- Page 1 SDM-1135G7L (MTGU5AL-SI) SDM-1115G4L (MTGU3AL-SI) Smart Display Module Series Quick Start Guide www.gigaipc.com...
-
Page 2: Copyright Notice
While reasonable efforts have been made in the preparation of this document to assure its accuracy, GIGAIPC assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. - Page 3 Core, Atom are trademarks of Intel Corporation • • ITE is a trademark of Integrated Technology Express, Inc. IBM, PC/AT, PS/2, and VGA are trademarks of International Business • Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com...
-
Page 4: Packing List
• To get installation instructions, please see P.24 Item Quantity DIMM2 PAD (P/N : 25ST3-200086-T5R) M.2 Standoff (P/N : 12KSF-F10303-20R) M.2 Screw (P/N: 25KSG-130048-S0R) M.2 Bracket (P/N: 25ST1-1231Z0-S7R) If any of these items are missing or damaged, please contact your distributor or sales representative immediately. www.gigaipc.com... -
Page 5: About This Document
(if any), its specifications, dimensions, jumper/ connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com... -
Page 6: Safety Precautions
Make sure the device is installed near a power outlet and is easily accessible. 10. Keep this device away from humidity. 11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat dissipation. www.gigaipc.com... - Page 7 18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com...
-
Page 8: Fcc Statement
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte. Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et les directives gouvernementales de recyclage. www.gigaipc.com... - Page 9 Chapter 2 – Hardware Information Jumpers and Connectors ..........16 2.2.1 TPM (Trusted Platform Module Connector) ....18 2.2.2 CPU_FAN (CPU Fan connector) ........19 2.2.3 BATTERY (Battery cable connector) ......20 Chapter 3 – SDM-L Installation Dimension ..............22 Installation ..............23 www.gigaipc.com...
- Page 10 www.gigaipc.com...
-
Page 11: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications www.gigaipc.com... - Page 12 www.gigaipc.com...
-
Page 13: Specifications
4096x2160 @60 Hz 4096x2160 @60 Hz (4 independent display outputs) (4 independent display outputs) Audio Intel® integrated Audio 1 x 2280 M.2 M-Key (PCIe x4, SATA 6Gb/s) Expansion Slots 1 x 2230 M.2 E-Key www.gigaipc.com... - Page 14 2 x Antenna(WiFi/BT)(Optional) 1 x Reset button 1 x Power button 1 x TPM header OS Compatibility Windows® 10 (x64) Operating temperature: 0°C to 55°C Operating Operating humidity: 0-90% (non-condensing) Properties Non-operating temperature: -40°C to 85°C Non-operating humidity: 0%-95% (non-condensing) www.gigaipc.com...
-
Page 15: Chapter 2 - Hardware Information
Chapter 2 Chapter 2 – Hardware Information www.gigaipc.com... -
Page 16: Jumpers And Connectors
Jumpers and Connectors 6 7 1 www.gigaipc.com... - Page 17 SODIMM_A 2 x DDR4 SO-DIMM sockets SODIMM_B 1 x 2280 M.2 M-Key (PCIe x4, SATA 6Gb/s) 1 x 2230 M.2 E-Key 1 x Trusted Platform Module Connector CPU_FAN 1 x CPU Fan connector BATTERY 1 x Battery cable connector www.gigaipc.com...
- Page 18 2.2.1 TPM (Trusted Platform Module Connector) Pin 1 TPM Connector Connector PN Vendor 87216-1004-06 ACES Pin No. Definition Clock SPI_CS TPM_SO RESET TPM_SI 3.3V www.gigaipc.com...
- Page 19 2.2.2 CPU_FAN (CPU Fan connector) Pin 1 CPU FAN Connector Connector PN Vendor 85205-0470N ACES KYOYAKU A1250WV-S-04PC JOINT-TECH Pin No. Definition Speed control Detect www.gigaipc.com...
- Page 20 2.2.3 BATTERY (Battery cable connector) Pin 1 Battery cable Connector Connector PN Vendor 85205-0270L ACES ACES A1250WV-S-02PC JOINT-TECH Pin No. Definition 3.3V RTC www.gigaipc.com...
-
Page 21: Chapter 3 - Sdm-L Installation
Chapter 3 Chapter 3 – SDM-L Installation www.gigaipc.com... - Page 22 Dimension www.gigaipc.com...
-
Page 23: Installation
Installation [SDM Install] ＊ The image is for reference only. The actual product could be slightly different. www.gigaipc.com... - Page 24 M.2 slot, and use the standoff which provided in the accessory kits to secure the M.2 SSD. Step 3. Step 4. Tighten up the screw which was Tighten up the screw which was previously removed. provided in the accessory kits on the bracket. www.gigaipc.com...
