Page 2: Table Of Contents
4.2.1.6 Base sheet thickn. 4.2.2 Info fields 4.2.3 Buttons Load Start 4.4.1 Tool change 4.4.1.1 Automatic 4.4.1.2 Manual 4.4.1.3 Spindle control 4.4.2 Execution Offset 4.5.1 Teach-In Bungard Elektronik GmbH&Co.KG ·Rilke Str. 1 · D-51570 Windeck Tel 02292 5036 · Fax 6175 · info@bungard.de... - Page 3 6.1.1 Clamp fixing 6.1.2 Span fixing Drilling 6.2.1 Bare boards 6.2.2 Presensitized base mat. 6.2.3 Etched PCBs Routing Error messages Relation of speed settings Appendix Bungard Elektronik GmbH&Co.KG ·Rilke Str. 1 · D-51570 Windeck Tel 02292 5036 · Fax 6175 · info@bungard.de...
- Page 4 0. Application The BUNGARD CCD machines are manufactured by Bungard Elektronik, Rilke Straße 1, 51570 Windeck, Germany and are brought into circulation in European countries via local dis- tributors or agents.
-
Page 5: Declaration Of Conformity
Laminator RLM 419p, RLM 426p Rollverzinner RT 12R Bürstmaschine RBM 300, 400, 402 Multilayerpresse RMP210 Tauchbeschichter RDC 10, 12 Bohr- und Fräsmaschine BUNGARD CCD Durchkontaktierungsanlage COMPACTA Abwasserreinigungsanlage IONEX mit den Anforderungen der Normen EN 50 081-1, EN 50082-1 fullfil the requirements of the standards... -
Page 6: Introduction
To run the machine, you need an external computer. The hard- and software requirements are described in chapter II.0. We hope that you enjoy using the BUNGARD CCD. Please let us know if we can be of any supplementary technical assistance. -
Page 7: Trouble Shooting
Put the machine onto a stable, even table and adjust the machine's 4 feet by turning them. A stable desk and a proper setting are important to prevent vibrations etc. Bungard Elektronik GmbH&Co.KG ·Rilke Str. 1 · D-51570 Windeck Tel 02292 5036 · Fax 6175 · info@bungard.de... -
Page 8: Mounting The Spindle
Press and turn right the knob to close the chuck. To gain better access to the tool, You may lift the spindle but it is not recommended to pull it off entirely. Bungard Elektronik GmbH&Co.KG ·Rilke Str. 1 · D-51570 Windeck Tel 02292 5036 · Fax 6175 · info@bungard.de... -
Page 9: Maintenance
After changing the belts it is likely that the machine needs recalibration. See chapter 4.7.7 for a description of how to determine the X and Y correction factors. Bungard Elektronik GmbH&Co.KG ·Rilke Str. 1 · D-51570 Windeck Tel 02292 5036 · Fax 6175 · info@bungard.de... -
Page 10: Software
The machine comes with a standard cable with 9 pin sub-D connectors. If your computer has a 25 pole sub-D connector, please use a 1:1 25 on 9 pole adaptor. Bungard Elektronik GmbH&Co.KG ·Rilke Str. 1 · D-51570 Windeck Tel 02292 5036 · Fax 6175 · info@bungard.de... -
Page 11: Conventions
To load files from another drive, move the cursor to the input line, enter the drive name and a wildcard extension (i. e. E:*.*) and press ALT+O. To quit the file selector without action, press ALT+C (Cancel). Bungard Elektronik GmbH&Co.KG ·Rilke Str. 1 · D-51570 Windeck Tel 02292 5036 · Fax 6175 · info@bungard.de... -
Page 12: Mouse
The software will then initialize, open the serial interface and ca- librate the speed for driving the stepper motors. Except for a litt- Bungard Elektronik GmbH&Co.KG ·Rilke Str. 1 · D-51570 Windeck Tel 02292 5036 · Fax 6175 · info@bungard.de... -
Page 13: Main Menu
In the first line of this box there will be a short status information like "Drilling...", "Moving...", "Spindle Start", "Spindle Stop", "Tool Change" or else. Bungard Elektronik GmbH&Co.KG ·Rilke Str. 1 · D-51570 Windeck Tel 02292 5036 · Fax 6175 · info@bungard.de... -
Page 14: Interruption
AT-compatible, the program will not show this dia- logue but will give a short mes- sage at the DOS prompt. Bungard Elektronik GmbH&Co.KG ·Rilke Str. 1 · D-51570 Windeck Tel 02292 5036 · Fax 6175 · info@bungard.de... -
Page 15: Main Menu
High values may produce coordinates out of the table range. See 4.2.1.3, clipping. The decimal digits are rounded to multiples of 1 mil during drilling / routing. Bungard Elektronik GmbH&Co.KG ·Rilke Str. 1 · D-51570 Windeck Tel 02292 5036 · Fax 6175 · info@bungard.de... -
