SPECIFICATIONS

EN
FR
PL
CZ
TOOL
battery tool for blind rivet Ø2.4mm-5.0mm
Tool net weight: 2,15kgs / 4,73 lbs
(including battery)
Stroke: 21mm / 0,827''
Power: DC motor 18V
Traction power: 12000N / 2640 lbs min.
BATTERY
Rated Voltage: 18V
Battery Type: Li-ion
Cells: 5 cells
Capacity: 2.0 Ah
Weight: 0,36 kgs
READ AND UNDERSTAND ALL OF THE SAFETY PRECAUTIONS, WARNINGS AND
OPERATING INSTRUCTIONS IN THE INSTRUCTION MANUAL BEFORE OPERATING OR
MAINTAINING THIS POWER TOOL.
2 •
ELEMENT FIVE - User Manual
Trigger
Nosepiece
Mandrel container
Belt hook
Battery
CHARGER
Input Voltage: 100-240VAC/50-60Hz
Output Voltage: 18VDC
Output Current: 2,5A max.
Weight: 0,37 kgs
IMPORTANT
wrench before turning the power tools
on. A wrench or wrench left attached
SAFETY
part of the power tool may result in
personal injury.
INFORMATION
5.Do not overreach. Keep proper
footing and balance at all times. This
WARNING:
enables better control of the power tool
in unexpected situations.
Read all safety warnings
6.Dress properly. Do not wear loose
and all instructions. Failure
clothing. Keep your hair, clothing and
to follow the warnings and
gloves away from moving parts. Loose
instructions may result in
clothes or a long hair can be caught in
electric shock, fire and/ moving parts.
or serious injury. Save all
7.You must check that the mandrel
container is well connected and
warnings and instructions
properly used.
for future reference.
Power tool use and care
W
ork area
1.Do not force the power tool. Use the
1.Keep work area clean and well
correct power tool for your application.
lit. Cluttered and dark areas invite
The correct power tool will do the job
accidents.
better and safer at the rate for which it
2.Do not operate power tools on
was designed.
explosive atmospheres, such as in the
2.Do not use the power tool if the on-off
presence of flammable liquids, gases
switch is defective. Any power tool that
or dust. Power tools create sparks
cannot be controlled with the switch is
which may ignite the dust of fumes.
dangerous and must be repaired.
3.Keep children and bystanders
3.Disconnect
away while operating a power tool.
the power tool before making an
Distractions can cause you to lose
adjustment, changing accessories, or
control.
storing power tools. Such preventive
safety measures reduce the risk of
Electric safety
starting the power tool accidentally.
1.Do not expose power tools to rain or
4.Store the power tool out of the reach
wet conditions. Water entering a power
of children and do not allow persons
tool will increase the risk of electric
unfamiliar with the power tool or these
shock.
instructions to operate the power tool.
Power tools are dangerous in the hands
Personal safety
of untrained users.
1.Stay alert, watch what you are
5.Maintain your power tool. Check for
doing and use common sense when
misalignment of binding of moving
operating a power tool. Do not use a
parts, breakage of parts and any other
power tool while you are tired or under
condition that may affect the power
the influence of drugs, alcohol or
tools operation. If damaged, have
medication. A moment of inattention
the power tool repaired before use.
while operating power tools may result
Many accidents are caused by poorly
in serious personal injury.
maintained power tools.
2.Use personal protective equipment.
6. Use the power tool, accessories
Always wear goggles. Protective
and tool bits etc., in accordance with
equipment such as dust mask,
these instructions and in the manner
non-skid safety shoes, hard hat, or
intended for the particular type of
hearing protection used for appropriate
power tool, taking into account the
conditions will reduce personal injuries.
working conditions and the work to be
3.Prevent unintentional starting. Ensure performed. The use of the power tool
the switch is in the off-position before for operations different from intended
connecting to power source and/or could result in a hazardous situation.
battery pack, picking up or carrying
the tool. Carrying power tools with
Service
your finger on the switch or energizing
1.Have your power tool serviced by
power tools that have the switch on
a qualified repair person using only
invites accidents.
identical replacement parts. This will
4.Remove any adjusting wrench or
ensure that the safety of the power tool
is maintained.
Specific warnings
1.Hold power tool by insulated
gripping surfaces, when performing
an operation where the fastener may
contact hidden wiring.
Fasteners contacting a «live» wire may
make exposed metal parts of the power
tool «live» and could give the operator
an electric shock.
IMPORTANT SAFETY
INSTRUCTIONS FOR
CHARGER & BATTERY
1. Before using the battery charger,
read all instructions and cautionary
markings on battery charger, battery,
and product using battery.
2. Do not expose battery & battery
charger to water, rain or snow.
3. Use power tool only with specifically
designated battery packs. The use of
any other battery packs may create a
risk of injury and fire.
4. Do not charge at voltage higher
the battery from
than indicated as charger specification;
otherwise, the charger will burn up.
5. Recharge only with the charger
specified by the manufacturer. A
charger that is suitable for one type of
battery pack may create a risk of fire
when used with another battery pack.
6. To reduce risk of damage of the
charger plug and cord, pull by plug
when disconnecting battery charger.
7. Make sure charger is located so that
it will not be stepped on cord, tripped
over, or otherwise subjected to damage
or stress.
8. An extension cord should not be
used unless absolutely necessary.
The use of improper extension cord
could result in a risk of fire and electric
shock. If extension cord must be used
make sure, it is correct and property
connected.
9. Do not operate battery charger with
damaged cord or plug - replace them
immediately.
10. Do not operate battery charger
if it has received a sharp blow, been
dropped, or otherwise damaged in
any way; send it back to a qualified
serviceman.
11. To reduce risk of electric shock,
unplug charger from receptacle
before attempting any maintenance or
cleaning. Removing the battery will not
