Scell-it ELEMENT FIVE User Manual page 3

reduce this risk. will start when the lithium battery is
EN
used the first time. Please charge the
12. Never recharge a fully charged
lithium battery to prevent battery from
battery. Overcharging shortens the
damage.
FR
battery service life.
b. After using, the temperature of the
13. Under abusive conditions, liquid
lithium battery will keep rising. When
may be ejected from the battery; avoid
PL
the temperature of the lithium battery
contact. If contact accidentally occurs,
exceeds the max temperature, battery
flush with water. If liquid contacts eyes,
CZ "temperature protects function "will
additionally seek medical help. Liquid
start.
ejected from the battery may cause
irritation or burns. The lithium battery will be locked to
prevent dangerous overheating please
14. Suitable charging environment:
wait till the lithium battery cools down.
a. Charging temperature:
c. The overload on the battery can
0°C ~40°C (32°F~104°F)
cause a voltage peak on the tool.. The
lithium battery pack will start "electric
b. Discharging temperature:
current overload protection function" to
0°C ~40°C (32°F~104°F)
protect the lithium battery and battery
c. Storage temperature:
P .C. board. In this situation, the tool
will stop few seconds till protecting
-20°C ~60°C (-4°F~140°F)
function relieve automatically. If the tool
Please wait one-hour first before
can not be used after few minutes, the
charging, if the battery pack is stored
lithium battery might be in "low-voltage
under 0°C (32°F).
protecting function" or "temperature
15. Storage instructions of battery:
protecting function". Please follow
above mentioned ways to relieve.
When battery pack is not in use, keep
it away from other metal objects like 17. A small leakage of liquid from
paper clips, coins, wrenchs, nails, the battery pack may occur under
screws, or other small metal objects extreme usage or temperature. This
that can make a connection from does not necessarily indicate a
one terminal to another. Shorting the failure of the battery pack. However,
battery terminals together may cause
if the outer seal is broken and
burns or a fire.
this leakage comes into contact
with your skin: Wash the affected
a. If battery pack is at a low
area quickly with soap and water.
temperature (under -20°C / -4°F) its
Neutralize the liquid with a mild acid
chemical elements will be in solid state
such as lemon juice or vinegar. If the
and resistance in charging will become
leakage gets in your eyes. Flush your
too high for the battery to be charged.
eyes with clean water for a minimum
b. If battery pack is at a high
of 10 minutes and seek immediate
temperature (above 60°C / 140°F),
medical attention. Inform the medical
its chemical elements will be in a
staff that the liquid is a 25-35% solution
vapor state that can make the battery
of potassium hydroxide.
ineffective in a short time.
18. Do not store or carry a spare
16. The lithium battery safe protection
battery pack in a pocket or toolbox or
function:
any other place where it may come into
a. The «low-voltage protect function» contact with metal objects. The battery
4 •
ELEMENT FIVE - User Manual
pack may be short circuited causing
damage to the battery pack, burns or
a fire. If storing or disposing the battery
pack, cover the terminals with a heavy
insulation tape to ensure short circuit
cannot occur. Batteries, when stored
for a long period of time, will discharge.
19. DANGER: If the battery pack is
cracked or damaged in any other way,
do not insert it in the charging base.
There is a danger of electric shock or
electrocution.
20. WARNING: Do not allow any liquid
to come into contact with the charger.
There is a danger of electric shock.
21. Do not place any object on the
top of the charger as it could cause
overheating. Do not place the charger
near any heat source.
22. Do not disassemble the charger.
Take it to an authorized service center
when service or repair is required.
Incorrect re-assembly may result
in the risk of fire, electric shock or
electrocution.
23. This appliance is not intended for
use by persons (including children)
with reduced physical, sensory
or mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision
or instruction concerning use of the
appliance by a person responsible for
their safety.
24. lf the supply cord is damaged, it
must be replaced by the manufacturer,
its service agent or similarly qualified
persons in order to avoid a hazard.
1
OPERATING
INSTRUCTIONS
RIVETING
1- Choose the nosepiece according to the diameter of the rivet to
set. Please refer to the adjacent table to find the right nosepiece.
CAUTION
the use of the wrong nosepiece can damage the tool.
2 - Place the rivet mandrel into the nosepiece.
3 - Place the rivet body in the hole of the assembling part.
4 - Operate the trigger until the rivet mandrel breaks.
2
MANDREL
CONTAINER
Make sure that the mandrel container has enough
space to receive the mandrel of the rivet in setting. The
mandrel container can be easily emptied :
1. Turn the mandrel container
2. Remove the mandrel container and
3. Put the mandrel container in place on
4. Turn the mandrel container clockwise.
CAUTION
A full mandrel collector can cause a jamming of the rivet mandrel inside the tool and
result in a tool malfunction.
NOSEPIECES
Nosepiece Rivet Ø (mm)
A Ø2.4
B Ø3.0/3.2
C Ø4.0
D Ø4.8/5.0
counterclockwise.
You must hear a «click»
empty it in a proper container.
the tool .
You must hear a «click»
ELEMENT FIVE - User Manual
EN
FR
PL
CZ
• 5