Page 16: Clipping
An invalid entry will be rejected as soon as you try to leave the main menue. You may alter the configuration file in order to change the default value. Bungard Elektronik GmbH&Co.KG ·Rilke Str. 1 · D-51570 Windeck Tel 02292 5036 · Fax 6175 · info@bungard.de... -
Page 17: Base Sheet Thickn
If errors occurred when loading, the start button remains inactive. In this case, you should either read another file or quit the program and check the drill file for errors. Bungard Elektronik GmbH&Co.KG ·Rilke Str. 1 · D-51570 Windeck Tel 02292 5036 · Fax 6175 · info@bungard.de... -
Page 18: Start
ESC key. Keep it pressed for a short time until a message like "Interrupted... Z axis lift, Spindle Stop" appears. After the spindle stop, the following dialogue appears: Bungard Elektronik GmbH&Co.KG ·Rilke Str. 1 · D-51570 Windeck Tel 02292 5036 · Fax 6175 · info@bungard.de... -
Page 19: Offset
The distance for each movement is set by a choice from the radio buttons in the left lower corner of the screen. Possible values are 1, 10, 100 or 1000 mil. Bungard Elektronik GmbH&Co.KG ·Rilke Str. 1 · D-51570 Windeck Tel 02292 5036 · Fax 6175 · info@bungard.de... -
Page 20: Teach-In
15 tools in a file, an error message comes up. The drill rack´s empty positions have a "- -" entry in the name column. Bungard Elektronik GmbH&Co.KG ·Rilke Str. 1 · D-51570 Windeck Tel 02292 5036 · Fax 6175 · info@bungard.de... -
Page 21: Info Fields
For this reason the driver is capable of routing a vector chain in multiple passes (iterations) with increasing routing depths. Bungard Elektronik GmbH&Co.KG ·Rilke Str. 1 · D-51570 Windeck Tel 02292 5036 · Fax 6175 · info@bungard.de... -
Page 22: Speed Xy
In addition to the following explanations, please also have a look at the CFG files by use of an ASCII editor. Bungard Elektronik GmbH&Co.KG ·Rilke Str. 1 · D-51570 Windeck Tel 02292 5036 · Fax 6175 · info@bungard.de... -
Page 23: File
Set it to a value that is high enough to avoid any collision with any fixing aids on the machine table. Bungard Elektronik GmbH&Co.KG ·Rilke Str. 1 · D-51570 Windeck Tel 02292 5036 · Fax 6175 · info@bungard.de... -
Page 24: Correct. Factors
When you leave the following dialogueby the DONE button, the chuck closes again. The dialog shows the values that are set in the TOOLS menu. You will then be prompted to confirm the spindle start. Bungard Elektronik GmbH&Co.KG ·Rilke Str. 1 · D-51570 Windeck Tel 02292 5036 · Fax 6175 · info@bungard.de... -
Page 25: Configuration Files
(CONFIG. menu) is well set! After the first pane- lization, the buttons CALC and DONE are inactive until another drill file was loaded. Bungard Elektronik GmbH&Co.KG ·Rilke Str. 1 · D-51570 Windeck Tel 02292 5036 · Fax 6175 · info@bungard.de... -
Page 26: Quit
1 base sheet and 1 to 3 boards of the same size. The two disks near to the machine's zero position determine the board zero position. Bungard Elektronik GmbH&Co.KG ·Rilke Str. 1 · D-51570 Windeck Tel 02292 5036 · Fax 6175 · info@bungard.de... -
Page 27: Span Fixing
(C) 1991-2001 Copyright on software and manual by Bungard Elektronik. All rights reserved. No part of this manual or the software may be copied, altered, reproduced or reduced to any form without prior written consent of Bungard Elektronik. -
Page 28: Error Messages
Error in bidirect. Sorting, cont. without sorting. Prior to offset teaching: Offset position not reached. (Do not press ESC during this action) Input Error: (Pict.) Bungard Elektronik GmbH&Co.KG ·Rilke Str. 1 · D-51570 Windeck Tel 02292 5036 · Fax 6175 · info@bungard.de... - Page 29 30 000 26 500 24 000 Z-axis feed (m/min) This table is based on a cutting speed of 150 m/min at the router tip. Bungard Elektronik GmbH&Co.KG ·Rilke Str. 1 · D-51570 Windeck Tel 02292 5036 · Fax 6175 · info@bungard.de...
