Control via DMX

•
Channel
1 (0-255)
2 (128)
3 (0-128-255)
4 (0-128)

Disassembling the system

•
Vent the tank using Channel 24 after the last ignition, or ignite channel 17. Repeat at least 3 times.
After disconnecting the hose, E should be pressed to disarm the device, and vent it.
6
•

Technical Data

Power Supply:
Size:
Weight:
Gas connector:
•

Safety Notes

The device may only be used when it is in usable and well kept condition. Defective devices must be
checked and repaired by the manufacturer, or qualified personnel. Uner no circumstances may
defective devices be used. The devices should be placed on solid, even ground, in a horizontal
position.
The safety distances mentioned in the manual are to be adhered.
All persons taking part in the gasprojector show (eg. Actors, set up helpers,..) are to be informed
about the safety distances, hazards, and the general functions of the gasprojector.
The person in charge of controling the projector, should always have clear line of sight to the devices.
Either directly, or by camera. This person is in charge of taking heed of the safety distances during
the show, and interrupt the show immediately, in case of danger.
Before usage, the system should be checked for leak tightness, to prevent an unwanted escape of
gas. Should gas leak from the system, all safety valves must be closed, and the hazardous area be
evacuated.
VENT (Careful, the gas will not be ignited)
STOP recharge routine
START recharge routine
Ignition ≤ 253 = no ignition
254 and 255 = Ignition
Opening time 0 = 0,5 sec
255 = 2,5 sec
Status 0-84 = Pilot flame
85-170 = Power Flame with recharge
171-255 = Power Flame without recharging
Mode <50 = Test
50-200 = Armed
> 200 = Test
230VAC / max. 100W
410x410x550mm
ca. 12kg
Euro-Norm, 30mm Wrench width
Function
