Page 1: Com Express Module
CE6-6412A COM Express Module www.gigaipc.com... -
Page 2: Copyright Notice
While reasonable efforts have been made in the preparation of this document to assure its accuracy, GIGAIPC assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. -
Page 3: Acknowledgement
Core, Atom are trademarks of Intel Corporation ITE is a trademark of Integrated Technology Express, Inc. • • IBM, PC/AT, PS/2, and VGA are trademarks of International Business Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com... -
Page 4: Packing List
Packing List Before setting up your product, please make sure the following items have been shipped: Item Quantity CE6-6412A MB If any of these items are missing or damaged, please contact your distributor or sales representative immediately. www.gigaipc.com... -
Page 5: About This Document
(if any), its specifications, dimensions, jumper/ connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com... -
Page 6: Safety Precautions
Make sure the device is installed near a power outlet and is easily accessible. 10. Keep this device away from humidity. 11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat dissipation. www.gigaipc.com... - Page 7 18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com...
-
Page 8: Fcc Statement
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte. Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et les directives gouvernementales de recyclage. www.gigaipc.com... -
Page 9: China Rohs Requirements (Cn)
China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 GIGAIPC Main Board/ Daughter Board/ Backplane 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 及其电 ○ ○ ○ ○ ○ ○ 子组件 外部信号 连接器 ○ ○ ○ ○... -
Page 10: China Rohs Requirement (En)
China RoHS Requirement (EN) Poisonous or Hazardous Substances or Elements in Products GIGAIPC Main Board/ Daughter Board/ Backplane Poisonous or Hazardous Substances or Elements Component Hexavalent Polybrominated Polybrominated Lead Mercury Cadmium Chromium Biphenyls Diphenyl Ethers (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB &... -
Page 11: Table Of Contents
COM Express connector ROW A/B ....... 22 2.2.2 COM Express connector ROW C/D ....... 26 Chapter 3 – BIOS Introduction ..............31 The Main Menu............. 32 Advanced ..............33 3.3.1 TPM Configuration ............34 3.3.2 S5 RTC Wake Settings ........... 36 www.gigaipc.com... - Page 12 CPU Configuration ............37 3.3.4 SATA Configuration ............38 3.3.5 Hardware Monitor ............39 3.3.6 AMI Graphic Output Protocol Policy ......40 3.3.7 Network Stack Configuration .........41 Chipset ................42 Security ................. 43 Boot ................46 Save & Exit ..............47 www.gigaipc.com...
-
Page 13: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications www.gigaipc.com... - Page 14 16.46 95.00 www.gigaipc.com...
-
Page 15: Specifications
Specifications COM Express CE6-6412A module (MEHLJAC) COM Express® R3.0 Compact Module, Type 6 Form Factor 95W x 95D (mm) Intel® Celeron® J6412 Processor 10nm, 4 cores, 4 threads, up to 2.60 GHz TDP 10W Socket 1 x FCBGA 1493 2 x DDR4 SO-DIMM sockets, Max. Capacity 32 GB... - Page 16 COM Express CE6-6412A module (MEHLJAC) Operating temperature: 0°C to 60°C Operating Operating humidity: 0-90% (non-condensing) Properties Non-operating temperature: -40°C to 85°C Non-operating humidity: 0%-95% (non-condensing) www.gigaipc.com...
-
Page 17: Chapter 2 - Hardware Information
Chapter 2 Chapter 2 – Hardware Information www.gigaipc.com... -
Page 18: Dimensions
Dimensions 16.46 95.00 www.gigaipc.com www.gigaipc.com... - Page 19 COM Express module with Heat spreader 18.66 95.00 2.0T www.gigaipc.com...
- Page 20 COM Express module with Heat sink 34.50 95.00 2.0T www.gigaipc.com...
