ESPO PATH SLIDE PRINTER Instruction Manual page 34

Cleaning of platen roller (indication of cleaning: after the operation is terminated)
Open upper cover and front cover.
Disconnect the connector and pull out the
transfer unit.
(1)
(2)
While the lock nail is pushed toward (1), pull
out the connector downward (2).
Remove the taint attached to the platen roller
using an air blow etc.
Platen roller
Clean up the whole circumference of platen
roller while rotating it.
Air blow
Clean up the platen roller using a waste
cloth impregnated with dehydrated ethanol.
Clean up the whole circumference of platen roller
while rotating it.
34
