Sunshine HORIZON 4600 Assembly, Operation And Maintenance Instructions

Advertisement

CE845
Made In China For
ARLEC BARBEQUES PTY LTD
274 Maroondah Hwy
Mooroolbark, VIC 3138
Australia
! "
#$
%
! &
$ $
' !
(! &
!
!
!
!
)%
! '
Retain These Instructions For Future Use
Ver.2.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HORIZON 4600 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sunshine HORIZON 4600

  • Page 1 CE845 Made In China For ARLEC BARBEQUES PTY LTD 274 Maroondah Hwy Mooroolbark, VIC 3138 Australia ! " ! & (! & Retain These Instructions For Future Use Ver.2.0...
  • Page 2: Safety Precaution

    SAFETY PRECAUTION • This grill is designed for outdoor use only THIS APPLIANCE SHALL NOT BE INSTALLED OR USED INDOORS. • The area surrounding your new grill should be kept clean, and free from flammable liquids and other combustible materials such as mops, rags, brooms, as well as solvents, cleaning fluids, and gasoline.
  • Page 3 All gas fitting work, service and repairs (including works on any part of the gas circuit) can only be performed by an authorized gas fitter in accordance with national regulations. All replacement parts must meet Sunshine specification. GAS TYPES The barbecues are both category I3+(28-30/37) and I3B/P(30) appliances.
  • Page 4: Assembly Instruction

    ASSEMBLY INSTRUCTION Inspect all components for damage before assembly begins. If damage is present please contact your local dealer. Replace the damaged components with original manufacturers’ parts only. The cart panel, door, condiment assembly and main BBQ body have been pre assembled for convenience and ease of assembly.
  • Page 5 Step 4 Attach the horizontal support rail to the front legs. Then align the holes on both ends of the support rail with the threaded holes on the legs. Tighten with two M5 screws. Step 5 Insert four M5 screws into the LH and RH rear legs with hand tighten.
  • Page 6 Step 8 Place condiment shelf assembly in front of the trolley right hand panel, ensure that the condiment shelf handle are on top position. Slide the bracket located at the back of condiment shelf assembly onto the RH stud on trolley right hand panel as illustrated. Step 9 Place front trimming infront of RH and LH trolley assembly.
  • Page 7 Step 11 Attach RH side burner assembly to RH cart assembly, slide RH side burner assembly onto front/rear legs of the RH frame with downward pressure as shown. Tighten with 2 bolts and nuts only to the outsides holes only. Step 12 Attached cylinder hook under RH panel bar.
  • Page 8 Step 14 Place the grill plate flame tamers on right lower level of bbq body assembly directly above burners between the location tabs on the bbq chassis. Step 15 Insert the warming rack and place cast iron grill plate directly above flame tamers and hot plate on support ribs as illustrated.
  • Page 9: Gas Supply Cylinder

    There are no user serviceable parts for this LED unit. Do not attempt any repairs yourself, doing so will void the manufactures warranty. In the unlikely event, your unit may require service. Please contact your nearest Arlec Sunshine Barbecue dealer. • Do not modify the circuit. This circuit is already optimized and confirmed by tests and by measurements.
  • Page 10: Connecting The Gas Supply

    SUPPLY HOSE A hose conforming to the national standard must be connected at one end to the regulator outlet and at the other to the barbecue inlet nipple using hose clips. The hose length must not exceed 1.5 m. CONNECTING THE GAS SUPPLY Screw the female flared fitting of the hose and regulator onto the bbq inlet fitting at one side and side burner inlet fitting on the other side, tighten using two adjustable wrenches.
  • Page 11: Lighting Instructions

    find any leaks, tighten the connection. If the leaks persist, contact an authorized agent. DO NOT USE NAKED FLAME FOR LOCATING GAS LEAKS. IF A LEAK PERSIST, CALL AN AUTHORISED GAS FITTER. DO NOT USE APPLIANCE UNTILL ALL LEAKS ARE CORRECTED. LIGHTING INSTRUCTIONS Please read the SAFETY PRECAUTIONS section in this manual before you start the unit for the first time or when the gas supply has been turned off or...
  • Page 12: Temperature Setting

    TEMPERATURE SETTING: The temperature settings on this barbecue are labeled high (or ON) to low flame and the control knob can be set any where in this temperature range on all burners. To pre-heat this unit, close the lid and monitor the thermometer located on the lid.
  • Page 13 INJECTORS / MAIN BURNER ORIFICES: Injectors should be inspected on a regular basis to ensure they are not blocked. Cleaning can be performed on these injectors by removing the injector from the valve assembly. Using a very small wire or a small pipe cleaner could also be used. STAINLESS STEEL PANELS: Stainless steel is a very durable material and should last indefinitely with minimal care.
  • Page 14: Troubleshooting

    TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Electrode fouled Wipe the electrode with a soft clean cloth. Electrode improperly gapped The electrode should be 3 mm to 5 mm away from the burner tube and if the positioned close to the gas ports. Gently bend the electrode tip into position.
  • Page 15 Blockage in the burner or Check to ensure no insects or blocking gas system the venture tubes. Use a special venture brush to clean. UNEVEN Use a pin or a toothpick to clean the BURN orifice on the gas valve. DO NOT PATTERN ENLARGE THE HOLE.
  • Page 16: Parts Identification

    PARTS IDENTIFICATION NB: Item 17a or 17b varies depending on BBQ model...
  • Page 17: Replacement Parts

    Note : Use only original parts. This will protect your warranty coverage for parts replaced under warranty. Parts Under Warranty Contact authorized dealer from whom you purchased this product, call Sunshine Lifestyle Products Ltd for referral information. European Distributor: Sunshine Lifestyle Products Ltd Unit 9, Oxonian Park...

This manual is also suitable for:

Horizon 4700
