Navigating the OZONE XLM Series Menu System
There are two aspects to the general Ozone XLM Series Menu system – the Timer Menu
and the Chlorine Output Menu.
Access the Ozone XLM Series Menu system by pressing the ENT button and following the
prompts on the LCD. If you find you have ended up in a part of the Menu system
unintentionally, you can return to the Home Screen by pressing the ESC/OFF button at any
time.
Use the Y/UP and N/DOWN buttons to scroll through the various menu options until the
desired option is displayed on the LCD. Use the ENT button to confirm that you wish to
select that option. Once accessed, use the Y/UP and N/DOWN buttons to adjust
operational settings up or down – and confirm adjustments by pressing ENT. To cancel
any adjustments, simply press ESC/OFF to return to the Home Screen.

Timer Menu

Setting the time
Once you have installed your Ozone XLM Series and turned it on, you will need to set the
correct time on the OZONE XLM SERIES Series' 24 hour clock.
First, access the Menu System by pressing the ENT button. The LCD will display the word
TIMER MENU. Select this by pressing the ENT button once more.
Line 2 on the LCD will now read SET TIME HOURS. Press ENT to select this option and
then use the Y/UP and N/DOWN buttons- to adjust the hours on the LCD. Confirm the
correct hours value by pressing ENT again.
The LCD will now show SET TIME MINUTES. Adjust the minutes using the Y/UP and
N/DOWN buttons. When complete, press ENT to return to normal operation.
Filter Cycles Menu
Your Ozone XLM Series has two filter cycles pre-programmed as factory defaults as
follows:
Filter Cycle 1:
Filter Cycle 2:
You can change the start and finish times of each filter cycle to meet your sanitiser
requirements and to suit your lifestyle.
To adjust filter cycle start and finish times, press ENT to access the Ozone XLM Series
Menu system. Press ENT again to select the TIMER menu and then scroll down using the
N/DOWN button until ADJUST CYCLES is displayed on the LCD.
ON at 07:00 (7am)
ON at 18:00 (6pm)
OFF at 11:00 (11am)
OFF at 22:00 (10pm)
