Sunshine PA4ST-SB Owner's Manual

Outdoor gas barbecue 4 burner with side burner
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLER: These instructions must be left with the consumer.
CONSUMER: Retain these instructions for future use.
Please read and understand the contents of this manual fully before operating the barbecue.
Failure to do so and follow the instructions could result in fire or explosion.
FOR YOUR SAFETY
If you smell gas:
1 Shut off gas to the appliance at the
cylinder.
2 Extinguish any open flame
3 Remove weather cover
4 If odour continues, immediately call
your gas supplier or your fire
department.
1/04 Revision 1.2
OUTDOOR GAS BARBECUE
OWNER'S MANUAL
Installation, Operation, and Maintenance
WARNING
0048
MODEL
PA4ST-SB
4 BURNER
BBQ WITH
SIDE BURNER
FOR YOUR SAFETY
1 Do Not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other
appliance.
2 An LP Cylinder not connected for
use shall not be stored in the vicinity
of this or any other appliance.
PMA 0481 GB/IE
