled...

  • Page 10: Table Of Contents

    Table of Contents  Safety Symbols ............................. i Trademarks ............................... i Notes on this Manual ............................i Introduction ............................3  Notes on Use ............................... 4  Notes on Storage ............................6  Notes on Cleaning ............................6  Notes on Transporting ..........................7 ...

  • Page 11: Accessories

    Accessories Standard and optional accessories are available with the instrument. Memo The shape of some products may be different from those shown. ² indicates an accessory only for the CM-36dG.  Standard Accessories White Calibration Plate CM-A288 Used to perform white calibration. Memo When the plate is not being used, close the cover to prevent the plate from becoming dusty or scratched and to protect it...
  • Page 12 USB Cable (2 m) IF-A17 Used to connect the instrument to a computer. Accessory Case CM-A286 This case is used to store all the accessories in one place. Notes Use it for storage. Do not use it on its own for transport. Dust Cover CM-A295 This can prevent foreign substances from entering the instrument when it is stored in a location where there is much...

  • Page 13: Optional Accessories

     Optional Accessories DVD for Color Data Software SpectraMagic NX CM-S100w (Ver. 3.2 or later) This computer software is used to control the instrument and manage data from a computer. UV Control Software for CM-36dG/V This software is used to calculate the UV control coefficient and write it to the instrument when measuring a sample that includes fluorescence.

  • Page 14: System Diagram

    System Diagram CM-36dG Color Plates (14 colors) DVD for Color Data Software SpectraMagic NX Plastic Cell Professional version CM-A130 (optical path length 2 mm) Basic version CM-A131 (optical path length 10 mm) * With UV Control Software CM-A132 (optical path length 20 mm) for CM-36dG/V Glass Cell CM-A97...
  • Page 15 CM-36d Color Plates (14 colors) DVD for Color Data Software SpectraMagic NX Professional version Basic version * With UV Control Software for CM-36dG/V Computer (commercially available) Target Mask (LAV) USB Cable CM-A291 IF-A17 (2 m Spectrophotometer Target Mask (MAV) CM-36d...

  • Page 16: Names And Functions Of Parts

    Names and Functions of Parts ① ⑤ ② ③ ④ ④ ⑥ ⑦ ² Transmittance specimen chamber �Used to install samples when performing transmittance measurement. ² Target mask �����������Select an illumination area of ø30 mm (LAV), ø20 mm (LMAV) , ø11 mm (MAV), or ø7 mm (SAV) according to the specimen to be measured, and install into the instrument.

  • Page 17: Opening And Closing The Transmittance Specimen Chamber ²

    Opening and Closing the Transmittance Specimen Chamber ²  Opening the Transmittance Chamber Procedure 1 Pull the knob on the transmittance chamber cover up to ① ① unlock it. ② Pulling it up frees the cover to open and close. ②...

  • Page 18: Indicators

    Indicators ² ² ² ² CM-36dG only Status panel and operation keys Operation keys Power key Used to turn the power ON/OFF. The instrument switches between ON/OFF every time the power key is pressed. The lamp illuminates blue when the power is ON. ON: Press once.

  • Page 19: Cleaning Parts

    • Do not touch the white-coated inner surface of the integrating sphere, wipe it with a cloth, or put an object inside it. If it becomes dirty and the dirt cannot be removed by a blower, contact a KONICA MINOLTA-authorized service facility. Receptor Window of the Transmittance Specimen ²...

  • Page 20: Measurement Procedure

    Measurement Procedure • This manual explains the measurement preparation procedure, specimen setting procedure, and other procedures for measurement with the CM-36dG/36d. • Control is performed and measurement is executed from the computer connected to the instrument by using the optional SpectraMagic NX (CM-S100w) color data software. •...

  • Page 21: Preparation

    Preparation  Connecting to a Computer Connect the instrument to the computer with the supplied USB cable IF-A17 (2 m). Notes Be sure to connect the USB cable to the designated USB terminal on the instrument when it is used. Memo •...

  • Page 22: Connecting The Ac Adapter

     Connecting the AC Adapter Notes • To supply AC power to the instrument, always use the AC adapter (AC-A312F) that was supplied with the instrument. • Insert the AC adapter plug all the way. Operating Procedure 1 Check that the power of both the instrument and computer is OFF (LED lamp is not illuminated).

  • Page 23: Installing The Target Mask

    (measurement area ø4 mm / illumination area ø7 mm) (²) Memo • Not included with CM-36d. Procedure 1 Pull the sample holder toward you and hold it so it is opened. 2 Pull the currently installed target mask toward you to remove it.

  • Page 24: Mask Detection Function

    • Check that there is no dirt or scratching on the mounting surface of the target mask. If there is dirt, use a blower to remove any dust, dirt, and other substances. If the dirt does not come off easily, wipe using a soft cloth dampened with ethanol. If the above does not resolve the problem, contact a KONICA MINOLTA-authorized service facility.

  • Page 25: Installing The Zero Calibration Box

    Installing the Zero Calibration Box The zero calibration box is used to perform zero calibration for reflectance measurement, and to perform haze measurement for transmittance measurement. • Perform this calibration when there is no specimen in the transmittance specimen chamber. •...

  • Page 26: Installing The White Calibration Plate

    Installing the White Calibration Plate The white calibration plate is used to perform white calibration for reflectance measurement, and to perform transmittance measurement (²) (0% calibration, 100% calibration, measurement). • Perform this calibration when there is no specimen in the transmittance specimen chamber. •...

  • Page 27: Installing The Gloss Calibration Plate

    Installing the Gloss Calibration Plate ² The gloss calibration plate is used when performing gloss calibration. Install the target mask to use for measurement in advance. From the software in advance, set the same measurement area, specular component (SCI/SCE), and UV output that will be used for measurement.

