Behringer PHASER PH9 User Manual

Thank you for showing your confidence in us by purchasing the BEHRINGER PHASER PH9. This
ultimate effects pedal is designed for all musicians longing for a way to pep up their sound.
Thanks to its high-performance features, you can create phase-shifting effects with different
characteristics ranging from modern to vintage.
With the phaser, a second phase-shifted signal is added to the original audio of your instrument.
The resulting sound is thicker and above all livelier. Nowadays, this effect is often used for guitar
sounds and keyboards, but it was also extensively used for other instruments like electric
pianos in the '70s.
The RATE control determines the speed of the phase-shifting effect, in other words the
overall effect rate.
The SWIRL switch changes the phaser character from modern (upper position) to vintage
(lower position).
The LED illuminates when the effect is activated. It also serves as a battery level indicator.
Depress the footswitch to activate/deactivate the effect.
Use this 1/4" TS IN connector to plug in the instrument cable.
The 1/4" TS OUT connector sends the signal to your amp.
Use the DC IN connection to plug in a 9 V power supply (not included).
To install or replace the 9 V battery, remove the bottom side of the unit taking the four screws off.
The PH9 has no on/off switch. As soon as you connect the jack to the IN connector,
the PH9 is switched on. When the PH9 is not being used, remove the jack from
the IN connector to extend the battery life.
The SERIAL NUMBER is located on the bottom side of the device.
For our current warranty terms, please refer to our website at http://www.behringer.com.
PHASER PH9

1. CONTROLS

Top view

2. WARRANTY
