UI MultiAdjust User Guide. iss1 07/21
UI
MultiAdjust Quick User Guide
The MultiAdjust is an adaptable chair designed for
individuals who require a combination of comfort, function,
postural support and pressure care. This chair can be used
in multi-user environments or for individual users due to its
adjustability and range of accessories.
WARNING
A level of supervision appropriate to the user's abilities should be
applied at all times.
Class 1
Medical Device

Advertisement

loading
Need help?

Need help?

Do you have a question about the MultiAdjust and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CareFlex MultiAdjust

Summary of Contents for CareFlex MultiAdjust

  • Page 1 UI MultiAdjust User Guide. iss1 07/21 MultiAdjust Quick User Guide The MultiAdjust is an adaptable chair designed for individuals who require a combination of comfort, function, postural support and pressure care. This chair can be used in multi-user environments or for individual users due to its adjustability and range of accessories.
  • Page 2 UI MultiAdjust User Guide. iss1 07/21 The MultiAdjust Chair Most adjustments on the MultiAdjust can be made quickly and easily using no tools. When set up correctly the MultiAdjust should: • Support the user in a comfortable position. • Promote the user’s functional ability.

  • Page 3: Tilt-In-Space

    UI MultiAdjust User Guide. iss1 07/21 1. Brakes • To locate the brakes, push the chair forward so that the rear and front castors swing around and the brakes can easily be accessed. • Use the foot to press down on the end of the blue brake lever to lock the castors.

  • Page 4: Seat Depth

    UI MultiAdjust User Guide. iss1 07/21 4. Back Angle Recline* Back Angle Recline (BAR) can be used to adjust the angle between the seat and back, thus changing the angle of the user’s hips. When the back is fully upright, the user’s hip angles will be approximately 95°;...

  • Page 5: Seat Width

    To increase seat width, move the arm rests outwards by placing the palm of the hand on the The MultiAdjust has a width size guide inside face of the arm rest and push. on each arm to assist with adjustments.
  • Page 6 UI MultiAdjust User Guide. iss1 07/21 8. Leg Rest Elevation The leg rest can be elevated to promote comfort during periods of rest, or to achieve a change of position: • Locate lever at the right-hand side of the leg rest.
  • Page 7 Footplates are important for the user’s comfort, postural stability and pressure distribution. The MultiAdjust footplate is also suitable for users with a longer lower leg length. The footplate is fixed into a bracket on the back of the leg rest. To insert and adjust the footplate height: •...
  • Page 8 UI MultiAdjust User Guide. iss1 07/21 12. Pelvic Belt* (Optional) Pelvic belt length is adjusted by the two part buckle and a ‘tri-glide’ adjuster: • To fasten buckle ‘click’ two halves together. • To release buckle, press tabs on the sides of buckle and pull two halves apart.

  • Page 9: Tray (Optional)

    UI MultiAdjust User Guide. iss1 07/21 15. Tray (Optional) The MultiAdjust can be fitted with a tray, which can be used to assist in the user’s upper limb positioning and engagement in activities; it should never be used as a restraint.
  • Page 10 Once in the desired position tighten the hand wheel to lock the pad in place. • If the MultiAdjust is to be used without the adjustable lateral supports undo the hand wheel controlling the width adjustment and slide the laterals completely out of the adjustment blocks.
  • Page 11 However, do not store or use the chair in damp or wet areas. • Do not attempt to carry out any structural maintenance or adjustment of the MultiAdjust or its accessories without consulting CareFlex or the local CareFlex Distributor. Details of cover material care and maintenance can be found in the Fabric Guide. Both are available in hard copy on request from CareFlex, or are free to download at www.careflex.co.uk.
  • Page 12 UI MultiAdjust User Guide. iss1 07/21 Identification Each MultiAdjust chair has a unique chair number which must be quoted during any correspondence with CareFlex or the local CareFlex distributor. This is on a white label on the back of the chair. Important Safety Information •...