  • Page 28: Installing The Transmittance Zero Calibration Plate ² (Option)

    Installing the Transmittance Zero Calibration Plate (Option) ² The transmittance zero calibration plate is used when performing 0% calibration for transmittance measurement. • When using the optional SpectraMagic NX, set the measurement method to transmittance in advance. • Install the target mask for LAV measurement and the white calibration plate onto the instrument. Procedure 1 Open the transmittance specimen chamber cover.

  • Page 29: Transmittance Measurement 100% Calibration Procedure

    Transmittance Measurement 100% Calibration Procedure ² Transmittance measurement 100% calibration can be performed with nothing set in the transmittance specimen chamber or using the cell (option) and distilled water (or pure water). Memo • When measuring a liquid sample using the cell (option), perform 100% calibration using the cell and distilled water (or pure water).

  • Page 30: Setting A Specimen

    Setting a Specimen Reflectance Measurement P.29 When measuring the reflectance of a film or plate specimen, install the specimen into the sample holder before setting it onto the instrument. When measuring a specimen that is not fit into the sample holder, remove the sample holder and measure with the specimen measuring port in close contact with the specimen.

  • Page 31: Reflective Measurement/Gloss Measurement

     Reflective Measurement/Gloss Measurement ² • Perform this calibration when there is no specimen in the transmittance specimen chamber. • Install the target mask to use for measurement in advance. • From the software in advance, set the measurement area, the specular component, and UV output. Procedure 1 Pull the sample holder toward you and hold it so it is opened.

  • Page 32: Transmittance Measurement

     Transmittance Measurement ² • When using the optional SpectraMagic NX, set the measurement method to transmittance in advance. • Install the target mask for LAV measurement and the white calibration plate onto the instrument. Procedure 1 Open the transmittance specimen chamber cover. 2.
  • Page 33 • Perform measurement when the specimen or the inside and outside of the container containing the specimen are free of scratches, fingerprints, and other dirt. If the measurement surface is grasped with a hand, fingerprints will be left on it. Hold the specimen at a part which is not the measurement surface. •...

  • Page 34: Error Messages

    SpectraMagic NX (CM-S100w) operating screens. When a message is displayed, perform the correction shown below. If the conditions do not return to normal after performing the correction, contact a KONICA MINOLTA-authorized service facility. Symptom Displayed message...
  • Page 35 KONICA MINOLTA- dropped. dropped. authorized service facility. Expiration of the The time when wavelength To renew the wavelength...
  • Page 36 Symptom Displayed message Possible cause Correction 36dG Install the white calibration White calibration was Perform white calibration plate and appropriate not performed using the using the provided white target mask, and then correct procedure. calibration plate and perform calibration. appropriate target mask. Install the gloss calibration Gloss calibration was Perform gloss calibration...
  • Page 37 Symptom Displayed message Possible cause Correction 36dG The specified operation The operation cannot Wait for motor operation to cannot be executed be executed because end before executing the because motor drive is in the motor that performs operation. progress. switching of the measurement area and SCI/SCE is currently operating.

  • Page 38: Troubleshooting

    If an abnormality has occurred with the instrument, take the necessary actions as given in the table below. If the instrument still does not work properly, turn the power OFF, and then turn it ON again. If the conditions still do not return to normal, contact a KONICA MINOLTA-authorized service facility. Symptom...
  • Page 39 Symptom Check Point Action Reference Page Measurement ² Is there a foreign ² Remove the specimen or other results are abnormal. substance in the substance from the transmittance (Reflection (color), transmittance specimen chamber. gloss ² specimen chamber? Is transmittance Refer to the software instruction For details, refer to the measurement manual and perform the...

  • Page 40: Fluorescence Measurement

    Fluorescence Measurement ² This instrument features both a UV full xenon lamp and a UV cut xenon lamp. Fluorescence reflectance is calculated through numerical processing of the reflectance from these two light sources. With fluorescence calibration To ensure accurate fluorescence reflectance measurement, fluorescence calibration can be performed using the UV Control Software that is provided with SpectraMagic NX (Ver.

  • Page 41: Specifications

    Compared to values measured with a agreement Konica Minolta standard measurement master body under Konica Minolta conditions) standard measurement conditions) 100% / 0% / Adjusted (Instantaneous numerical adjustment of UV with no...
  • Page 42 ±0.2 GU 10 to 100 GU: ±0.5 GU Inter-instrument (MAV. Compared to values measured with a − agreement master body under Konica Minolta standard conditions) JIS-Z8741 (MAV), JIS-K5600, ISO2813, Geometry ISO7668 (MAV), ASTM D523-08, ASTM − D2457-13, DIN 67530 Approx. 3.5 seconds (SCI+SCE measurement) Approx.

  • Page 43: Dimensions

    Dimensions CM-36dG (Unit: mm) 4-M3, depth 5...
  • Page 44 CM-36d (Unit: mm) 4-M3, depth 5...
  • Page 45 <CAUTION> KONICA MINOLTA WILL NOT BE LIABLE FOR ANY DAMAGES RESULTING FROM THE MISUSE, MISHANDLING, UNAUTHORIZED MODIFICATION, ETC. OF THIS PRODUCT, OR FOR ANY INDIRECT OR INCIDENTAL DAMAGES (INCLUDING BUT NOT LIMITED TO LOSS OF BUSINESS PROFITS, INTERRUPTION OF BUSINESS, ETC.) DUE TO THE USE OF...
  • Page 46 9222-AD2X-11 ©2021 KONICA MINOLTA, INC. CBCADA...
