2000 MOBILE ES PRODUCT GUIDE
Amplifiers
• 75 W x 2 (4 ohm) at 0.04% THD (14.4 V)
• 150 W x 2 at 2 ohm (14.4 V)
• 300 W x 1 (4 ohm) (14.4V)
• Non-Negative Feedback Design
• High Current MOSFET Output Stage
Specifications
Circuit System
Inputs
Outputs
Speaker Impedance
(*
Hi-current mode)
Rated Outputs
(at 14.4 VDC, NFB on)
(Hi-Current /Hi-Voltage)
(Hi-Current)
Maximum Output
(Hi-Current /Hi-Voltage)
Frequency Response
Harmonic Distortion
Input Level Adjustment Range
High-Pass Filter
Low-Pass Filter
Low Boost & Cut
Power Requirements
Power Supply Voltage
Current Drain
Dimensions (w/h/d)
Weight
Supplied Accessories
26
XM-7527
2/1 Channel Amplifier
Pure Direct Drive SEPP
Pulse Power Supply
RCA Pin Jacks
Speaker Terminals
0.5*-8 Ω (stereo)
1*-8 Ω (when used as bridging amplifier)
35.7/75 W x 2 (20-20,000 Hz, 0.04% THD, at 4 Ω)
75/150 W x 2 (20-20,000 Hz, 0.10% THD, at 2 Ω)
150/300 W x 1 (20-20,000 Hz, 0.10% THD, at 4 Ω)
150 W x 2 (20-20,000 Hz, 0.3% THD, at 1 Ω)
180 W x 2 (20-20,000 Hz, 0.3% THD, at 0.5 Ω)
300 W x 1 (20-20,000 Hz, 0.10% THD, at 2 Ω)
360 W x 1 (20-20,000 Hz, 0.3% THD, at 1 Ω)
90/180 W x 2 (at 4 ohms)
180/300 W x 2 (at 2 ohms)
360/600 W x 1 (at 4 ohms)
5 Hz-100 Hz (+0/-3 dB)
0.005% or less (at 1 kHz, 4 ohms)
0.2-4.0 V
50-200 Hz, -12 dB/oct
50-200 Hz, -12 dB/oct
0-10dB (7-40Hz)
12 V DC Car Battery (negative ground)
10.5-16 V
At Rated Output: 23 A (4 ohms, Hi-Voltage), 58 A (4 ohms, Hi-Current); Remote Input: 1.6 mA
Approx. 321 x 84 x 287mm (315 w/cover)/(12
Approx. 5 kg (11 lb.)
Mounting Screws (4), Terminal Protect Cover (1), 3mm Hex Wrench (1)
Design and specifications subject to change without notice.
• 0.5 ohm Drive Capability
• MOSFET Switching Power Supply
• Dual Mode Mono/Stereo
• 50-200 Hz LP Filter, 50-200 Hz HP Filter
• 7-40 Hz Low Frequency Boost/Cut
5
/
x 3
5
/
x 11
1
/
8
16
4
in.) (12
3
/
in. w/cover)
8
