Names and functions

(1)
No Name
(1) Power switch
Liquid crystal display /
(2)
operation section
(3) Dust tray
(4) Upper cover
(5) Power connector
(6) LAN connector
(7) USB connector
(8) Wireless LAN antenna
(9) USB A connector
(10) Cable clamp
(3) (4)
(2)
Power switch of main unit
Status display and change of setting can be
implemented from touch panel liquid crystal display
Removable tray for collecting the dust removed from
frost surface
Cover to be opened when accessing the inside of
device. Ink ribbon and slide glass are set from here.
Insert the jack from AC adapter.
Connector of wireless LAN
USB connector
Antenna for wireless LAN
Connect the USB memory at the connection of optional
barcode scanner or download of firmware
Clamp that prevents disconnection of power supply and
I/F cable
12
(10)
(5) (6) (7)
Function
(8) (9)
