Sony XM-604EQX Marketing Specifications Specifications

2000 MOBILE PRODUCT GUIDE – PART 2
• 60 W x 4 Ch at 0.04% THD
• 60 W x 2 + 150 W x1 at 0.1% THD
• 150 W x 2 at 0.1% THD
• RCA and Speaker Level Inputs
• Regulated MOSFET Power Supply
Specifications
Circuit System
Inputs
Outputs
Speaker Impedance
Rated Outputs (at 14.4 VDC)
Maximum Output
Equalizer
Frequency Response
Harmonic Distortion
Input Level Adjustment Range
High-Pass Filter
Low-Pass Filter
Power Requirements
Power Supply Voltage
Current Drain
Dimensions (w/h/d)
Weight
Supplied Accessories
16
XM-604EQX
4/3/2 Channel Amplifier/EQ
OTL (output transformerless) Circuit
Pulse Power Supply
RCA Pin Jacks
High Level Input Connector
Speaker Terminals
2-8 ohms (stereo)
4-8 ohms (when used as bridging amplifier)
60 W x 4 (20-20 kHz, 0.04% THD, at 4 Ω )
75 W x 4 (20-20 kHz, 0.1% THD, at 2 Ω )
150 W x 2 (20-20 kHz, 0.1% THD, at 4 Ω )
120 W x 4 (at 4 Ω)
120 W x 2 + 300 W x 1 (at 4 Ω)
300 W x 2 (at 4 Ω)
50 Hz, 200 Hz, 800 Hz, 3.2 kHz, 12.8 kHz ±12 dB
5-100 Hz (+0/-3 dB)
0.005% or less (at 1 kHz, 4 Ω)
0.2-4.0 V (RCA pin jack); 0.4-8.0 V (high level input)
50-200 Hz, -12 dB/oct
50-200 Hz, -12 dB/oct
12 V DC Car Battery (negative ground)
10.5-16 V
At Rated Output: 36 A
Remote Input:1.5 mA
Approx. 282 x 55 x 320 mm (11
(not including projecting parts and controls)
Approx. 3.3 kg (7 lb. 4 oz.) (not including accessories)
Mounting Screws (4); Terminal Cap (1)
Design and specifications subject to change without notice.
• F&R 5 Band +/-12 dB Adjustable EQ
• 50/200/800/3.2k/12.8 kHz Frequency Centers
• Variable 50-200 Hz Hi-Pass/Lo-Pass Filter
• Recessed Controls w/Level LEDs
• Heavy-Duty Connectors
/ x 2 / x 12 / in.)
1 1 5
8 4 8