-
Page 21: Jumpers And Connectors
Jumpers and Connectors Code Description SODIMMA DDR4 SO-DIMM Socket SODIMMB DDR4 SO-DIMM Socket COM Express connector ROW A/B CEP_M COM Express connector ROW C/D www.gigaipc.com www.gigaipc.com... -
Page 22: Com Express Connector Row A/B
Pin No. Definition Pin No. Definition GND (FIXED) GND (FIXED) ESPI_CS#_R ESPI_IO0_R ESPI_IO1_R ESPI_IO2_R ESPI_IO3_R ESPI_CLK_R GND (FIXED) GND (FIXED) PANSHW SMB_CK SMB_DATA PCH_SLP_S3# SMB_ALERT_n SATAIII_TX0p SATA_M.2_SSD_SLOT1_TX_Dp SATAIII_TX0n SATA_M.2_SSD_SLOT1_TX_Dn PCH_SLP_S4# ESPI_RST#_R SATAIII_RX0p SATA_M.2_SSD_SLOT1_RX_Dp SATAIII_RX0n SATA_M.2_SSD_SLOT1_RX_Dn GND (FIXED) GND (FIXED) www.gigaipc.com... - Page 23 USBP2p USBP3p USB_OC2 USB_OC0 USBP0n USBP1n USBP0p USBP1p 3.3A_RTC SYS_RESET# PCIRST1# GND (FIXED) GND (FIXED) PWR LED M2E_WIFI_RF_KILL_R_N M.2_WLAN_TX_Dp M.2_LAN_RX_Dp M.2_WLAN_TX_Dn M.2_LAN_RX_Dn MPCIE_W_DISABLE LAN2_TXp_S LAN2_RXp_H LAN2_TXn_S LAN2_RXn_H GND (FIXED) GND (FIXED) LAN1_TXp_S LAN1_RXp_H LAN1_TXn_S LAN1_RXn_H PS_ON 5VSB_CTRL PCIE1_TX_Dp PCIE1_RX_Dp www.gigaipc.com...
- Page 24 LVDS_RST 5VSB SPI_TPM_PIRQ_LT_R 5VSB eDP_HPD 5VSB CLK_100M_9ZXL831_Dp CLK_100M_9ZXL831_Dn GND (FIXED) GND (FIXED) SPI_SO_OUT M2E_BT_RF_KILL_N SPI_CLK_OUT SPI_SI_IN SPI_CS#2_OUT A100 GND (FIXED) B100 GND (FIXED) A101 B101 FAN_PWM4 A102 B102 FANIO4 A103 B103 A104 ATX_12V B104 ATX_12V A105 ATX_12V B105 ATX_12V www.gigaipc.com...
- Page 25 Pin No. Definition Pin No. Definition A106 ATX_12V B106 ATX_12V A107 ATX_12V B107 ATX_12V A108 ATC_12V B108 ATX_12V A109 ATX_12V B109 ATX_12V A110 GND (FIXED) B110 GND (FIXED) www.gigaipc.com...
-
Page 26: Com Express Connector Row C/D
COM Express connector ROW C/D Pin No. Definition Pin No. Definition GND (FIXED) GND (FIXED) USB3_RN0 USB3_TN0 USB3_RP0 USB3_TP0 USB3_RN1 USB3_TN1 USB3_RP1 USB3_TP1 USB3_RN2 USB3_TN2 USB3_RP2 USB3_TP2 GND (FIXED) GND (FIXED) DDI0_AUXP DDI0_AUXN PCIE6_MPCIE_RX_DP PCIE6_MPCIE_TX_DP PCIE6_MPCIE_RX_DN PCIE6_MPCIE_TX_DN GND (FIXED) GND (FIXED) www.gigaipc.com... - Page 27 GND (FIXED) DDI1_DDC_SCL DDI0_TX2_DP DDI1_DDC_SDA DDI0_TX2_DN DDI2_DDC_SCL DDI0_TX3_DP DDI2_DDC_SDA DDI0_TX3_DN DDI2_TX0_DP DDI1_TX0_DP DDI2_TX0_DN DDI1_TX0_DN GND (FIXED) GND (FIXED) DDI2_TX1_DP DDI1_TX1_DP DDI2_TX1_DN DDI1_TX1_DN DDI2_HPD DDI1_HPD DDI2_TX2_DP DDI1_TX2_DP DDI2_TX2_DN DDI1_TX2_DN DDI2_TX3_DP DDI1_TX3_DP DDI2_TX3_DN DDI1_TX3_DN GND (FIXED) GND (FIXED) GND (FIXED) GND (FIXED) www.gigaipc.com...
- Page 28 Pin No. Definition Pin No. Definition GND (FIXED) GND (FIXED) GND (FIXED) GND (FIXED) GND (FIXED) GND (FIXED) C100 GND (FIXED) D100 GND (FIXED) C101 D101 C102 D102 C103 D103 C104 ATX_12V D104 ATX_12V C105 ATX_12V D105 ATX_12V www.gigaipc.com...
- Page 29 Pin No. Definition Pin No. Definition C106 ATX_12V D106 ATX_12V C107 ATX_12V D107 ATX_12V C108 ATX_12V D108 ATX_12V C109 ATX_12V D109 ATX_12V C110 GND (FIXED) D110 GND (FIXED) www.gigaipc.com...
