Sierra Designs Sweet Suite 2/3 Quick Start Manual

SWEET SUITE 2/3
PITCHING INSTRUCTIONS
Congratulations on the purchase of your new Sierra Designs tent! In order to familiarize yourself with your new tent, we
recommend you "test pitch" it before embarking on your wilderness adventure.
PACKAGE INCLUDES: Tent Body, Rain Fly, 2 Poles, Guy Cords, FL-stakes, Storage Bag, and Pole bag with stake pocket.
STEP 1: Find an even piece of ground; be sure the area is clear of
debris. Lay out your tent as shown. Stake the 4 corners (circled).
STEP 3: Connect Tent Lite hooks to poles. Attached yellow ridge
pole to Ball Cap Connectors.
STEP 5: On the under side of the fy, Clip the SQ Rings to the Ball
Cap Connector & wrap the 4 Velcro loops to the tent poles.
NOTE: this will ensure proper fy tensioning.
SQ Ring
Velcro Loop
Ridge Pole
Ball Cap Connector
T ent Lite Hook
STEP 2: Assemble the "X" pole. Locate the YELLOW pole ends and
insert into the corners with YELLOW SD Anchors/webbing.
Yellow Pole
Yellow
webbing & SD
Anchor
STEP 4: Lay the rain fy over the tent body matching the RED corner
of the tent with the RED corner on the fy.
Match RED
with RED corner
of tent body.
STEP 6:
Attach fy cord loop around pole tip
on all corners. Adjust tension by pulling
down on String Lock cord. Stake out
vestibules and your tent is fully set up!
Pull down String Lock cord to tighten
Attach fy cord loop around pole tip
