Troubleshooting

[1] Description of error or alarm and coping process
Indication
Ribbon end
Glass empty
Head break
Jam error
Head position error
Cover open
Magazine holder
switching error
[2] Coping process when a slide glass is clogged
in the printer
If a slide glass is clogged during transfer, turn
OFF the power supply and remove the glass.
Open the upper cover and check the point
where the glass is clogged.
The front cover can be opened by pressing
the front cover unlock lever.
Description
The ribbon runs short.
The magazine runs short of slide
glass.
The thermal head is damaged.
The slide glasses
transferred normally.
Up/down movement of head is
abnormal.
Upper cover or front cover is opened.
The magazine holder cannot be
switched.
Change the ribbon.
Replace the magazine to the magazine
in which slide glasses are set.
Change the thermal head.
are not
Remove the clogging of slide glass.
It is necessary to carry out adjustment or
replacement etc. Contact the maintainer.
Close upper cover or front cover.
It is necessary to carry out adjustment or
replacement etc. Contact the maintainer.
OFF
Unlock lever
30
Coping process