-
Page 30: Chapter 3 - Bios
Chapter 3 Chapter 3 – BIOS www.gigaipc.com... -
Page 31: Introduction
Execute command or enter the submenu Increase the numeric value or make ＋ changes Decrease the numeric value or make – changes General Help Previous Values Load Optimized Defaults Settings Save changes & Exit the BIOS Setup program Exit the BIOS Setup program www.gigaipc.com... -
Page 32: The Main Menu
ME FW version Shows ME firmware version Set the Date for the system System Date (Format : Week - Month - Day - Year) Set the time for the system System Time (Format : Hour - Minute - Second) www.gigaipc.com... -
Page 33: Advanced
Advanced The Advanced menu is to configure the functions of hardware settings through submenu. Use arrow keys to move among the items, and press <Enter> to access into the related submenu. www.gigaipc.com... -
Page 34: Tpm Configuration
3.3.1 TPM Configuration Use TPM Configuration submenu to choose TPM interface. Item Description PTT : Internal TPM TPM Device dTPM : External TPM (When using External TPM module or Selection having TPM chip on MB) (Default setting) www.gigaipc.com... - Page 35 Item Description Security Device Enabled : Enables TPM feature (Default setting) support Disabled : Disables TPM feature None : No execution will be conducted (Default setting) Pending operation TPM clear : Set to clear data on TPM www.gigaipc.com...
-
Page 36: S5 Rtc Wake Settings
Enable or Disable System to wake on a specific time. Wake system Disabled : Disables system to wake on a specific time (Default setting) from S5 Fixed Time : Enables system to wake on a specific time (Format : hr : min : sec) www.gigaipc.com... -
Page 37: Cpu Configuration
Enabled : Enables C states (Default setting) Disabled : Disables C states CPU will adjust frequency depends on it's loading. CPU P states Enabled : Enables CPU P states function (Default setting) Disabled : Disables CPU P states function www.gigaipc.com... -
Page 38: Sata Configuration
3.3.4 SATA Configuration Item Description SATA Mode AHCI : Configures the SATA controllers to AHCI mode. (Default setting) Selection Serial ATA Port 0 shows 2.5" SATA HDD/SSD information M.2 Port shows M.2 SATA interface SSD information www.gigaipc.com... -
Page 39: Hardware Monitor
Normal : Fan speed set by BIOS default (Default setting) Control Full Speed : Set Fan operates at full speed CPU Temperature Shows current CPU temperature System Shows current system temperature Temperature SYS Fan Speed Shows current System fan Speed www.gigaipc.com... -
Page 40: Ami Graphic Output Protocol Policy
3.3.6 AMI Graphic Output Protocol Policy Item Description Choose default monitor output when there are more than one monitor plugged Output Select on the motherboard. www.gigaipc.com... -
Page 41: Network Stack Configuration
IPv4 PXE Support Disabled : Disables IPv4 PXE Support Enabled : Enables IPv4 PXE Support (Default setting) When Network stack is enabled : IPv6 PXE Support Disabled : Disables IPv6 PXE Support Enabled : Enables IPv6 PXE Support (Default setting) www.gigaipc.com... -
Page 42: Chipset
To modified the backlight brightness of the LVDS panel Brightness Level Option items : 10%, 20%, 30%, 40%, 50%, 60%, 70%, 80%, 90%, 100% (Default Setting) Enable/Disable BIOS Lock function BIOS Lock Enabled : Enables BIOS Lock function (Default setting) Disabled : Disabled BIOS Lock funtion www.gigaipc.com... -
Page 43: Security
To set up Administrator's password Administrator Minimum length : 3 Password Maximum length : 20 To set up User's password User Password Minimum length : 3 Maximum length : 20 Secure Boot Press <Enter> to configure the advanced items www.gigaipc.com... - Page 44 No : Cancel to restore factory settings Reset To Setup Yes : Agree to setup mode Mode No : Cancel to setup mode Enables expert users to modify Secure boot policy variables without full Key Management authentication Press <Enter> to configure the advanced items www.gigaipc.com...
- Page 45 'UEFI CA' from database from DB No : Cancel to remove 'UEFI CA' from database Restore DB variables to fac tor y Restore DB defaults defaults Yes : Agree to restore DB defaults No : Cancel to restore DB defaults www.gigaipc.com...
-
Page 46: Boot
Enabled : Enables Full screen LOGO Show on POST screen LOGO Show Disabled : Disables Full screen LOGO Show on POST screen (Default setting) Shows the information of the storage that be installed in the system Boot Option #1 Choose/set the boot priority www.gigaipc.com... -
Page 47: Save & Exit
Yes : Agree to load optimized defaults No : Cancel to load optimized defaults Enable/Disable Me FW image re-flash function Me FW Image Enabled : Enables Me FW image re-flash function Re-Flash Disabled : Disables Me FW image re-flash function (Default setting) www.gigaipc.com...
