Behringer UW300 User Manual

Thank you for showing your confidence in us by purchasing the BEHRINGER ULTRA
WAH UW300. This high-quality effects pedal delivers auto-wah effects for almost all
styles and sounds. Control the wah effect with your string-picking strength and add an
awesome funky touch with the modulation wah pedal.
The RATE control determines the speed of the wah effect modulation.
The DEPTH control adjusts the sweep range of the effect. Turn it to the right to
increase the range. At minimum position no modulation effect is produced and the
wah effect is controlled by your playing intensity only. In this case the RATE control
has no function.
The MANUAL control adjusts the basic frequency where the effect starts working.
High MANUAL settings will decrease the sweep range, because the low end of the
frequency sweep is moved upwards.
The SENS control adjusts the sensitivity of the effect. Nearer maximum position
you achieve wah effect even with soft playing, nearer minimum position the wah
effect will not be dependent on your playing dynamics.
The ON/BATT LED illuminates when the effect is activated. It also serves as a
battery level indicator.
Use the footswitch to activate/deactivate the effect.
Use this 1/4" TS IN connector to plug in the instrument cable.
The 1/4" TS OUT connector sends the signal to your amp.
Use the DC IN connection of the unit to plug in a 9 V power supply (not included).
The BATTERY COMPARTMENT is located underneath the pedal cover. To install or
replace the 9 V battery (not included), press the hinges with a ballpoint pen and remove
the pedal cover. Be careful not to scratch the unit.
The UW300 has no on/off switch. As soon as you insert the plug into the IN
connector, the UW300 is on. When not in use, remove the plug from the IN
connector. This extends the life of the battery.
ULTRA WAH UW300
1. CONTROLS
Top view
