CAUTION
THIS ATV WAS SHIPPED
WITHOUT ENGINE OIL.
ALWAYS FILL WITH THE
CORRECT AMOUNT AND
GRADE OF ENGINE OIL
POWERSPORTS
AS LISTED IN THE
OWNER'S MANUAL
ASSEMBLY/PRE-RIDE
INSPECTION INSTRUCTIONS
AT200-B
FOR QUESTIONS ABOUT THESE ASSEMBLY INSTRUCTIONS,
CALL COLEMAN POWERSPORTS 888-405-8725
WARNING
WARNING
NEVER ATTEMPT TO START THIS ATV WITHOUT READING AND
UNDERSTANDING THE OWNER'S/ OPERATOR'S MANUAL. THE
OWNER'S OPERATOR'S MANUAL PROVIDES INFORMATION ON
SAFETY, PARTS, FUNCTIONS, PRE-RIDE INSPECTION,
STARTING AND MAINTENANCE
01J05R21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AT200-B and is the answer not in the manual?

Questions and answers

Related Manuals for Coleman AT200-B

Summary of Contents for Coleman AT200-B

  • Page 1 AS LISTED IN THE OWNER’S MANUAL ASSEMBLY/PRE-RIDE INSPECTION INSTRUCTIONS AT200-B FOR QUESTIONS ABOUT THESE ASSEMBLY INSTRUCTIONS, CALL COLEMAN POWERSPORTS 888-405-8725 WARNING WARNING NEVER ATTEMPT TO START THIS ATV WITHOUT READING AND UNDERSTANDING THE OWNER’S/ OPERATOR’S MANUAL. THE OWNER’S OPERATOR’S MANUAL PROVIDES INFORMATION ON...
  • Page 2 AS LISTED IN THE OWNER’S MANUAL ASSEMBLY/PRE-RIDE INSPECTION INSTRUCTIONS FOR QUESTIONS ABOUT THESE ASSEMBLY INSTRUCTIONS, CALL COLEMAN POWERSPORTS 888-405-8725 WARNING WARNING NEVER ATTEMPT TO START THIS ATV WITHOUT READING AND UNDERSTANDING THE OWNER’S/ OPERATOR’S MANUAL. THE OWNER’S OPERATOR’S MANUAL PROVIDES INFORMATION ON...
  • Page 3 PARTS (continued) TIRE ASSEMBLY Front Tires Rear Tires M20 Washers M20 Castle Nuts M10 Lock Nuts M20 Lock Washers Cotter Pins M10 Washers Hub Caps Hub Caps DISPLAY CONSOLE ASSEMBLY M6 X 16 Bolts BATTERY...

  • Page 4: Handlebar Installation

    HANDLEBAR INSTALLATION HANDLEBAR PARTS 1. Attach bottom clamp brackets to Handlebar Clamp steering assembly Bracket bracket using M10 x 30 bolts, M10 Lock Washers Steering Assembly and M10 Lock Nuts Bracket Display Console Bracket Display Console Handlebar Bracket M10 x 30 Bolts...
  • Page 5 DISPLAY CONSOLE INSTALLATION HANDLEBAR PARTS M6 x 16 Bolts 1. Attach bottom side of display console to the display console bracket using 2 - M6 x 16 bolts M6 x 16 Bolt M6 x 16 Bolt...

  • Page 6: Rear Wheel Installation

    REAR WHEEL INSTALLATION REAR WHEEL PARTS M20 Lock Washers M20 Castle Nuts Tires Large Washers Hub Caps Fill tires with 10 PSI of air before assembly. Install each wheel - ensure the tread faces forward and valve stems face out. Attach each wheel using large M20 Washer, M20 Lock Washer, and M20 Castle Nut Install Cotter Pin through axle end and bend over the ends.

  • Page 7: Front Wheel Installation

    FRONT WHEEL INSTALLATION FRONT WHEEL PARTS M10 Lock Nuts M10 Washers Tires Hub Caps Fill tires with 10 PSI of air before assembly. Install each wheel - ensure the tread faces forward and valve stems face out. Attach each wheel with M10 Washer followed by M10 Lock Nut.

  • Page 8: Front Bumper Installation

    FRONT BUMPER INSTALLATION BUMPER PARTS M8 x 20 Bolts Install front bumper to front frame with M8 x 20 Bolts M8 x 20 Bolts...

  • Page 9: Rear Carrier Installation

    REAR CARRIER INSTALLATION REAR CARRIER PARTS M8 Lock Nuts M8 x 16 Bolts Rear Carrier Support Install Rear Carrier Support with 4 - M8 x 16 bolts to the rear frame. Attach Rear Carrier to Rear Carrier Support with 2 - M8 x 16 bolts and 2 - M8 x 30 bolts. M8 x 16 Bolts M8 x 16 Bolts Rear Carrier...

  • Page 10: Battery Installation

    NOTICE Positive (+) cable is red in color. Negative (-) cable is black in color. This Coleman Powersports AT200 ATV has two positive (+) cables red in color. Both attach to the positive terminal on battery. WARNING Battery electrolyte is poisonous and dangerous, contains sulfuric acid, which can cause severe burns.

  • Page 11: Pre-Ride Inspection

    PRE-RIDE INSPECTION Inspecting and checking the WHAT TO CHECK FOR condition of the ATV before each CHECK ride is important. Following the • Smoothness Steering pre-ride checklist will help ensure • No restriction of that you do not have mechanical movement issues which could result in severe Brakes...
  • Page 12 WARNING NEVER ATTEMPT TO START THIS ATV WITHOUT READING AND UNDERSTANDING THE OWNER’S/ OPERATOR’S MANUAL. THE OWNER’S/ OPERATOR’S MANUAL PROVIDES INFORMATION ON SAFETY, PARTS, FUNCTIONS, PRE-RIDE INSPECTION, STARTING AND MAINTENANCE POWERSPORTS (888) 405-8725 1775 E. University Dr., Tempe, AZ 85281 www.colemanpowersportsusa.com www.facebook.com/colemanpowersportusa.com www.instagram.com/colemanpowersports_usa...
