Maintenance - Scell-it ELEMENT FIVE User Manual

EN
3
FR
BATTERY LEVEL
PL
INDICATOR
CZ
4 lights on the battery panel allows you to check the
remaining power. Press and hold the blue button to
check the battery level :
4 lights on : 100% remaining
3 lights on : 75% remaining
2 lights on : 50% remaining
1 light on : 25% remaining
The information on the battery panel can vary
(+/- 5%) due to environmental conditions.
Red light on the charger: the
battery has to be charged
4
LED
LIGHTS
6 •
ELEMENT FIVE - User Manual
100%
Green light on the charger:
the battery is fully charged
ELEMENT FIVE is equipped with 3 powerful LED lights
to enlight the work place.
Turn on the light only
Press the trigger half way to turn on the light.
The lights will shutdown after 10'.
Turn on the tool with the lights on
Press the trigger to set the rivet. The lights
turn on and remain on until 10' after the
trigger is released.
5

MAINTENANCE

75%
REPLACING NOSE PIECE
50%
25%
1 3 2
Special wrench supplied
with the tool Wrench SW14
1.
Use the special wrench 3 to
unscrew the nosepiece.
3. 4.
Activate the trigger
5.
Use the special
3
wrench
the nosepiece.
EN
FR
PL
CZ
2.
Remove the nosepiece
Screw the nosepiece pressing
the trigger
to screw
• 7
ELEMENT FIVE - User Manual
