Navigating the Menu System

There are two aspects to the general Menu system – the Timer Menu and the Chlorine
Output Menu.
Access the Menu system by pressing the ENT button and following the prompts on the
LCD. If you find you have ended up in a part of the Menu system unintentionally, you can
return to the Home Screen by pressing the ESC/OFF button at any time.
Use the Y/UP and N/DOWN buttons to scroll through the various menu options until the
desired option is displayed on the LCD. Use the ENT button to confirm that you wish to
select that option.
Once accessed, use the Y/UP and N/DOWN buttons to adjust operational settings up or
down – and confirm adjustments by pressing ENT. To cancel any adjustments, simply
press ESC/OFF to return to the Home Screen.

Timer Menu

Setting the time
Once you have installed your Pool Controls chlorinator and turned it on, you will need to
check that the correct time is displayed on the LCD. You may need to adjust the factory
pre-set time.
To adjust the time, access the Menu System by pressing the ENT button. The LCD will
display the word TIMER MENU. Select this by pressing the ENT button once more.
Line 2 on the LCD will now read SET TIME HOURS. Press ENT to select this option and
then use the Y/UP and N/DOWN buttons- to adjust the hours on the LCD. Confirm the
correct hours value by pressing ENT again.
The LCD will now show SET TIME MINUTES. Adjust the minutes using the Y/UP and
N/DOWN buttons. When complete, press ENT to return to normal operation.
Filter Cycles Menu
Two filter cycles are pre-programmed as factory defaults as follows:
Filter Cycle 1:
Filter Cycle 2:
You can change the start and finish times of each filter cycle to meet your sanitiser
requirements and to suit your lifestyle.
To adjust filter cycle start and finish times, press ENT to access the Menu system. Press
ENT again to select the TIMER menu and then scroll down using the N/DOWN button until
ADJUST CYCLES is displayed on the LCD.
ON at 07:00 (7am)
ON at 18:00 (6pm)
OFF at 11:00 (11am)
OFF at 22:00 (10pm)
