Bungard RMP 210 Instructions For Use Manual

Multilayerpress
Instructions for Use
Preface
The RMP 210 multilayerpress was designed
for use in PCB labs. It allows quick
prototyping of multilayer PCBs of 4 or more
layers according to industry standards. A
compact and floor standing aluminium rack
contains the pressure supply and heated
press plates, covered by a big door with
security switch.
The unit is controlled by two digital
thermostats,
pressure valve with meter. Two strong air
ventilators
during cooling cycle.
Bungard Elektronik GmbH & Co. KG, Rilkestraße 1, 51570 Windeck – Germany
Tel.: +49 (0) 2292/5036, Fax: +49 (0) 2292/6175, E-mail: support@bungard.de
RMP 210
one digital timer
are activated automatically
To produce a multilayer with this machine
you have to go through the following steps:
•
•
•
•
•
•
Taking out the multilayer
The whole process lasts about 3 hours.
When you insert a batch of 250 x 350 mm,
you get a usuable multilayer size of approx.
210 x 300mm, depending on the quality of
the pcb material you are using (losses in
size due to resin flow inside of the stack).
This Multilayerpress is designed for use in
laboratories and shall be operated by skilled
staff.
The general safety rules for operating elec-
trical machines need to be applied.
Before all maintenance work disconnect the
machine from power supply.
Children and pets need to be kept away.
The installation location of the machine is of
special importance. You should choose a
mostly dust free room with a non corrosive
atmosphere.
There is a door security switch that will de-
and a
activate the pressure bottom when door is
opened during operation. THAT MAY DES-
TROY YOUR MULTILAYER but it is an im-
portant security feature of the machine.
Fixing and inserting the prepreg batch
Building up pressure
Turning on the heater
Heat up cycle
Press cycle at set temperature
cool down cycle
Safety Regulations
Page 1 / 6
